Intel UHD Graphics 620

De Intel UHD Graphics 620 (GT2) is een geïntegreerde grafische kaart die wordt aangetroffen in verschillende ULV-processors (Ultra Low Voltage) van de Kaby Lake-generatie (8ste generatie Core). In vergelijking met de gelijkaardig genaamde Intel HD Graphics 620 in de Kaby Lake-CPU's van 2016 werd alleen de naam gewijzigd van HD naar UHD. De GPU is geklokt aan 1150 MHz en dus 100 MHz hoger dan de oude HD Graphics 620 (max. 1050 MHz), waardoor de prestaties dus vergelijkbaar zijn. Door het ontbreken van discreet grafisch geheugen of eDRAM-cache, moet de UHD 620 het hoofdgeheugen aanspreken (2x 64bit DDR3/DDR4).
De precieze prestaties van de UHD Graphics 620 hangen af van verschillende factoren zoals de grootte van het L3-cache, geheugenconfiguratie (DDR3/DDR4) en maximale kloksnelheid van het het specifieke model en zijn vergelijkbaar met de Intel HD Graphics 620 en Intel HD Graphics 630. In vergelijking met de gemiddelde HD Graphics 620 heeft de UHD Graphics in onze gaming-benchmarks ook baat bij de quad-core-CPU. De grafische kaart zou zich daarom moeten situeren tussen een GeForce 910M en 920M van Nvidia. Voor games worden de drivers echter minder vaak geüpdatet en getest dan met een GeForce-GPU. In onze tests is de UHD 620 vooral geschikt voor simpele games zoals Team Fortress 2, Rocket League of Farming Simulator 17. Zie onder voor een lijst van moderne games getest met verschillende laptopmodellen.
De herziene video-engine biedt nu hardwarematige ondersteuning voor H.265/HEVC Main10 met 10-bit-kleuren. Daarnaast kan de VP9-codec van Google ook in hardware gedecodeerd worden. De eerste modellen bieden geen ondersteuning voor HDCP 2.2 en dus Netflix 4K. Dit werd toegevoegd met de nieuwe modellen in 2017 en in het begin van 2017 werden ook de oudere CPU-modellen zoals de i3-7100U uitgerust met een nieuwe S-Spec Code die HDCP 2.2 ondersteunt. HDMI 2.0 wordt echter nog altijd alleen ondersteund met een externe conversiechip (LSPCon).
De UHD Graphics 620 wordt aangetroffen in laptop-processors met een TDP van 15 Watt en is dus geschikt voor compacte laptops en ultrabooks. Het energieverbruik bij het spelen van The Witcher 3 (met een externe monitor) was vergelijkbaar met dat van een Intel HD Graphics en behoort tot de laagste van onze metingen. Discrete GPU's zoals de GeForce 940MX verbruiken een stuk meer.
Fabrikant | Intel |
Gen. 9.5 Serie | Iris Plus Graphics 655 | 48 @ 0.3 - 1.2 GHz | | Iris Plus Graphics 650 | 48 @ 0.3 - 1.1 GHz | 64/128 bit | Iris Plus Graphics 645 | 48 @ 0.3 - 1.15 GHz | | Iris Plus Graphics 640 | 48 @ 0.3 - 1.05 GHz | 64/128 bit | UHD Graphics 630 | 24 @ 0.3 - 1.15 GHz | 64/128 bit | UHD Graphics P630 | 24 @ 0.3 - 1.2 GHz | 64/128 bit | HD Graphics 630 | 24 @ 0.3 - 1.15 GHz | 64/128 bit | HD Graphics P630 | 24 | 64/128 bit | UHD Graphics 620 | 24 @ 0.3 - 1.15 GHz | 64/128 bit | HD Graphics 620 | 24 @ 0.3 - 1.05 GHz | 64/128 bit | UHD Graphics 617 | 24 @ 0.3 - 1.15 GHz | 64/128 bit | UHD Graphics 615 | 24 @ 0.3 - 1 GHz | 64/128 bit | HD Graphics 615 | 24 @ 0.3 - 1.05 GHz | 64/128 bit |
|
Codenaam | Kaby-Lake-Refresh GT2 |
Architectuur | Gen. 9.5 |
Pipelines | 24 - verenigd |
Core-snelheid | 300? - 1150 (Boost) MHz |
Geheugenbusbreedte | 64/128 bit |
