Intel Core m7-6Y75
De Intel Core m7-6Y75 is een erg energie-efficiënte dual-core-SoC voor notebooks gebaseerd op de Skylake-architectuur en werd gelanceerd in september 2015. Dankzij zijn extreem lage TDP kan de CPU toegepast worden in passief gekoelde tablets en 2-in-1-notebooks. Naast de twee CPU-cores met Hyper-Threading geklokt aan 1.2 - 3.1 GHz (2 cores: max. 2.9 GHz), integreert de chip ook een HD Graphics 515 GPU en een dual-channel DDR4-2133/DDR3L-1600 geheugencontroller. De CPU is gefabriceerd via een 14-nm-proces met FinFET-transistors.
Skylake vervangt zowel Haswell als Broadwell en brengt dezelfde microarchitectuur naar elke TDP-klasse van 4.5 tot 45 Watt. De uitgebreide verbeteringen van Skylake zijn onder meer de vergrote out-of-order-buffers, geoptimaliseerde prefetching en aftakkingsvoorspelling en bijkomende prestatiewinsten door Hyper-Threading. Al bij al werd de performance in verhouding tot de kloksnelheid met slechts 5 tot 10 procent verbeterd ten opzichte van Haswell en met minder dan 5 procent in vergelijking met Broadwell, wat redelijk bescheiden is voor een nieuwe architectuur ('Tock').
De eigenlijke prestaties van de Core m7-6Y75 hangt sterk af van de koelcapaciteit en de TDP-configuratie van het toestel in kwestie. Terwijl de CPU vergelijkbaar kan zijn met een Core i5-6300U (Skylake, 15 Watt) in korte benchmarks, lopen zijn prestaties achter op een Core i3-6100U onder aanhoudende belasting. Al bij al biedt de chip voldoende rekenkracht voor office- en multimedia-doeleinden evenals voor iets meer veeleisende applicaties.
De geïntegreerde grafische kaart, HD Graphics 515 genaamd, vertegenwoordigt de 'GT2'-versie van de Skylake-GPU (Intel Gen. 9). De 24 Execution Units, ook EU's genoemd, zijn geklokt aan 300 - 1000 (beperkt door de TDP-reserve) en bieden prestaties van ongeveer hetzelfde niveau als de oudere HD Graphics 4400 (Haswell, 15 Watt). Games van 2015 zijn dus vloeiend speelbaar in de laagste instellingen. Voor meer informatie over prestaties en features kan je onze pagina voor de HD Graphics 515 raadplegen.
Met een TDP van 4.5 Watt (inclusief CPU, GPU en geheugencontroller) is de CPU geschikt voor passief gekoelde notebooks en tablets. Het TDP kan indien gewenst verlaagd worden tot 3.5 Watt (cTDP up) of verhoogd tot 7 Watt (cTDP up), wat zowel de warmteontwikkeling als de prestaties vermindert.
Serie Intel Core m7 Codenaam Skylake Kloksnelheid 1200 - 3100 MHz Level 1 Cache 128 KB Level 2 Cache 512 KB Level 3 Cache 4 MB Aantal Cores / Threads 2 / 4 Stroomverbruik (TDP = Thermal Design Power) 4.5 Watt Productietechnologie 14 nm Chipgrootte 99 mm2 Max. Temperatuur 100 °C Socket BGA Features Dual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT GPU Intel HD Graphics 515 (300 - 1000 MHz)64-Bit 64-Bit-ondersteuning Architecture x86 Startprijs $393 U.S. Aankondigingsdatum 01-09-2015 Productlink (extern) Intel Core m7 6Y75
Benchmarks Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 172 gem: 213.4 mediaan: 205 (2%) max: 283 Points
...
AMD PRO A8-9600B -5%
Intel Celeron N4100 -4%
Intel Core i3-5005U -3%
AMD A10-9600P -1%
Intel Core i3-5015U 0%
Intel Core m5-6Y54 1%
Intel Core i3-5010U 2%
AMD PRO A12-9800B 6%
...
