Intel Core i7-3540M

Intel 3540M

De Intel Core i7-3540M is de snelste dual-core processor voor laptops (bij het moment van introductie in het eerste kwartaal van 2013), gebaseerd op de Ivy Bridge architectuur. Dankzij Hyperthreading kunnen de twee cores tegelijk tot en met vier threads in parallel aan, wat resulteert in efficiënter gebruik van de CPU. Elke core biedt een basiskloksnelheid van 3.0 GHz maar kan met Turbo Boost dynamisch overklokken tot 3.5 GHz (voor 2 actieve cores) en 3.7 GHz (voor 1 actieve core). Net als zijn Sandy Bridge-gebaseerde voorganger Core i7-2640M, beschikt hij over een L3-Cache van 4 MB.

Ivy Bridge is een die shrink van de Sandy Bridge architectuur met verbeterde prestaties voor zowel GPU en CPU. De CPU's zijn gefabriceerd in 22nm (tegenover 32nm voor Sandy Bridge CPU's) en gebruiken voor het eerst 3D-transistoren voor een betere energie-efficiëntie vergeleken met vergelijkbaar geklokte Sandy Bridge processors. Andere nieuwe functionaliteiten zijn geïntegreerde PCI Express 3.0 en ondersteuning voor DDR3(L)-1600.

De prestaties van de Core i7-3540M liggen iets boven die van een vergelijkbaar geklokte Sandy Bridge processor dankzij de kleine verbeteringen in architectuur. Bijgevolg is de globale performance zo'n 5 - 10 % beter dan die van de oude i7-2640M.

De geïntegreerde Intel HD Graphics 4000 biedt 16 Execution Units (EU's) geklokt aan 650 MHz tot 1300 MHz met Turbo Boost, wat het tot een van de snellere varianten maakt.

Zoals de meeste andere Ivy Bridge dual-cores is de i7-3540M afgestemd op een TDP van 35W. Daarom kunnen zelfs kleinere laptops de Core i7 gebruiken.

SerieIntel Core i7
CodenaamIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M « 3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Kloksnelheid3000 - 3700 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Aantal Cores / Threads2 / 4
Stroomverbruik (TDP = Thermal Design Power)35 Watt
Productietechnologie22 nm
Max. Temperatuur105 °C
SocketBGA1023, PGA988
FeaturesHD Graphics 4000 (650 - 1300 MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1300 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum01-01-2013
Productlink (extern)Intel Core i7 3540M

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.41     gem: 3.5     mediaan: 3.5 (5%)     max: 3.49 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.52     gem: 1.5     mediaan: 1.5 (5%)     max: 1.54 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5018     gem: 5030     mediaan: 5029.5 (41%)     max: 5041 punten
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 10628     gem: 10811     mediaan: 10810.5 (12%)     max: 10993 punten
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 13307     gem: 13435     mediaan: 13434.5 (10%)     max: 13562 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6326     gem: 6414     mediaan: 6414 (35%)     max: 6502 Points
wPrime 2.10 - wPrime 2.0 1024m *
471.2 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
14.9 s (3%)
WinRAR - WinRAR 4.0
2940 punten (17%)
X264 HD Benchmark 4.0 - x264 Pass 2
19.9 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
105.3 fps (25%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (0%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (0%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (0%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 4267     gem: 4320     mediaan: 4319.5 (9%)     max: 4372 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.4 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
23.9 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
557 s (2%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
11749 Points (11%)
3DMark 11 - 3DM11 Performance Physics
min: 4391     gem: 4627     mediaan: 4627 (13%)     max: 4863 Points
3DMark - 3DMark Ice Storm Physics
min: 40631     gem: 42023     mediaan: 42022.5 (27%)     max: 43414 Points
3DMark - 3DMark Cloud Gate Physics
min: 3424     gem: 3483     mediaan: 3482.5 (9%)     max: 3541 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 4929     gem: 4966     mediaan: 4966 (9%)     max: 5003 Points
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
