Intel UHD Graphics 630
De Intel UHD Graphics 630 (GT2) is een geïntegreerde grafische kaart, die kan worden aangetroffen in diverse desktop- en notebookprocessoren van de Coffee-Lake generatie. De "GT2"-versie van de GPU biedt 24 Execution Units (EU's) en de kloksnelheden zijn afhankelijk van het CPU-model. Door het ontbreken van een eigen grafisch geheugen of eDRAM cache, moet de UHD 630 toegang hebben tot het hoofdgeheugen (2x 64-bit DDR3L-1600 / DDR4-2133). Vergeleken met de oude HD Graphics 630 (Kaby-Lake) is de nieuwe UHD GPU identiek, maar kan hij iets hoger worden geklokt.
De exacte prestaties van de UHD Graphics 630 zijn afhankelijk van verschillende factoren, zoals TDP, L3 Cache, geheugen (DDR3/DDR4) en maximale klokfrequentie van het specifieke model. Ze zouden echter vrij gelijkaardig moeten zijn aan de HD Graphics 530 en HD Graphics 630 en dus enkel geschikt voor niet veeleisende games zoals Overwatch of Farming Simulator 2017 (lage details).
De features van de UHD 630 zijn hetzelfde als die van de HD 630 en zo wordt het H.265/HEVC Main10 10-bit kleurdiepteprofiel in hardware ondersteund. Daarnaast wordt HDCP 2.2 in alle chips ondersteund, waardoor bijvoorbeeld 4K video's op Netflix kunnen worden gezet. HDMI 2.0 wordt echter nog steeds alleen ondersteund met een externe converterchip (LSPCon).
De UHD Graphics 630 kan worden gevonden in verschillende notebook en desktop processoren van verschillende TDP klassen (35 - 91 W).
Gen. 9.5 Serie Codenaam Kaby-Lake-H-GT2 Architectuur Gen. 9.5 Pipelines 24 - verenigd Core-snelheid 300 - 1150 (Boost) MHz Geheugenbusbreedte 64/128 bit Gedeeld geheugen ja API DirectX 12_1, OpenGL 4.4 technologie 14 nm Faciliteiten QuickSync Aangekondigde datum 01.10.2017
CPU in UHD Graphics 630 GPU Base Speed GPU Boost / Turbo Intel Core i9-10900K 10 x 3700 MHz, 125 W ? MHz ? MHz Intel Core i9-10850K 10 x 3600 MHz, 125 W ? MHz ? MHz Intel Core i9-10910 10 x 3600 MHz, 125 W ? MHz ? MHz » show 42 more Intel Core i9-9900KS 8 x 4000 MHz, 127 W 350 MHz 1200 MHz Intel Core i7-10700K 8 x 3800 MHz, 125 W ? MHz ? MHz Intel Core i9-9900K 8 x 3600 MHz, 95 W 350 MHz 1200 MHz Intel Core i7-10700 8 x 2900 MHz, 65 W 350 MHz 1200 MHz Intel Core i9-10980HK 8 x 2400 MHz, 45 W 350 MHz 1250 MHz Intel Core i9-10885H 8 x 2400 MHz, 45 W 350 MHz 1200 MHz Intel Core i9-10880H 8 x 2300 MHz, 45 W 350 MHz 1200 MHz Intel Core i7-10875H 8 x 2300 MHz, 45 W 350 MHz 1200 MHz Intel Core i9-9980HK 8 x 2400 MHz, 45 W 350 MHz 1250 MHz Intel Core i7-10870H 8 x 2200 MHz, 45 W 350 MHz 1200 MHz Intel Core i7-9700K 8 x 3600 MHz, 95 W 350 MHz 1200 MHz Intel Core i5-10600K 6 x 4100 MHz, 125 W ? MHz ? MHz Intel Core i9-9880H 8 x 2300 