Intel Core i7-12800HX 1485%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 80 gem: 102.8 mediaan: 102 (31%) max: 119 Points
...
Intel Core i3-6157U -4%
Intel Core m5-6Y54 -3%
Intel Core i5-5250U -2%
Intel Core m5-6Y57 -1%
Intel Core i5-4310U 4%
Intel Core i3-6100H 5%
...
Intel Core i9-12900HX 170%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.94 gem: 2.5 mediaan: 2.5 (3%) max: 3.25 Points
...
AMD PRO A8-9600B -2%
Intel Celeron N4100 -2%
Intel Core i5-7Y54 -1%
Intel Core i5-2415M -1%
Intel Core i3-5157U 0%
Intel Core i7-8500Y 2%
AMD Phenom II X4 N970 2%
...
Intel Core i9-12900HX 1596%
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.94 gem: 1.1 mediaan: 1.1 (3%) max: 1.37 Points
...
Intel Core i3-6100U -1%
Intel Core m5-6Y57 1%
Intel Core i5-5250U 3%
Intel Core i3-5157U 4%
...
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3817 gem: 4021 mediaan: 3854 (31%) max: 4553 punten
...
Intel Core i5-2520M -2%
Intel Core i5-5250U 2%
...
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4611 gem: 6176 mediaan: 6302 (7%) max: 7473 punten
...
Intel Celeron N4100 -3%
AMD A8-3510MX 0%
Intel Core i3-2310M 0%
Intel Core i3-370M 1%
Intel Core i7-2657M 1%
Intel Celeron 2970M 1%
...
Intel Core i9-12900HX 946%
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
8461 Points (6%)
...
AMD Phenom II X4 N970 -1%
...
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
5022 Points (27%)
...
Intel Core m5-6Y57 -3%
Intel Core m5-6Y54 -2%
Intel Core i3-5157U 2%
...
wPrime 2.10 - wPrime 2.0 1024m *
698 s (8%)
...
Intel Core i5-4310U -3%
Intel Pentium N3540 -1%
AMD A6-3410MX -1%
AMD A8-3520M 0%
AMD Phenom II X4 P960 1%
Intel Pentium N3700 3%
...
VIA C3-M C3-M-1200 1112%
wPrime 2.10 - wPrime 2.0 32m *
19 s (4%)
...
AMD Pro A8-8600B -1%
Intel Core i5-4310U 2%
Intel Core i5-5250U 3%
...
Transmeta Crusoe TM-5800 2516%
wPrime 1.55 - wPrime 1.55 1024m *
817 s (3%)
...
Intel Core i7-8650U -49%
Intel Core i5-7200U -43%
Intel Core i5-7Y54 -9%
AMD A6-7310 -7%
Intel Core i5-7Y57 29%
Intel Core Duo L2500 72%
Intel Pentium Dual Core T2080 91%
AMD Mobile Sempron SI-40 207%
...
Intel Celeron M 373 3042%
wPrime 1.55 - wPrime 1.55 32m *
19.7 s (10%)
...
Intel Core i7-8650U -48%
Intel Core i5-7200U -24%
Intel Core i5-7Y54 12%
AMD A6-7310 20%
AMD Phenom II X3 N850 21%
AMD Phenom II X2 X640 BE 25%
...
Intel Pentium M 713 864%
min: 1319 gem: 1624 mediaan: 1624.5 (9%) max: 1928 punten
...
AMD A10-9600P -6%
Intel Core M-5Y31 7%
...
X264 HD Benchmark 4.0 - x264 Pass 2
min: 11.32 gem: 15.3 mediaan: 15.5 (6%) max: 19.13 fps
AMD Athlon Neo MV-40 -87%
...
Intel Core i3-7020U 2%
...
Intel Core i9-12900HX 1111%
X264 HD Benchmark 4.0 - x264 Pass 1
min: 61.3 gem: 86.3 mediaan: 89 (21%) max: 108.7 fps
...
