AMD Ryzen 5 3500U
De AMD Ryzen 5 3500U is een mobile SoC die voorgesteld werd in januari 2019. De chip combineert vier Zen+ cores (8 threads) geklokt aan 2.2 - 3.8 GHz met een Radeon RX Vega 8-GPU met 8 CU's (512 shaders) geklokt aan max. 1200 MHz. Met een TDP van 15 Watt is de SoC vooral bedoeld voor dunne mid-range laptops.
De Picasso-SoC's zijn gebaseerd op de Zen+ microarchitectuur met kleine verbeteringen die moeten leiden tot 3% meer IPC (Instructions per Clock). Het 12-nm-proces laat daarnaast hogere kloksnelheden toe voor een gelijkaardig energieverbruik.
De geïntegreerde dual-channel-geheugencontroller ondersteunt tot DDR4-2400-geheugen. Aangezien de features van de Picasso-APU's hetzelfde zijn als die van de Raven Ridge-voorgangers, verwijzen we naar ons hoofdartikel over Raven Ridge.
Volgens AMD zijn de Picasso-APU's ongeveer 8% sneller dan de voorgangers. De Ryzen 5 3500U zou sneller moeten zijn dan de Ryzen 5 2500U (2 - 3.6 GHz) en bijna even snel als de Ryzen 7 2700U (2.2 - 3.8 GHz).
Serie AMD Picasso (Ryzen 3000 APU) Codenaam Zen+ Serie: Picasso (Ryzen 3000 APU) Zen+ Kloksnelheid 2100 - 3700 MHz Level 1 Cache 384 KB Level 2 Cache 2 MB Level 3 Cache 4 MB Aantal Cores / Threads 4 / 8 Stroomverbruik (TDP = Thermal Design Power) 15 Watt Aantal Transistoren 4500 miljoen Productietechnologie 12 nm Socket AM4 Features XFR, FMA3, SSE 4.2, AVX2, SMT GPU AMD Radeon RX Vega 8 (Ryzen 2000/3000) ( - 1200 MHz)64-Bit 64-Bit-ondersteuning Architecture x86 Aankondigingsdatum 06-01-2019
Benchmarks Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
33.3 pt (39%)
...
AMD Ryzen Embedded V1605B -4%
AMD Ryzen 5 3580U -1%
Intel Core i5-8265U 5%
Intel Core i5-8259U 8%
Intel Core i5-1035G4 8%
Intel Core i5-1035G1 8%
...
Intel Core i9-12900H 100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 317 gem: 354.3 mediaan: 364 (47%) max: 372 Points
...
Intel Core i3-8130U -2%
AMD Ryzen Embedded R1606G -1%
Intel Core i3-8109U -1%
AMD Ryzen 5 3580U -1%
Intel Core i5-6287U 0%
Intel Core i7-6567U 4%
Intel Core i7-7700HQ 4%
Intel Core i5-8259U 7%
Apple M2 8%
...
Intel Core i7-12800H 98%
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 1063 gem: 1436 mediaan: 1477 (6%) max: 1540 Points
...
Intel Core i5-1035G7 -9%
Intel Core i5-1035G1 -2%
Intel Core i5-8259U 1%
Intel Core i7-1065G7 5%
AMD Ryzen 5 3580U 8%
AMD Ryzen 7 3780U 10%
...
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 482 gem: 642 mediaan: 650 (7%) max: 682 Points
...
Intel Core i7-1065G7 1%
AMD Ryzen Embedded V1605B 2%
Intel Core i5-1035G7 3%
Intel Core i7-5850HQ 4%
...
0 35 70 105 140 175 210 245 280 315 350 385 420 455 490 525 560 595 630 665 Tooltip Acer Swift 3 SF314-41G-R491 : Ø411 (394.45-481.96)
Walmart Motile M142 : Ø604 (598.77-639.56)
Lenovo V155-15API : Ø609 (600.38-643.97)
Lenovo Ideapad L340-17API-81LY0004GE : Ø626 (614.9-661.93)
Lenovo ThinkPad E495-20NEA001GE : Ø665 (662.58-667.28)
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 131 gem: 142.4 mediaan: 143 (49%) max: 147 Points
...