MHz, 45 W 350 MHz 1200 MHz Intel Core i7-8086K 6 x 3700 MHz, 95 W 350 MHz 1200 MHz Intel Core i7-8700K 6 x 3700 MHz, 95 W 350 MHz 1200 MHz Intel Core i7-9700 8 x 3000 MHz, 65 W 350 MHz 1200 MHz Intel Core i9-8950HK 6 x 2900 MHz, 45 W 350 MHz 1200 MHz Intel Xeon E-2186M 6 x 2900 MHz, 45 W 350 MHz ? MHz Intel Core i7-8700 6 x 3200 MHz, 65 W 350 MHz 1200 MHz Intel Core i5-9600K 6 x 3700 MHz, 95 W 350 MHz 1150 MHz Intel Core i9-9900T 8 x 2100 MHz, 35 W 350 MHz 1200 MHz Intel Core i7-9850H 6 x 2600 MHz, 45 W 350 MHz 1150 MHz Intel Core i7-9750H 6 x 2600 MHz, 45 W 350 MHz 1150 MHz Intel Core i7-10850H 6 x 2700 MHz, 45 W 350 MHz 1150 MHz Intel Core i7-10750H 6 x 2600 MHz, 45 W 350 MHz 1150 MHz Intel Xeon E-2176M 6 x 2700 MHz, 45 W 350 MHz ? MHz Intel Core i5-10500H 6 x 2500 MHz, 45 W 350 MHz 1050 MHz Intel Core i7-8850H 6 x 2600 MHz, 45 W 350 MHz 1150 MHz Intel Core i5-8600K 6 x 3600 MHz, 95 W 350 MHz 1150 MHz Intel Core i5-8500 6 x 3000 MHz, 65 W 350 MHz 1100 MHz Intel Core i7-8750H 6 x 2200 MHz, 45 W 350 MHz 1100 MHz Intel Core i5-8400 6 x 2800 MHz, 65 W 350 MHz 1050 MHz Intel Core i5-10400H 4 x 2600 MHz, 45 W 350 MHz 1100 MHz Intel Core i3-10320 4 x 3800 MHz, 65 W 350 MHz 1150 MHz Intel Core i5-10300H 4 x 2500 MHz, 45 W 350 MHz 1050 MHz Intel Core i5-8500T 6 x 2100 MHz, 35 W 350 MHz 1100 MHz Intel Core i5-9400H 4 x 2500 MHz, 45 W 350 MHz 1100 MHz Intel Core i5-10200H 4 x 2400 MHz, 45 W 350 MHz 1050 MHz Intel Core i5-9300H 4 x 2400 MHz, 45 W 350 MHz 1050 MHz Intel Core i5-8400H 4 x 2500 MHz, 45 W 350 MHz 1100 MHz Intel Core i5-8300H 4 x 2300 MHz, 45 W 350 MHz 1000 MHz Intel Core i3-8100H 4 x 3000 MHz, 45 W 350 MHz 1000 MHz min. - max. 350 MHz 1000 - 1250 MHz
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
4.9 pt (5%)
...
AMD Radeon R6 M340DX -4%
Intel UHD Graphics G1 (Ice Lake 32 EU) 0%
...
3DMark - 3DMark Time Spy Score
min: 425 gem: 474.5 mediaan: 479.5 (2%) max: 534 Points
Intel UHD Graphics 605 -73%
...
Intel HD Graphics 630 -10%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -9%
AMD Radeon R7 M360 -2%
Intel UHD Graphics G1 (Ice Lake 32 EU) 1%
AMD Radeon R7 M445 12%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 30%
Intel Iris Plus Graphics 650 31%
...
3DMark - 3DMark Time Spy Graphics
min: 367 gem: 409.5 mediaan: 414.5 (2%) max: 459 Points
Intel UHD Graphics 605 -72%
...
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -15%
Intel HD Graphics 630 -10%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -9%
AMD Radeon R7 M360 0%
Intel UHD Graphics G1 (Ice Lake 32 EU) 2%
AMD Radeon R7 M445 15%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 37815 gem: 97120 mediaan: 106362 (14%) max: 122355 Points
...