Intel Core i3-6100U -3%
AMD A10-9600P -1%
Intel Core i5-4310U 1%
Intel Core i5-5300U 2%
Intel Core i5-5250U 3%
...
Intel Core i9-12900HX 263%
TrueCrypt - TrueCrypt Serpent
min: 0.115 gem: 0.2 mediaan: 0.2 (0%) max: 0.182 GB/s
...
Intel Core m5-6Y57 -7%
Intel Core i5-5300U -6%
Intel Celeron N4100 -2%
AMD A6-7310 2%
Intel Core i5-6260U 2%
AMD Pro A8-8600B 3%
Intel Core i5-6198DU 4%
...
Intel Core i9-12900HX 949%
TrueCrypt - TrueCrypt Twofish
min: 0.186 gem: 0.3 mediaan: 0.3 (0%) max: 0.311 GB/s
...
AMD Pro A8-8600B 2%
Intel Core i5-6260U 5%
...
Intel Core i9-12900HX 1084%
TrueCrypt - TrueCrypt AES
min: 1.1 gem: 1.6 mediaan: 1.7 (0%) max: 1.8 GB/s
...
Intel Core m5-6Y57 -5%
Intel Core i5-5250U -5%
Intel Core m5-6Y54 -5%
Intel Core i5-5300U -1%
Intel Core i7-2640M 2%
Intel Core i5-4310U 2%
Intel Core i3-7130U 8%
...
Intel Core i9-12900HX 1005%
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2575 gem: 2854 mediaan: 2730 (6%) max: 3302 Points
...
AMD Pro A10-8700B -2%
Intel Core i3-5010U -1%
Intel Core i3-5015U 0%
Intel Core i5-2415M 1%
Intel Core i5-7Y54 2%
...
Intel Core i9-12900HX 519%
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 12 gem: 12.3 mediaan: 12 (3%) max: 12.83 s
AMD Ryzen 7 PRO 6850H -92%
...
Intel Core i5-7300U -2%
AMD Ryzen 5 3580U -2%
Intel Core i5-7267U -1%
Intel Core i7-5600U -1%
Intel Core i5-6360U 0%
Intel Core i5-7200U 0%
Intel Core i7-6500U 1%
Intel Core i5-2520M 1%
Intel Core i5-5257U 1%
...
VIA C3-M C3-M-1200 3670%
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 27 gem: 28.9 mediaan: 29 (1%) max: 30.77 s
Intel Core i7-11390H -50%
...
Intel Core i3-7100H -1%
Intel Core i5-2520M 0%
Intel Core i5-6300U 1%
Intel Core i5-6260U 1%
AMD Ryzen 5 PRO 2500U 1%
...
Intel Celeron Dual-Core T1400 7991%
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 640 gem: 865 mediaan: 707 (3%) max: 1248 s
...
Intel Core i3-6100U -2%
Intel Celeron 2970M -2%
...
VIA C3-M C3-M-1200 2503%
3DMark 11 - 3DM11 Performance Physics
min: 1547 gem: 2613 mediaan: 2678.5 (7%) max: 3360 Points
...
Intel Core m5-6Y54 -3%
Intel Core i5-4302Y -1%
Intel Core i3-5015U 4%
...
Intel Core i7-12800HX 756%
3DMark - 3DMark Ice Storm Physics
min: 18687 gem: 26970 mediaan: 26679 (17%) max: 36128 Points
...
Intel Core i7-2640M -1%
Intel Core i3-5005U -1%
Intel Core m5-6Y54 -1%
Intel Core i5-7Y54 -1%
Intel Core i3-5015U 1%
Intel Core i5-1038NG7 2%
Intel Core i5-4310U 2%
...
Intel Core i5-4300Y 477%
3DMark - 3DMark Ice Storm Extreme Physics
min: 18563 gem: 21750 mediaan: 21738 (18%) max: 24950 Points
...