Geheugentype | DDR3/DDR4 |
Gedeeld geheugen | ja |
DirectX | DirectX 12_1 |
technologie | 14 nm |
Faciliteiten | QuickSync |
Aangekondigde datum | 01.09.2017 |
CPU in UHD Graphics 620 | GPU Base Speed | GPU Boost / Turbo |
---|
Intel Core i7-10810U | 6 x 1100 MHz, 15 W | 300 MHz | ? MHz | Intel Core i7-10710U | 6 x 1100 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i7-10610U | 4 x 1800 MHz, 15 W | 300 MHz | 1150 MHz | » show 15 more | Intel Core i7-10510U | 4 x 1800 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i5-10310U | 4 x 1700 MHz, 15 W | 300 MHz | ? MHz | Intel Core i7-8665U | 4 x 1900 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i7-8650U | 4 x 1900 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i5-10210U | 4 x 1600 MHz, 15 W | 300 MHz | 1100 MHz | Intel Core i7-8565U | 4 x 1800 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i5-8365U | 4 x 1600 MHz, 15 W | 300 MHz | 1100 MHz | Intel Core i5-8265U | 4 x 1600 MHz, 15 W | 300 MHz | 1100 MHz | Intel Core i7-8550U | 4 x 1800 MHz, 15 W | 300 MHz | 1150 MHz | Intel Core i5-8350U | 4 x 1700 MHz, 15 W | 300 MHz | 1100 MHz | Intel Core i5-8250U | 4 x 1600 MHz, 15 W | 300 MHz | 1100 MHz | Intel Core i3-10110U | 2 x 2100 MHz, 15 W | 300 MHz | 1000 MHz | Intel Core i3-8145U | 2 x 2100 MHz, 15 W | 300 MHz | 1000 MHz | Intel Core i3-8130U | 2 x 2200 MHz, 15 W | 300 MHz | 1000 MHz | Intel Celeron 5205U | 2 x 1900 MHz, 15 W | 300 MHz | 900 MHz | min. - max. | | 300 MHz | 900 - 1150 MHz |
|
Benchmarks
Performance Rating - 3DMark 11 + Fire Strike + Time Spy
6.7 pt (7%)
...
Intel UHD Graphics G1 (Ice Lake 32 EU) 1%
Intel UHD Graphics 630 3%
...
AMD Radeon RX 6800 XT 1323%
3DMark - 3DMark Time Spy Score
min: 343 gem: 434 mediaan: 434.5 (2%) max: 512 Points
Intel UHD Graphics 600 -72%
...
Intel HD Graphics 620 -16%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -10%
Intel HD Graphics 630 -2%
AMD Radeon R7 M360 7%
Intel UHD Graphics 630 8%
NVIDIA GeForce 920MX 9%
Intel UHD Graphics G1 (Ice Lake 32 EU) 10%
Intel Iris Plus Graphics 640 15%
AMD Radeon R7 M445 22%
...
AMD Radeon RX 6900 XT 3944%
3DMark - 3DMark Time Spy Graphics
min: 299 gem: 378 mediaan: 378 (2%) max: 443 Points
Intel UHD Graphics 600 -71%
...
Intel UHD Graphics 617 -22%
Intel HD Graphics 620 -15%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -8%
Intel HD Graphics 630 -3%
Intel UHD Graphics 630 7%
AMD Radeon R7 M360 8%
Intel UHD Graphics G1 (Ice Lake 32 EU) 10%
NVIDIA GeForce 920MX 10%
Intel Iris Plus Graphics 640 17%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 65949 gem: 89052 mediaan: 88807 (14%) max: 115515 Points
...
AMD Radeon R7 M360 -7%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -1%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 6%
Intel HD Graphics 630 7%
ARM Mali-G78 MP14 8%
Intel UHD Graphics 630 9%
...
3DMark - 3DMark Ice Storm Extreme Graphics
min: 29002 gem: 43200 mediaan: 42660 (6%) max: 59483 Points
...
Intel HD Graphics 620 -4%
Intel UHD Graphics Xe G4 48EUs -3%
AMD Radeon R7 M360 -2%
AMD Radeon R7 M445 1%
Intel UHD Graphics G1 (Ice Lake 32 EU) 3%
AMD Radeon R7 M340 4%
...
AMD Radeon RX 6800 XT 877%
3DMark - 3DMark Cloud Gate Score
min: 5821 gem: 8157 mediaan: 8135 (11%) max: 10960 Points
...