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -10%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -3%
Intel HD Graphics 630 -2%
Intel UHD Graphics G1 (Ice Lake 32 EU) 0%
Intel UHD Graphics Xe G4 48EUs 0%
AMD Radeon R7 M260X 1%
AMD Radeon R7 M460 8%
AMD Radeon Pro WX 3200 9%
AMD Radeon RX Vega 10 19%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 21%
...
3DMark - 3DMark Ice Storm Extreme Graphics
min: 19075 gem: 40640 mediaan: 45176 (6%) max: 48377 Points
...
AMD Radeon R5 (Bristol Ridge) -9%
AMD Radeon R7 M460 -5%
NVIDIA GeForce GTX 1050 Ti Max-Q -2%
AMD Radeon R6 M340DX -1%
AMD Radeon R7 (Carrizo) 1%
AMD Radeon R7 M360 4%
Intel UHD Graphics G1 (Ice Lake 32 EU) 5%
...
NVIDIA GeForce RTX 3080 Laptop GPU 922%
3DMark - 3DMark Cloud Gate Score
min: 3712 gem: 9196 mediaan: 9545 (12%) max: 11286 Points
...
Intel HD Graphics 630 -7%
NVIDIA Quadro M520 -7%
Intel UHD Graphics Xe G4 48EUs -5%
Intel UHD Graphics G1 (Ice Lake 32 EU) -4%
AMD Radeon R9 M385X -2%
Intel Iris Plus Graphics 650 -1%
NVIDIA Quadro P500 1%
AMD Radeon RX Vega 10 10%
...
3DMark - 3DMark Cloud Gate Graphics
min: 3863 gem: 9333 mediaan: 9798 (4%) max: 11199 Points
...
AMD Radeon R6 M340DX -4%
AMD Radeon R7 M260X -3%
NVIDIA Quadro K620M -3%
Intel HD Graphics 630 0%
AMD Radeon R7 M445 3%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 8%
Intel UHD Graphics G1 (Ice Lake 32 EU) 16%
...
3DMark - 3DMark Fire Strike Standard Score
min: 779 gem: 1143 mediaan: 1115 (3%) max: 1355 Points
...
AMD Radeon R5 (Bristol Ridge) -8%
AMD Radeon R7 M460 -8%
AMD Radeon R7 M340 2%
AMD Radeon R6 M340DX 2%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 4%
...
3DMark - 3DMark Fire Strike Standard Graphics
min: 722 gem: 1228 mediaan: 1211 (2%) max: 1472 Points
...
AMD Radeon R7 M460 -4%
AMD Radeon R5 (Bristol Ridge) 5%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 6%
...
3DMark - 3DMark Ice Storm Graphics
min: 43334 gem: 63184 mediaan: 68228 (9%) max: 74772 Points
...
NVIDIA GeForce RTX 3050 Laptop GPU -2%
Intel UHD Graphics Xe G4 48EUs -1%
AMD Radeon RX 560X (Laptop) -1%
...
3DMark - 3DMark Night Raid
6929 Points (8%)
Intel UHD Graphics 600 -74%
...
Intel UHD Graphics 615 -57%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -47%
Intel UHD Graphics 617 -46%
Intel UHD Graphics G1 (Ice Lake 32 EU) -16%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -11%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 10%
Intel UHD Graphics Xe G4 48EUs 11%
AMD Radeon RX Vega 10 17%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 18%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) 19%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 57%
AMD Radeon RX Vega 7 79%
...
NVIDIA GeForce RTX 3070 Laptop GPU 651%
3DMark - 3DMark Night Raid Graphics Score
6446 Points (4%)
Intel UHD Graphics 600 -70%
...
Intel UHD Graphics 615 -47%
Intel UHD Graphics 617 -30%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) -26%
Intel UHD Graphics G1 (Ice Lake 32 EU) -2%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 19%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 39%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) 42%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 44%
AMD Radeon RX Vega 10 51%
Intel UHD Graphics Xe G4 48EUs 66%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 77%
...