Intel Core i5-7267U -1%
Intel Core i5-7260U 0%
Intel Core i7-6700HQ 0%
Intel Core i5-7360U 0%
Intel Core i5-6440HQ 0%
Intel Core i5-6287U 0%
Intel Core i7-6567U 1%
Intel Core i5-8350U 3%
...
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
7.6 Points (14%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 7.62
...
Intel Core i5-8305G -2%
Intel Core i5-1038NG7 -2%
Intel Xeon E3-1535M v6 -2%
Intel Core i7-8705G 0%
Intel Core i7-6820HQ 1%
Intel Core i7-6770HQ 2%
AMD Ryzen 5 3580U 3%
Intel Xeon E3-1505M v5 3%
Intel Core i7-7820HQ 3%
Intel Core i7-6920HQ 4%
...
Intel Core i9-12900HK 333%
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.7 Points (47%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 1.65
...
Intel Core i3-8130U -1%
AMD Ryzen 5 3580U 0%
Intel Core i7-6770HQ 1%
Intel Core i7-6567U 1%
Intel Core i5-8350U 1%
Intel Core i5-7360U 3%
Intel Core i7-6820HQ 4%
...
Intel Core i9-12900H 100%
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4542 gem: 4556 mediaan: 4557.5 (41%) max: 4565 punten
Model CPU GPU RAM waarde Lenovo Ideapad C340-14API 81N6004UGE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 4542 Acer Swift 3 SF314-41G-R491 R5 3500U Radeon 540X 1095 / 1000 MHz 2 GB 8 GB 4555 Acer Swift 3 SF314-41-R8HZ R5 3500U Vega 8 1200 / 1299 MHz 2.9 GB 8 GB 4560 Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 4565
...
Intel Core i5-6260U -2%
Intel Core i5-6198DU -1%
AMD Ryzen 5 3580U -1%
Intel Core i7-2860QM 0%
Intel Core i5-4310M 2%
Intel Core i5-6300U 3%
...
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 13249 gem: 16322 mediaan: 17230.5 (24%) max: 17578 punten
Model CPU GPU RAM waarde Acer Swift 3 SF314-41G-R491 R5 3500U Radeon 540X 1095 / 1000 MHz 2 GB 8 GB 13249 Acer Swift 3 SF314-41-R8HZ R5 3500U Vega 8 1200 / 1299 MHz 2.9 GB 8 GB 16980 Lenovo Ideapad C340-14API 81N6004UGE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 17481 Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 17578
...
Intel Core i5-6300HQ 1%
Intel Core i7-2860QM 3%
Intel Core i5-6440HQ 5%
...
Intel Core i9-12900H 271%
wPrime 2.10 - wPrime 2.0 1024m *
368.2 s (4%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 368.2
...
Intel Xeon E3-1535M v6 -7%
Intel Core i5-1038NG7 -4%
Intel Core i5-6440HQ -1%
Intel Core i5-6300HQ 3%
AMD Ryzen 5 PRO 2500U 5%
Intel Core i5-8265U 9%
AMD Ryzen 3 3300U 10%
AMD A12-9720P 13%
...
VIA C3-M C3-M-1200 2198%
wPrime 2.10 - wPrime 2.0 32m *
12.9 s (3%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 12.88
...
Intel Core i5-1038NG7 -13%
Intel Core i5-6440HQ -11%
AMD Ryzen 3 3300U -7%
Intel Core i5-6300HQ -6%
AMD Ryzen 5 PRO 2500U -4%
Intel Core i7-7660U 0%
AMD A12-9720P 1%
Intel Core i3-8145U 2%
AMD PRO A12-9800B 7%
Intel Core i7-6567U 8%
...
