Intel Core i5-1140G7

Intel i5-1140G7

De Intel Core i5-1140G7 is een energiezuinige quad-core SoC voor laptops en Ultrabooks, gebaseerd op de Tiger Lake-U-generatie (UP4) die begin 2021 werd geïntroduceerd. Hij integreert vier Willow Cove-processorkernen (8 threads dankzij Hyper-Threading). De gegarandeerde basiskloksnelheid is afhankelijk van de TDP-instelling en kan variëren van 0,8 (7 W TDP) tot 1,8 GHz (15 W TDP). De turbokloksnelheid is gespecificeerd op 4,2 GHz voor één kern, alle kernen kunnen tot 3,5 GHz bereiken.

Een andere noviteit is de geïntegreerde Xe grafische kaart met 80EU's op basis van de geheel nieuwe Gen 12 architectuur. Deze biedt aanzienlijk hogere prestaties in vergelijking met de oudere Iris Plus G7 (Ice Lake). In de i5-1140G7 gebruikt hij 80 van de 96EU's en klokt tussen 400 - 1100 MHz. De GPU en CPU kunnen samen gebruik maken van de 8 MB L3 cache.

Verder voegen Tiger Lake SoC's PCIe 4-ondersteuning (vier lanes), AI-hardwareversnelling, en de gedeeltelijke integratie van Thunderbolt 4 / USB 4 en Wi-Fi 6 in de chip toe. De i5-1140G7 ondersteunt ook de beheerfunctie vPro.

De chip wordt geproduceerd in het verbeterde 10nm+ proces (SuperFin genaamd) bij Intel dat vergelijkbaar zou moeten zijn met het 7nm proces bij TSMC (bijv. Ryzen 4000-serie).

Het werkbereik van de UP4-serie wordt gespecificeerd op 7 tot 15 Watt. De processor is daarom zeer geschikt voor zeer dunne en lichte laptops, convertibles of tablets.