3DMark 11 - 3DM11 Performance Score
min: 790 gem: 1990 mediaan: 2030 (4%) max: 2326 Points
...
AMD Radeon R7 M260 -2%
Qualcomm Adreno 685 -1%
AMD Radeon R7 (Carrizo) -1%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -1%
AMD Radeon R6 M255DX -1%
...
3DMark 11 - 3DM11 Performance GPU
min: 642 gem: 1742 mediaan: 1789.5 (3%) max: 2025 Points
...
Intel HD Graphics 630 -3%
AMD Radeon R5 (Bristol Ridge) -2%
AMD Radeon R5 (Carrizo) -2%
AMD Radeon R5 M335 2%
Intel UHD Graphics G7 (Lakefield GT2 64 EU) 3%
AMD Radeon R7 (Carrizo) 3%
...
3DMark Vantage + 3DMark Vantage - 3DM Vant. Perf. total
7704 Points (2%)
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -1%
NVIDIA GeForce GTX 460M -1%
AMD Radeon R7 M260X -1%
Intel HD Graphics 630 0%
NVIDIA Quadro K620M 2%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 6%
...
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
6111 Points (5%)
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -2%
AMD Radeon R7 M445 -2%
Intel HD Graphics 630 2%
...
3DMark 06 3DMark 06 - Standard 1280x1024 +
min: 11920 gem: 13425 mediaan: 13216.5 (20%) max: 15020 Points
...
NVIDIA GeForce GTX 460M -2%
AMD Radeon RX Vega 9 0%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 0%
AMD FirePro W4170M 1%
AMD Radeon R9 M385X 4%
...
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 5.7 gem: 6.1 mediaan: 6.1 (3%) max: 6.4 fps
Intel HD Graphics (Cherry Trail) -80%
...
Intel HD Graphics 630 -12%
AMD Radeon R7 M445 9%
AMD Radeon RX Vega 10 16%
AMD FirePro W4190M 20%
...
NVIDIA GeForce RTX 3070 Laptop GPU 2075%
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
18.9 fps (6%)
...
AMD Radeon R6 M340DX -3%
Intel HD Graphics 630 -1%
NVIDIA Quadro K620M 16%
...
SPECviewperf 12 + SPECviewperf 12 - specvp12 sw-03
min: 28.56 gem: 28.8 mediaan: 28.8 (13%) max: 29.03 fps
...
AMD Radeon R7 M260X -7%
AMD Radeon Pro WX 3100 0%
AMD FirePro W4190M 7%
AMD FirePro W5130M 11%
...
NVIDIA Quadro P5200 615%
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
min: 3.14 gem: 3.3 mediaan: 3.3 (1%) max: 3.37 fps
...
...
NVIDIA Quadro P5200 6530%
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
min: 7.98 gem: 8.2 mediaan: 8.2 (3%) max: 8.38 fps
...
AMD Radeon Pro WX 3100 -24%
NVIDIA Quadro K620M -23%
AMD FirePro W4190M -7%
AMD Radeon RX Vega 10 39%
NVIDIA Quadro M520 44%
...
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
min: 2.96 gem: 3.1 mediaan: 3.1 (2%) max: 3.32 fps
...
AMD Radeon Pro WX 3100 23%
AMD Radeon R7 M260X 39%
...
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
min: 14.66 gem: 15.2 mediaan: 15.2 (5%) max: 15.67 fps
...
NVIDIA Quadro K620M -21%
NVIDIA Quadro P500 -7%
AMD FirePro W4190M 9%
NVIDIA Quadro M520 29%
NVIDIA Quadro P520 38%
...
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
min: 0.29 gem: 0.3 mediaan: 0.3 (1%) max: 0.32 fps
...
AMD Radeon Pro WX 3100 -7%
AMD Radeon Pro 555 5%
AMD FirePro W4170M 15%
AMD FirePro W4190M 23%
NVIDIA Quadro K620M 25%
AMD FirePro W5130M 25%
...
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
min: 13.57 gem: 14 mediaan: 14 (8%) max: 14.51 fps
...
