Intel Core i7-3940XM

Intel 3940XM

De Intel Core i7-3940XM is de snelste quad-core processor voor laptops (in September 2012) en de opvolger van de i7-3920XM. Dankzij Hyperthreading kunnen de vier cores tot acht threads parallel draaien wat tot beter gebruik van de CPU leidt. Elke core heeft een basissnelheid van 3.0 GHz maar kan met Turbo Boost dynamisch overgeklokt worden naar 3.7 GHz (bij 4 actieve cores), 3.8 GHz (bij 2 actieve cores) of 3.9 GHz (bij 1 actieve core). Verder hebben de Extreme CPU's ook een open multiplicator zodat je makkelijk over kunt klokken.

Ivy Bridge is een verbeterde versie van de Sandy Bridge architectuur met betere prestaties van zowel de GPU als de CPU. De CPU's worden gemaakt op 22nm (vergeleken met de 32nm van de Sandy Bridge CPU's) en zijn de eerste die 3D transistors gebruiken voor een efficiënter verbruik vergeleken met de Sandy Bridge processors. Andere nieuwe features zijn de geïntegreerde PCI Express 3.0 en DDR3(L)-1600 ondersteuning.

De prestaties van de Core i7-3940XM zouden iets beter moeten zijn dan die van een vergelijkbaar geklokte Sandy Bridge processor door de kleine architectonische  verbeteringen. Vanwege de hogere kloksnelheid zal de nieuwe processor het ongeveer 3% beter doen dan het vorige topmodel, de Core i7-3920XM.

De geïntegreerde Intel HD Graphics 4000 heeft 16 Execution Units (EU's) met kloksnelheden van 650 MHz tot 1350 MHz met Turbo Boost wat het de snelste variant maakt.

De XM CPU's hebben allen een TDP van 55 watt inclusief grafische kaart en geheugencontroller en daardoor verbruiken ze 10 watt meer dan andere quad-core modellen. Deze CPU is geschikt voor laptops van 17-inches of meer.

SerieIntel Core i7
CodenaamIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM « 3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Kloksnelheid3000 - 3900 MHz
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache8 MB
Aantal Cores / Threads4 / 8
Stroomverbruik (TDP = Thermal Design Power)55 Watt
Aantal Transistoren1400 miljoen
Productietechnologie22 nm
Chipgrootte160 mm2
Max. Temperatuur105 °C
SocketFCPGA988
FeaturesHD Graphics 4000, DDR3(L)-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1350 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Startprijs$1096 U.S.
Aankondigingsdatum30-09-2012

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 7.45     gem: 7.5     mediaan: 7.5 (11%)     max: 7.46 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.62     gem: 1.6     mediaan: 1.6 (5%)     max: 1.63 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5246     gem: 5255     mediaan: 5252 (43%)     max: 5267 punten
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 20438     gem: 20582     mediaan: 20564 (23%)     max: 20744 punten
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 25475     gem: 25600     mediaan: 25624 (18%)     max: 25700 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6506     gem: 6621     mediaan: 6669 (36%)     max: 6687 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 208.8     gem: 219.2     mediaan: 215.7 (3%)     max: 233 s
wPrime 2.10 - wPrime 2.0 32m *
min: 6.8     gem: 7     mediaan: 7 (1%)     max: 7.169 s
WinRAR - WinRAR 4.0
min: 3467     gem: 4124     mediaan: 4123.5 (24%)     max: 4780 punten
X264 HD Benchmark 4.0 - x264 Pass 2
40.6 fps (15%)
X264 HD Benchmark 4.0 - x264 Pass 1
161.1 fps (38%)
TrueCrypt - TrueCrypt Serpent
min: 0.373     gem: 0.4     mediaan: 0.4 (0%)     max: 0.386 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.64     gem: 0.7     mediaan: 0.7 (0%)     max: 0.66 GB/s
TrueCrypt - TrueCrypt AES
min: 3.5     gem: 3.6     mediaan: 3.7 (0%)     max: 3.7 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 7166     gem: 7182     mediaan: 7176 (15%)     max: 7203 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 9     gem: 9.2     mediaan: 9 (2%)     max: 9.554 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 21     gem: 21.1     mediaan: 21 (1%)     max: 21.26 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 518     gem: 526     mediaan: 525.5 (2%)     max: 533 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 147240     gem: 147620     mediaan: 147620 (70%)     max: 148000 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 89600     gem: 89630     mediaan: 89630 (69%)     max: 89660 MFLOPS
Windows 7 Experience Index - Win7 CPU
7.7 Points (99%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 25344     gem: 25795     mediaan: 25885 (24%)     max: 26157 Points
3DMark 11 - 3DM11 Performance Physics
min: 7611     gem: 8737     mediaan: 9032 (25%)     max: 9568 Points
3DMark - 3DMark Ice Storm Physics
48410 Points (31%)
3DMark - 3DMark Cloud Gate Physics
7208 Points (18%)
3DMark - 3DMark Fire Strike Standard Physics
9863 Points (18%)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