SerieIntel Tiger Lake
CodenaamTiger Lake-UP4

Serie: Tiger Lake Tiger Lake-UP4

Intel Core i7-1180G72.2 - 4.6 GHz4 / 8 cores12 MB L3
Intel Core i7-1160G72.1 - 4.4 GHz4 / 8 cores12 MB L3
Intel Core i5-1140G7 « 1.8 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i5-1130G71.8 - 4 GHz4 / 8 cores8 MB L3
Intel Core i3-1120G41.5 - 3.5 GHz4 / 8 cores8 MB L3
Intel Core i3-1110G42.5 - 3.9 GHz2 / 4 cores6 MB L3
Kloksnelheid1800 - 4200 MHz
Level 1 Cache320 KB
Level 2 Cache5 MB
Level 3 Cache8 MB
Aantal Cores / Threads4 / 8
Stroomverbruik (TDP = Thermal Design Power)15 Watt
Productietechnologie10 nm
Max. Temperatuur100 °C
SocketBGA1598
FeaturesLPDDR4x-4266 RAM, PCIe 4, 2 GT/s bus, DL Boost, GNA, vPro, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AVX, AVX2, AVX-512, BMI2, AMB, FMA, ADX, SMX, SMEP, SMAP, EIST, TM1, TM2, HT, Turbo, SST, AES-NI, RDRAND, RDSEED, SHA, TME
GPUIntel Iris Xe Graphics G7 80EUs (400 - 1100 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum02-09-2020
Productlink (extern)ark.intel.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
29 pt (40%)
2.47 -91%
...
Intel Core i5-8260U
28.2 -3%
Intel Core i5-1035G4
28.3 -2%
28.4 -2%
Intel Core i5-1035G1
28.6 -1%
28.7 -1%
28.8 -1%
28.8 -1%
28.9 0%
28.9 0%
Intel Core i5-1140G7
29
Intel Core i5-1035G7
29.1 0%
Intel Core i7-8809G
29.5 2%
29.6 2%
29.6 2%
Intel Core i7-1065G7
29.8 3%
Intel Core i5-1230U
29.9 3%
Intel Core i5-1038NG7
30.1 4%
30.1 4%
30.1 4%
...
57 97%
max:
72.1 149%
0%
100%
Cinebench R23 - Cinebench R23 Multi Core
2611 Points (2%)
202 -92%
...
1989 -24%
Intel Core i3-8109U
2004 -23%
2142 -18%
2174 -17%
2175 -17%
2303 -12%
2499 -4%
2546 -2%
2600 0%
Intel Core i5-1140G7
2611
Intel Core i7-2860QM
2699 3%
2711 4%
2729 5%
2739 5%
2913 12%
2914 12%
2927 12%
Intel Core i5-8260U
3028 16%
3038 16%
...
32782 1156%
max:
107681 4024%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
1246 Points (53%)
Cinebench R20 - Cinebench R20 CPU (Single Core)
438 Points (49%)
Cinebench R20 - Cinebench R20 CPU (Multi Core)
1126 Points (3%)
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
630 Points (4%)
31 -95%
...
Intel Core i5-1035G1
613 -3%
Intel Core i7-4700MQ
614 -3%
620 -2%
Intel Core i5-8259U
622 -1%
624 -1%
624 -1%
Intel Core i5-8260U
627 0%
628 0%
629 0%
Intel Core i5-1140G7
630
632 0%
634 1%
635 1%
635 1%
640 2%
641 2%
642 2%
Intel Core i7-1065G7
648 3%
648 3%
...
5600 789%
max:
15842 2415%
0%
100%
03570105140175210245280315350385420455490525560595Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
179 Points (54%)
19 -89%
...
175.5 -2%
175.5 -2%
175.6 -2%
175.8 -2%
176 -2%
Intel Core i5-1230U
176 -2%
176.5 -1%
Intel Xeon W-2145
177 -1%
178.4 0%
Intel Core i5-1140G7
179
179.9 1%
180.3 1%
Intel Core i7-8850H
180.4 1%
181.4 1%
Intel Xeon E-2176M
181.7 2%
182 2%
Intel Core i7-9750H
183.7 3%
184 3%
186.3 4%
...
311 74%
max:
332 85%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
7.1 Points (9%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
2.3 Points (56%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
7771 punten (47%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
19199 punten (14%)
wPrime 2.10 - wPrime 2.0 1024m *
410.7 s (5%)
wPrime 2.10 - wPrime 2.0 32m *
11 s (2%)
WinRAR - WinRAR 4.0
4632 punten (7%)
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
15167 MIPS (9%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
4201 MIPS (50%)
X264 HD Benchmark 4.0 - x264 Pass 2
32.1 fps (11%)
X264 HD Benchmark 4.0 - x264 Pass 1
145.9 fps (34%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
3.8 fps (7%)
01234567Tooltip
TrueCrypt - TrueCrypt Serpent
0.3 GB/s (0%)
TrueCrypt - TrueCrypt Twofish
0.6 GB/s (10%)
TrueCrypt - TrueCrypt AES
3.1 GB/s (8%)
Blender - Blender 2.79 BMW27 CPU *
993 Seconds (7%)
R Benchmark 2.5 - R Benchmark 2.5 *
0.7 sec (16%)
3DMark 06 - CPU - 3DMark 06 - CPU
7524 Points (16%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
8.3 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
18.4 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
434.9 s (2%)
3DMark 11 - 3DM11 Performance Physics
6257 Points (17%)
3DMark - 3DMark Fire Strike Standard Physics
7678 Points (14%)
3DMark - 3DMark Time Spy CPU
2773 Points (12%)
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
1353 punten (57%)
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
3921 punten (7%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
1355 punten (6%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
3904 punten (12%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
5937 punten (59%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
15462 punten (17%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
750 ms (1%)
Sunspider - Sunspider 1.0 Total Score *
160.1 ms (2%)
Octane V2 - Octane V2 Total Score
57983 Points (52%)
WebXPRT 3 - WebXPRT 3 Score
216 Points (45%)
Power Consumption - Prime95 Power Consumption - external Monitor *
29.1 Watt (5%)
051015202530Tooltip
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
27.3 Watt (5%)
051015202530Tooltip
Power Consumption - Cinebench R15 Multi Power Efficiency - external Monitor
23.1 Points per Watt (17%)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