Intel Core i3-7100U -11%
Intel Celeron N4100 -7%
AMD A10-9600P -1%
Intel Core i5-8279U -1%
Intel Core m5-6Y54 1%
AMD PRO A8-9600B 8%
...
Intel Core i9-12900HX 368%
3DMark - 3DMark Ice Storm Unlimited Physics
min: 28359 gem: 31316 mediaan: 31316 (26%) max: 34273 Points
...
Intel Core m5-6Y54 -7%
Intel Core i3-5005U -6%
AMD Ryzen 5 PRO 2500U -6%
Intel Core i5-1038NG7 -5%
Intel Core i5-7Y54 2%
Intel Core i5-8259U 8%
...
Intel Core i9-12900HX 216%
3DMark - 3DMark Cloud Gate Physics
min: 1001 gem: 2145 mediaan: 2187 (6%) max: 2987 Points
...
AMD PRO A8-9600B -3%
AMD A8-7410 -3%
Intel Core M-5Y31 -1%
Intel Pentium 3825U 3%
Intel Core i5-8210Y 5%
...
Intel Core i9-12950HX 963%
3DMark - 3DMark Fire Strike Standard Physics
min: 1387 gem: 3003 mediaan: 3059 (6%) max: 4221 Points
...
AMD A10-9600P -3%
Intel Celeron N4100 -2%
AMD PRO A12-9800B 0%
AMD A8-7410 0%
Intel Core M-5Y31 0%
Intel Core i5-8210Y 4%
Intel Pentium 3825U 4%
Intel Core m5-6Y54 5%
...
Intel Core i7-12800HX 1047%
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 4078 gem: 5362 mediaan: 5457 (10%) max: 6454 punten
...
Intel Celeron N4100 -6%
Intel Core i3-7100U -4%
Intel Core i5-5250U -3%
Intel Core m5-6Y57 -2%
AMD PRO A12-9800B -1%
AMD A10-9600P 0%
Intel Core m5-6Y54 1%
Intel Core i5-5300U 2%
Intel Core i7-8500Y 5%
...
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 2492 gem: 2800 mediaan: 2754.5 (54%) max: 3199 punten
...
Intel Core i5-5300U -4%
Intel Core i5-6200U -3%
Intel Core m5-6Y54 -2%
Intel Core i3-7130U 1%
Intel Core i5-6300U 3%
Intel Core i5-6440HQ 3%
Intel Core i5-4210H 5%
...
Intel Core i5-1230U 83%
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
min: 4295 gem: 5445 mediaan: 5270 (8%) max: 6769 punten
...
Intel Core i3-7020U -9%
AMD PRO A8-9600B -8%
Intel Core i5-7Y54 -3%
Intel Celeron N4100 1%
Intel Core m5-6Y54 2%
AMD PRO A12-9800B 2%
Intel Core m5-6Y57 3%
AMD A10-9600P 5%
...
Intel Core i5-1230U 348%
Geekbench 3 - Geekbench 3 64 Bit Single-Core
min: 2626 gem: 2901 mediaan: 2732 (41%) max: 3346 punten
...
Intel Core m5-6Y54 -4%
Intel Core m5-6Y57 -4%
Intel Core i5-6200U -3%
Intel Core i5-7Y54 2%
Intel Core i3-7130U 2%
Intel Core i5-6440HQ 4%
Intel Core i5-7200U 8%
Intel Core i7-6500U 8%
Intel Core i5-6198DU 9%
Intel Core i5-6260U 10%
...
Intel Core i5-1230U 101%
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1126 gem: 1429 mediaan: 1195 (1%) max: 2238 ms
...
Intel Core i5-6267U -7%
Intel Core i7-2860QM -6%
Microsoft SQ1 -1%
AMD 3015Ce -1%
Intel Core i3-8130U 1%
Qualcomm Snapdragon 8cx 2%
AMD Ryzen 5 PRO 2500U 4%
Intel Core i7-8500Y 5%
Intel Core i5-6200U 7%
Intel Core i3-7100U 7%
...