AMD Radeon R7 M260X 3%
AMD Radeon RX Vega 10 16%
NVIDIA Quadro K620M 16%
AMD FirePro W4190M 20%
AMD Radeon Pro WX 3100 28%
...
NVIDIA Quadro P5200 1011%
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
min: 15.36 gem: 16 mediaan: 16 (5%) max: 16.61 fps
...
AMD Radeon Pro WX 3100 1%
AMD Radeon R7 M260X 12%
AMD FirePro W4190M 15%
...
NVIDIA Quadro P5200 1105%
specvp12 3dsmax-05 + SPECviewperf 12 - specvp12 3dsmax-05
min: 11.27 gem: 12.6 mediaan: 12.6 (3%) max: 14 fps
NVIDIA Quadro M520 56%
AMD Radeon RX Vega 10 95%
NVIDIA Quadro P520 97%
NVIDIA Quadro M620 97%
AMD Radeon Pro 455 109%
AMD Radeon Pro 555 111%
...
NVIDIA GeForce RTX 3070 Laptop GPU 1743%
SPECviewperf 13 specvp13 sw-04 + SPECviewperf 13 - specvp13 sw-04
min: 35.74 gem: 36.9 mediaan: 36.9 (17%) max: 37.96 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -81%
AMD Radeon RX Vega 10 -54%
AMD Radeon Pro WX 3200 18%
NVIDIA Quadro P520 54%
AMD Radeon RX Vega 7 55%
NVIDIA Quadro M620 62%
...
specvp13 snx-03 + SPECviewperf 13 - specvp13 snx-03
min: 5.64 gem: 5.9 mediaan: 5.9 (1%) max: 6.07 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -52%
...
NVIDIA Quadro P5200 6587%
specvp13 showcase-02 + SPECviewperf 13 - specvp13 showcase-02
min: 7.91 gem: 8.1 mediaan: 8.1 (3%) max: 8.34 fps
AMD Radeon RX Vega 10 18%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 22%
NVIDIA Quadro P520 72%
AMD Radeon RX Vega 7 90%
NVIDIA Quadro M620 99%
...
specvp13 medical-02 + SPECviewperf 13 - specvp13 medical-02
min: 2.13 gem: 2.2 mediaan: 2.2 (1%) max: 2.28 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 95%
NVIDIA Quadro M620 134%
AMD Radeon RX Vega 10 234%
NVIDIA Quadro P600 389%
AMD Radeon Pro WX 3200 423%
...
specvp13 maya-05 + SPECviewperf 13 - specvp13 maya-05
min: 21.35 gem: 22.2 mediaan: 22.2 (4%) max: 23.03 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -10%
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -10%
AMD Radeon RX Vega 10 7%
AMD Radeon Pro WX 3200 68%
NVIDIA Quadro P520 77%
NVIDIA Quadro M620 79%
AMD Radeon RX Vega 7 102%
...
specvp13 energy-02 + SPECviewperf 13 - specvp13 energy-02
0.8 fps (1%)
AMD Radeon RX Vega 10 -28%
NVIDIA Quadro M620 -21%
AMD Radeon RX Vega 7 17%
AMD Radeon RX 5300M 44%
AMD Radeon Pro WX 3200 162%
NVIDIA Quadro P520 251%
NVIDIA Quadro P1000 318%
...
specvp13 creo-02 + SPECviewperf 13 - specvp13 creo-02
min: 17.54 gem: 18.2 mediaan: 18.2 (5%) max: 18.83 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -91%
AMD Radeon RX Vega 10 22%
NVIDIA Quadro M620 96%
AMD Radeon Pro WX 3200 105%
NVIDIA Quadro P520 107%
...
NVIDIA Quadro P5200 1245%
specvp13 catia-05 + SPECviewperf 13 - specvp13 catia-05
min: 21.7 gem: 22.5 mediaan: 22.5 (5%) max: 23.36 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 11%
AMD Radeon RX Vega 10 17%
AMD Radeon Pro WX 3200 73%
NVIDIA Quadro M620 80%
NVIDIA Quadro P520 99%
...