Transmeta Crusoe TM-5800 3759%
2455 punten (14%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 2455
AMD Athlon Neo MV-40 -86%
...
Intel Core i5-4210H -2%
Intel Core i5-5250U -1%
Intel Core i5-6198DU -1%
Intel Core i7-6600U 0%
Intel Core i5-6260U 0%
Intel Core i7-8500Y 1%
...
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
min: 15825 gem: 16929 mediaan: 17024.5 (12%) max: 17508 MIPS
...
Intel Core i5-1035G1 -6%
Intel Core i5-8265U -4%
Intel Core i7-2860QM -3%
AMD Ryzen Embedded V1605B -1%
Intel Core i7-1065G7 1%
Intel Core i5-1035G7 1%
...
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
min: 3502 gem: 3541 mediaan: 3538 (51%) max: 3580 MIPS
...
AMD Ryzen Embedded R1606G 0%
AMD Ryzen 5 3580U 1%
Intel Core i5-1035G4 3%
Intel Core i7-6567U 5%
Intel Core i5-6287U 6%
...
X264 HD Benchmark 4.0 - x264 Pass 2
39.2 fps (18%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 39.2
AMD Athlon Neo MV-40 -95%
...
Intel Core i5-8350U -5%
Intel Core i5-1035G7 -3%
Intel Core i5-8259U -2%
Intel Core i7-8650U 0%
Intel Xeon E3-1535M v6 1%
AMD Ryzen 5 3580U 2%
...
Intel Core i9-12900HK 307%
X264 HD Benchmark 4.0 - x264 Pass 1
134.8 fps (37%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 134.8
...
Intel Core i5-7300U -5%
Intel Core i7-6567U -4%
Intel Core i7-2860QM -2%
AMD Ryzen 3 3300U -2%
AMD Ryzen 5 3580U 0%
Intel Core i7-7660U 1%
...
Intel Core i9-12900HK 123%
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
min: 3.35 gem: 3.9 mediaan: 4 (9%) max: 4.15 fps
...
Intel Core i7-6567U -20%
AMD Ryzen Embedded V1605B -8%
AMD Ryzen 5 3580U 4%
Intel Core i5-8265U 6%
Intel Core i5-1035G4 7%
...
0 1 2 3 4 5 6 7 Tooltip Lenovo ThinkPad E495-20NEA001GE : Ø4.2 (0.55-7.53)
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (15%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 0.443
...
Intel Core i7-8706G -5%
Intel Core i7-8650U -3%
Intel Xeon E3-1535M v5 -3%
Intel Core i7-6920HQ -2%
Intel Core i5-1035G4 -2%
Intel Core i5-1035G7 -2%
Intel Core i7-7820HQ -1%
Intel Core i7-8705G 1%
Intel Core i5-8265U 2%
Intel Xeon E3-1505M v6 2%
Intel Core i7-1065G7 3%
...
Intel Core i9-12900HK 239%
TrueCrypt - TrueCrypt Twofish
0.7 GB/s (14%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 0.672
...
Intel Core i5-1035G1 -3%
Intel Core i7-7820HQ -2%
Intel Core i7-6820HK 0%
Intel Core i7-6770HQ 0%
Intel Core i7-7700HQ 1%
Intel Core i7-6820HQ 1%
Intel Core i5-8350U 2%
Intel Core i7-8706G 5%
...
Intel Core i9-12900HK 287%
TrueCrypt - TrueCrypt AES
4.4 GB/s (16%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 4.4
...
Intel Core i7-7820HQ -5%
Intel Core i5-1035G1 -5%
Intel Core i7-6920HQ -5%
Intel Core i7-8650U -4%
Intel Core i5-8265U -2%
Intel Xeon E3-1505M v6 0%
Intel Core i7-8705G 5%
Intel Xeon E3-1535M v6 7%
Intel Core i5-1035G4 7%
...