NVIDIA GeForce GT 710 -6%
Intel Iris Plus Graphics 640 -2%
Intel HD Graphics 630 5%
NVIDIA Quadro M520 5%
AMD FirePro W4100 9%
Intel UHD Graphics G1 (Ice Lake 32 EU) 9%
AMD Radeon R9 M385X 10%
Intel UHD Graphics 630 12%
Intel Iris Plus Graphics 650 12%
Intel UHD Graphics Xe G4 48EUs 13%
...
AMD Radeon RX 6800 XT 779%
3DMark - 3DMark Cloud Gate Graphics
min: 6910 gem: 9222 mediaan: 9312 (5%) max: 11436 Points
...
NVIDIA GeForce 930MX -3%
AMD Radeon R6 M340DX -3%
AMD Radeon R7 M260X -2%
NVIDIA Quadro K620M -1%
NVIDIA GeForce 920MX -1%
Intel UHD Graphics 630 1%
Intel HD Graphics 630 1%
AMD Radeon R7 M445 4%
...
3DMark - 3DMark Fire Strike Standard Score
min: 538 gem: 1055 mediaan: 1071 (3%) max: 1298 Points
...
AMD Radeon R5 (Bristol Ridge) 0%
AMD Radeon R7 M460 0%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 5%
Intel UHD Graphics 630 7%
AMD Radeon R7 M340 10%
...
AMD Radeon RX 6900 XT 3602%
3DMark - 3DMark Fire Strike Standard Graphics
min: 557 gem: 1152 mediaan: 1164 (2%) max: 1420 Points
...
AMD FirePro W2100 -6%
AMD Radeon R7 (Carrizo) -4%
AMD Radeon R6 M255DX -3%
AMD Radeon R7 M360 -1%
AMD Radeon R7 M460 2%
Intel UHD Graphics 630 5%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 6%
...
AMD Radeon RX 6900 XT 4291%
3DMark - 3DMark Ice Storm Graphics
min: 13790 gem: 68374 mediaan: 67512 (9%) max: 102010 Points
...
Intel UHD Graphics 630 -6%
Intel HD Graphics 620 -3%
NVIDIA GeForce RTX 2070 Super Max-Q -2%
NVIDIA GeForce 930MX 1%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 4%
NVIDIA Quadro P520 5%
...
AMD Radeon RX 6800 XT 564%
3DMark 11 - 3DM11 Performance Score
min: 1175 gem: 1927 mediaan: 1935 (5%) max: 2283 Points
...
AMD Radeon R5 M430 -5%
AMD Radeon R5 M335 -2%
Intel HD Graphics 630 0%
Intel UHD Graphics 630 1%
AMD Radeon R7 M260 2%
AMD Radeon R7 (Carrizo) 3%
AMD Radeon R6 M255DX 3%
...
AMD Radeon RX 6900 XT 2101%
3DMark 11 - 3DM11 Performance GPU
min: 1235 gem: 1743 mediaan: 1744 (3%) max: 2006 Points
...
Intel UHD Graphics 630 -2%
AMD Radeon R5 (Bristol Ridge) -2%
AMD Radeon R5 (Carrizo) -2%
AMD Radeon R5 M335 2%
AMD Radeon R7 (Carrizo) 3%
NVIDIA GeForce 920MX 5%
...
AMD Radeon RX 6900 XT 3292%
3DMark Vantage
3DM Vant. Perf. total +3DMark Vantage - 3DM Vant. Perf. total
7761 Points (8%)
...
NVIDIA GeForce 920MX -5%
NVIDIA GeForce GTX 460M -2%
AMD Radeon R7 M260X -2%
Intel HD Graphics 630 -1%
Intel UHD Graphics 630 -1%
NVIDIA Quadro K620M 2%
NVIDIA GeForce 930MX 4%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 6%
...
AMD Radeon RX 6800 XT 1144%
3DM Vant. Perf. GPU no PhysX +3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
6341 Points (6%)
...
AMD Radeon R7 M445 -5%
Intel UHD Graphics 630 -4%
Intel HD Graphics 630 -2%
NVIDIA GeForce 920MX 5%
...
3DMark 2001SE - 3DMark 2001 - Standard
34467 Points (36%)
Honor Magicbook | i5-8250U | 8192 MB | 1468 / MHz | | 34467 |
...
AMD Radeon HD 6490M -3%
NVIDIA GeForce GTX 460M 1%
...
3DMark 06 3DMark 06 - Standard 1280x1024 +min: 7653 gem: 10759 mediaan: 10622 (20%) max: 14158 Points