NVIDIA Quadro P5200 1219%
specvp13 3dsmax-06 + SPECviewperf 13 - specvp13 3dsmax-06
min: 14 gem: 14.5 mediaan: 14.5 (4%) max: 14.98 fps
NVIDIA Quadro M620 15%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 28%
AMD Radeon RX Vega 10 70%
NVIDIA Quadro P520 89%
AMD Radeon Pro WX 3200 133%
...
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 6430 gem: 8262 mediaan: 8164 (35%) max: 10037 punten
...
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -4%
AMD Radeon Pro WX 3100 3%
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 42.77 gem: 46.8 mediaan: 46.9 (17%) max: 50.6 fps
...
AMD Radeon RX Vega 9 0%
NVIDIA GeForce GTX 1050 Max-Q 1%
NVIDIA Quadro K620M 5%
...
Cinebench R15 + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 17 gem: 51.7 mediaan: 54.1 (15%) max: 63.1 fps
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -5%
AMD Radeon R9 M280X -2%
Intel HD Graphics 630 1%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) 3%
AMD FirePro W4170M 6%
AMD Radeon RX Vega 9 6%
...
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
min: 97.8 gem: 97.8 mediaan: 97.8 (98%) max: 98 %
...
Intel UHD Graphics G1 (Ice Lake 32 EU) 0%
Intel UHD Graphics 605 0%
Intel UHD Graphics Xe G4 48EUs 0%
Intel HD Graphics 610 0%
Intel UHD Graphics 610 0%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 0%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake) 0%
...
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official Medium Offscreen 1080
105 fps (9%)
Intel UHD Graphics 600 -85%
...
Intel UHD Graphics 605 -78%
Intel UHD Graphics 610 -76%
Intel UHD Graphics Xe G4 48EUs -48%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) -21%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -3%
AMD Radeon R9 M280X 14%
AMD Radeon Pro 560X 71%
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
363 Samples/s (2%)
...
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -6%
AMD Radeon 540X -6%
NVIDIA Quadro P500 -5%
Intel UHD Graphics G1 (Ice Lake 32 EU) -4%
AMD FirePro W5130M -1%
Intel Iris Pro Graphics 580 0%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 5%
...
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
696 Samples/s (1%)
...
AMD FirePro W5130M -10%
Intel HD Graphics 630 -7%
AMD Radeon 540X -4%
NVIDIA Quadro M520 2%
Intel UHD Graphics G1 (Ice Lake 32 EU) 7%
...
ComputeMark v2.1 - ComputeMark v2.1 Result
894 punten (2%)
...
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -11%
Intel UHD Graphics 615 -4%
AMD Radeon R6 M255DX -1%
AMD Radeon R6 (Carrizo) -1%
AMD FirePro W5130M 0%
AMD FirePro W4190M 1%
AMD Radeon RX 550 (Laptop) 3%
AMD FirePro W7170M 3%
NVIDIA GeForce 910M 4%
Intel HD Graphics 630 6%
...
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 35.2 gem: 50.7 mediaan: 54.9 (8%) max: 61.9 Watt
...
NVIDIA Quadro M620 -11%
NVIDIA T500 Laptop GPU -7%
Intel Iris Plus Graphics 650 1%
AMD Radeon Pro 455 11%
NVIDIA Quadro M600M 17%
...
0 10 20 30 40 50 60 70 80 90 100 110 Tooltip Asus Maximus XIII Hero : Ø61.9 (59-116)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
Game Benchmarks De volgende benchmarks zijn afgeleid van onze laptop-testrapporten. De prestaties variëren afhankelijk van het gebruikte grafische geheugen, kloksnelheid, processor, systeeminstellingen, drivers en besturingssysteem. De resultaten zijn daarom niet noodzakelijk representatief voor alle laptops met deze GPU. Voor meer gedetailleerde informatie over de benchmarkresultaten, klik op het fps-aantal.