Intel Core i9-12900HK 270%
Blender - Blender 2.79 BMW27 CPU *
min: 680 gem: 704 mediaan: 694 (5%) max: 796 Seconds
Intel Core i5-1038NG7 -99%
...
Intel Core i7-7700HQ -10%
Intel Core i7-8559U -5%
Intel Core i7-6700HQ -4%
Intel Core i5-8350U 0%
AMD Ryzen 5 3580U 1%
Intel Core i5-8259U 5%
...
R Benchmark 2.5 - R Benchmark 2.5 *
min: 0.734 gem: 0.7 mediaan: 0.7 (16%) max: 0.804 sec
...
Intel Core i5-8265U -3%
Apple M1 -2%
Intel Core i7-7700HQ -2%
Intel Core i5-1035G1 -2%
Intel Core i5-1035G4 2%
Intel Core i5-8259U 3%
Intel Core i5-6287U 3%
AMD Ryzen 3 3300U 3%
...
3DMark 06 - CPU - 3DMark 06 - CPU
min: 5044 gem: 5951 mediaan: 5950.5 (13%) max: 6857 Points
Model CPU GPU RAM waarde Acer Swift 3 SF314-41G-R491 R5 3500U Radeon 540X 1095 / 1000 MHz 2 GB 8 GB 5044 Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 6857
...
Intel Core i5-6300HQ -3%
Intel Core i5-6440HQ 1%
Intel Core i5-8350U 3%
Intel Core i7-2860QM 6%
Intel Core i5-8265U 6%
...
Intel Core i9-12900HK 182%
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12 s (3%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 12
Intel Core i7-11390H -44%
...
Intel Core i7-6650U -2%
Intel Core i5-6300HQ -2%
Intel Core i7-6560U -2%
Intel Core i5-7300U 0%
AMD Ryzen 5 3580U 0%
Intel Core i5-7267U 1%
Intel Core i7-5600U 2%
Intel Core i5-6360U 3%
...
VIA C3-M C3-M-1200 3758%
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
27.8 s (1%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 27.81
Intel Core i7-11390H -48%
...
Intel Core i7-5557U -3%
AMD Ryzen 5 3580U -2%
Intel Core i5-7267U 0%
Intel Core i7-5600U 0%
Intel Core i5-6360U 0%
Intel Core i3-7020U 1%
Intel Core i7-6500U 1%
Intel Core i5-7200U 1%
Intel Core i5-5257U 2%
...
Intel Celeron Dual-Core T1400 8314%
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
697 s (3%)
Model CPU GPU RAM waarde Lenovo Ideapad L340-17API-81LY0004GE R5 3500U Vega 8 1200 / 1200 MHz 2 GB 8 GB 697
...
Intel Core i5-6300U -2%
AMD Ryzen 5 3580U 0%
Intel Core i5-4310U 0%
Intel Core i5-6200U 0%
Intel Core i5-5300U 0%
Intel Core i3-7020U 1%
AMD Ryzen 3 3300U 2%
...
VIA C3-M C3-M-1200 3130%
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
18229 Points (19%)
Model CPU GPU RAM waarde Acer Swift 3 SF314-41G-R491 R5 3500U Radeon 540X 1095 / 1000 MHz 2 GB 8 GB 18229
...
Intel Core i5-6300HQ -4%
Intel Core i5-1035G1 1%
Intel Core i5-6440HQ 2%
Intel Core i7-8650U 5%
Intel Core i5-2537M 10%
...
Intel Core i9-12900HK 325%
3DMark 11 - 3DM11 Performance Physics
min: 5213 gem: 6267 mediaan: 6402.5 (22%) max: 6967 Points
...
AMD Ryzen 5 PRO 2500U -6%
Intel Core i5-6440HQ -5%
Intel Core i5-8350U -4%
Intel Core i5-6300HQ -2%
Intel Core i5-8265U 1%
...
3DMark - 3DMark Ice Storm Physics
min: 29562 gem: 32942 mediaan: 30254 (19%) max: 48997 Points