Sunspider - Sunspider 1.0 Total Score *
min: 81.8 gem: 94.4 mediaan: 82.8 (1%) max: 138.7 ms
...
Intel Core i5-6267U -4%
Intel Core i5-6440HQ -4%
Intel Xeon W-2145 -4%
Intel Core i5-8265U -1%
Intel Core i3-6100H 0%
Intel Core m5-6Y54 2%
Intel Core i7-4712HQ 4%
...
Octane V2 - Octane V2 Total Score
min: 15298 gem: 23814 mediaan: 22962 (24%) max: 30999 Points
...
AMD 3015Ce -2%
Intel Core i3-7100U 1%
AMD Ryzen 5 PRO 2500U 2%
Intel Core i7-8500Y 2%
Intel Core i5-5257U 5%
...
Intel Core i9-12900HX 300%
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
v1.22
log 22. 07:36:32
#0 no ids found in url (should be separated by "_") +0s ... 0s
#1 not redirecting to Ajax server +0s ... 0s
#2 did not recreate cache, as it is less than 5 days old! Created at Fri, 20 Jan 2023 08:57:08 +0100 +0.001s ... 0.001s
#3 composed specs +0.006s ... 0.008s
#4 did output specs +0s ... 0.008s
#5 getting avg benchmarks for device 6964 +0.002s ... 0.009s
#6 got single benchmarks 6964 +0.03s ... 0.039s
#7 got avg benchmarks for devices +0s ... 0.039s
#8 min, max, avg, median took s +0.441s ... 0.48s
#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.48s
#10 return log +0s ... 0.48s
Testrapporten voor de Intel Core m7-6Y75 processor
Lenovo ThinkPad X1 Tablet Review Surface-potentieel… Lenovo’s eerste ThinkPad in de stijl van de Surface heeft heel wat goede ideeën. Slaagt het toestel er ook in deze te verenigen in een samen...
Intel Core m7-6Y75 | Intel HD Graphics 515 | 12.00" | 1 kg
Kort testrapport Dell XPS 12 9250 4K Convertible 4K voor onderweg Dell wil stappen maken in de convertible sector door de nieuwe standaard te zetten met de nieuwe 2-in-2 XPS 12 9250. Een 4K paneel, 512 GB SSD ...
Intel Core m7-6Y75 | Intel HD Graphics 515 | 12.50" | 1.3 kg
Kort testrapport HP Spectre x2 12-a003ng (K3D42EA) Notebook All-in-one PC? We hebben het hier niet over een zware laptop, maar een 850 gram zware tablet die de functionaliteiten van een volledige PC probeert te emuleren....
Intel Core m7-6Y75 | Intel HD Graphics 515 | 12.00" | 1.2 kg
HP EliteBook 1030 G1-Z2U93ES : Intel HD Graphics 515, 13.30", 1.2 kg
Extern testrapport » HP EliteBook 1030 G1-Z2U93ES
Dell Latitude 13 7370, Core m7 : Intel HD Graphics 515, 13.30", 1.3 kg
Extern testrapport » Dell Latitude 13 7370, Core m7
Lenovo ThinkPad X1 Tablet : Intel HD Graphics 515, 12.00", 1 kg
Extern testrapport » Lenovo ThinkPad X1 Tablet
HP EliteBook Folio G1-Z2U98ES : Intel HD Graphics 515, 12.50", 1 kg
Extern testrapport » HP EliteBook Folio G1-Z2U98ES
Toshiba Portege Z20t-C-144 : Intel HD Graphics 515, 12.50", 1.5 kg
Extern testrapport » Toshiba Portege Z20t-C-144
Asus ZenBook UX360CA-DQ099T : Intel HD Graphics 515, 13.30", 1.3 kg