11.8 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
3.39 fps, P0.1:
4.05 fps, P1:
7.89 fps, max:
72.8 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -3%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 10%
Intel UHD Graphics G1 (Ice Lake 32 EU) 16%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 44%
AMD Radeon RX Vega 10 51%
AMD Radeon RX 550 (Laptop) 75%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 92%
AMD Radeon RX Vega 7 114%
...
NVIDIA GeForce RTX 3080 Laptop GPU 1430%
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
Additional Benchmarks
Low Preset 1920x1080
7.9 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
2.33 fps, P0.1:
2.41 fps, P1:
5.21 fps, max:
65 fps
Your browser does not support the canvas element!
38.5 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
13.2 fps, P0.1:
16.2 fps, P1:
24.3 fps, max:
74.4 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -38%
Intel UHD Graphics G1 (Ice Lake 32 EU) -33%
AMD Radeon RX Vega 10 -24%
Intel UHD Graphics Xe G4 48EUs -14%
AMD Radeon 540X 3%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 5%
AMD Radeon RX Vega 7 25%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 49%
...
16.1 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
9.69 fps, P0.1:
10.5 fps, P1:
11.9 fps, max:
30 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -5%
Intel UHD Graphics G1 (Ice Lake 32 EU) 6%
AMD Radeon RX Vega 10 12%
AMD Radeon 540X 19%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 24%
Intel UHD Graphics Xe G4 48EUs 34%
AMD Radeon RX Vega 7 57%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 65%
...
9.6 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
1.075 fps, P0.1:
1.502 fps, P1:
6.88 fps, max:
26.1 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
NVIDIA GeForce RTX 3050 Laptop GPU 715%
...
» Met alle geteste laptops speelbaar met lage instellingen.
20.7 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
1.589 fps, P0.1:
2.12 fps, P1:
7.07 fps, max:
63.8 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 1%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 6%
Intel UHD Graphics G1 (Ice Lake 32 EU) 24%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 29%
AMD Radeon RX Vega 10 30%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 38%
...
13.2 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
8.35 fps, P0.1:
8.6 fps, P1:
9.62 fps, max:
19.8 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 10 -29%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -11%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -2%
Intel UHD Graphics G1 (Ice Lake 32 EU) 3%
AMD Radeon RX 550 (Laptop) 20%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 35%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 42%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 75%
AMD Radeon 540X 79%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
Additional Benchmarks
Low Preset 1920x1080
14.5 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
8.29 fps, P0.1:
8.57 fps, P1:
10 fps, max:
42.4 fps
Your browser does not support the canvas element!
Intel UHD Graphics G1 (Ice Lake 32 EU) -3%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 4%
AMD Radeon RX 550 (Laptop) 44%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 54%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 79%
Intel UHD Graphics Xe G4 48EUs 93%
AMD Radeon RX Vega 10 94%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 95%
...
Intel UHD Graphics G1 (Ice Lake 32 EU) 4%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 58%
AMD Radeon RX 550 (Laptop) 79%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 86%
AMD Radeon RX Vega 10 98%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 100%
Intel UHD Graphics Xe G4 48EUs 103%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
Additional Benchmarks
Minimum Settings 1920x1080
11.8 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
Your browser does not support the canvas element!
16 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
5.24 fps, P0.1:
5.42 fps, P1:
10.2 fps, max:
58.9 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics G1 (Ice Lake 32 EU) 6%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 14%
AMD Radeon RX Vega 10 56%
Intel UHD Graphics Xe G4 48EUs 57%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 63%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 83%
AMD Radeon 540X 119%
...
NVIDIA GeForce RTX 2070 Super Mobile 875%
5.7 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
1.948 fps, P0.1:
1.965 fps, P1:
3.99 fps, max:
50.4 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics G1 (Ice Lake 32 EU) 6%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 23%
AMD Radeon RX Vega 10 63%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 65%
Intel UHD Graphics Xe G4 48EUs 67%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 71%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 86%
AMD Radeon 540X 88%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
59.1 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
43.8 fps, P0.1:
45.4 fps, P1:
51.2 fps, max:
83.9 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 58%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 61%
AMD Radeon RX Vega 10 68%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 68%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 78%
...
29.8 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
23.2 fps, P0.1:
23.6 fps, P1:
24.5 fps, max:
42.7 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 59%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 85%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 106%
AMD Radeon RX Vega 10 111%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 118%
...
27.5 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
5.03 fps, P0.1:
12.4 fps, P1:
22.7 fps, max:
190 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 10 49%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 55%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 82%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 85%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 101%
AMD Radeon RX Vega 7 189%
...
NVIDIA GeForce RTX 2080 Super Mobile 911%
» Met alle geteste laptops speelbaar met lage instellingen.
31.9 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
3.49 fps, P0.1:
7.2 fps, P1:
11.8 fps, max:
150 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics G1 (Ice Lake 32 EU) 5%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 6%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 27%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 84%
Intel UHD Graphics Xe G4 48EUs 92%
AMD Radeon RX Vega 7 116%
...
7 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
1.281 fps, P0.1:
1.611 fps, P1:
3.09 fps, max:
55.1 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -13%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 6%
Intel UHD Graphics Xe G4 48EUs 71%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 72%
AMD Radeon RX Vega 7 207%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
21.6 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
4.18 fps, P0.1:
4.21 fps, P1:
4.46 fps, max:
147 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 10%
Intel UHD Graphics G1 (Ice Lake 32 EU) 13%
Intel UHD Graphics Xe G4 48EUs 44%
AMD Radeon RX Vega 10 52%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 54%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 64%
AMD Radeon 540X 82%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 108%
...
4.9 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
1.134 fps, P0.1:
1.138 fps, P1:
1.188 fps, max:
124 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
AMD Radeon RX Vega 6 (Ryzen 2000/3000) -3%
Intel UHD Graphics G1 (Ice Lake 32 EU) 22%
AMD Radeon 540X 39%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 43%
Intel UHD Graphics Xe G4 48EUs 83%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 96%
AMD Radeon RX Vega 10 152%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 158%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
13.7 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
3.55 fps, P0.1:
5.92 fps, P1:
11.9 fps, max:
24.9 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics G1 (Ice Lake 32 EU) 10%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 15%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 42%
AMD Radeon RX 550 (Laptop) 62%
AMD Radeon RX Vega 10 77%
Intel UHD Graphics Xe G4 48EUs 80%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 85%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 88%
...
7.8 fps [X] Medion Erazer Beast X20 Intel Core i7-10870H 2.2GHz
UHD Graphics 630
min:
5.62 fps, P0.1:
5.83 fps, P1:
6.44 fps, max:
9.07 fps
Your browser does not support the canvas element! fps
+ Vergelijk
- Verberg vergelijking
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 8%
Intel UHD Graphics G1 (Ice Lake 32 EU) 17%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 39%
AMD Radeon RX 550 (Laptop) 41%
AMD Radeon 540X 85%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 94%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
Intel UHD Graphics 610 -23%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 13%
Intel UHD Graphics G1 (Ice Lake 32 EU) 17%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 96%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 131%
AMD Radeon RX Vega 10 147%
...
Intel UHD Graphics 610 -37%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) 96%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 100%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 125%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 127%
AMD Radeon RX Vega 10 130%
...
» De benchmarkresultaten tonen aan dat de game niet speelbaar is met de geteste instellingen.
Intel UHD Graphics 600 -87%
Intel UHD Graphics 610 -59%
Intel HD Graphics 630 -24%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) 0%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 10%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 48%
AMD Radeon RX Vega 10 55%
Intel UHD Graphics Xe G4 48EUs 56%
...
Intel HD Graphics 630 -24%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -3%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 7%
Deutsch
English
Español
Français
Italiano
Polski
Português
Русский
Türkçe
Svenska
Chinese
Magyar
- Gemiddelde benchmarkresultaten voor deze videokaart