Extern testrapport » Asus ZenBook UX360CA-DQ099T
Lenovo Yoga 900S-12ISK-80ML0068PB : Intel HD Graphics 515, 12.50", 1 kg
Extern testrapport » Lenovo Yoga 900S-12ISK-80ML0068PB
Asus ZenBook UX360CA-C4112TS : Intel HD Graphics 515, 13.30", 1.3 kg
Extern testrapport » Asus ZenBook UX360CA-C4112TS
HP EliteBook 1030 G1-X2F03EA : Intel HD Graphics 515, 13.30", 1.2 kg
Extern testrapport » HP EliteBook 1030 G1-X2F03EA
HP EliteBook Folio G1-X2F49EA : Intel HD Graphics 515, 12.50", 1 kg
Extern testrapport » HP EliteBook Folio G1-X2F49EA
HP EliteBook Folio G1-W8H05PA : Intel HD Graphics 515, 12.50", 1 kg
Extern testrapport » HP EliteBook Folio G1-W8H05PA
HP Spectre x2 12-a003ng K3D42EA : Intel HD Graphics 515, 12.00", 1.2 kg
Extern testrapport » HP Spectre x2 12-a003ng K3D42EA
Toshiba Portege Z20t-C-121 : Intel HD Graphics 515, 12.50", 1.5 kg
Extern testrapport » Toshiba Portege Z20t-C-121
Asus Zenbook UX305CA-FB219T : Intel HD Graphics 515, 13.30", 1.2 kg
Extern testrapport » Asus Zenbook UX305CA-FB219T
Lenovo Ideapad Miix 700-80QL00BUGE : Intel HD Graphics 515, 12.10", 0.8 kg
Extern testrapport » Lenovo Ideapad Miix 700-80QL00BUGE
Lenovo Yoga 900S-12ISK-80ML001XGE : Intel HD Graphics 515, 12.50", 1 kg
Extern testrapport » Lenovo Yoga 900S-12ISK-80ML001XGE
Asus Transformer Book T302CA : Intel HD Graphics 515, 12.50", 0.8 kg
Extern testrapport » Asus Transformer Book T302CA
Toshiba Portege Z20t-C-121 : Intel HD Graphics 515, 12.50", 1.6 kg
Extern testrapport » Toshiba Portege Z20t-C-121
Dell XPS 12 9250 4K : Intel HD Graphics 515, 12.50", 1.3 kg
Extern testrapport » Dell XPS 12 9250 4K
HP EliteBook Folio G1-V1C36EA : Intel HD Graphics 515, 12.50", 1.1 kg
Extern testrapport » HP EliteBook Folio G1-V1C36EA
Lenovo ThinkPad X1 Tablet : Intel HD Graphics 515, 12.10", 1 kg
Extern testrapport » Lenovo ThinkPad X1 Tablet
Apple MacBook 12 (Early 2016) 1.3 GHz : Intel HD Graphics 515, 12.00", 0.9 kg
Extern testrapport » Apple MacBook 12 (Early 2016) 1.3 GHz
Dell Latitude 12 E7275 : Intel HD Graphics 515, 12.50", 1.4 kg
Extern testrapport » Dell Latitude 12 E7275
Dell XPS 12-9250 : Intel HD Graphics 515, 12.50", 1.3 kg
Extern testrapport » Dell XPS 12-9250
HP Spectre x2 12-a002dx : Intel HD Graphics 515, 12.10", 1.2 kg
Extern testrapport » HP Spectre x2 12-a002dx
Asus UX305CA-FB055T : Intel HD Graphics 515, 13.30", 1.2 kg
Extern testrapport » Asus UX305CA-FB055T
Please share our article, every link counts!
.170
Andere CPU's van de serie Core m7 Omringende CPU's + AMD A10-9620P 4x 2.5 GHz - 3.4 GHz
+ Intel Celeron 3965U 2x 2.2 GHz
+ Intel Core i5-4402E 2x 1.6 GHz - 2.7 GHz
- Intel Core i3-5020U 2x 2.2 GHz
- Intel Core i3-7020U 2x 2.3 GHz
Klaus Hinum (Update: 2015-12- 9)
