Intel Core i3-1120G4

Intel i3-1120G4

De Intel Core i3-1120G4 is een energiezuinige quad-core SoC voor laptops en Ultrabooks, gebaseerd op de Tiger Lake-U-generatie (UP4) die in september 2020 werd geïntroduceerd. Hij integreert vier Willow Cove processorkernen (8 threads dankzij Hyper-Threading). Elke core kan klokken van 1,1 GHz (basissnelheid) tot 3,5 GHz (1 core boost). Alle cores tegelijk kunnen tot 3 GHz klokken.

Een andere noviteit is de geïntegreerde Xe grafische kaart op basis van de volledig nieuwe Gen 12-architectuur. De i3 integreert de low-end UHD Graphics G4 met 48 van de 96 EU's ingeschakeld en een kloksnelheid van 400 - 1100 MHz. De GPU en CPU kunnen samen gebruik maken van de 8 MB L3-cache.

Verder voegen Tiger Lake SoC's PCIe 4-ondersteuning (4 lanes), AI-hardwareversnelling, en de gedeeltelijke integratie van Thunderbolt 4 / USB 4 en Wi-Fi 6 in de chip toe.

De chip wordt geproduceerd in het verbeterde 10nm+ proces (SuperFin genaamd) bij Intel dat vergelijkbaar zou moeten zijn met het 7nm proces bij TSMC (bijv. Ryzen 4000-serie).

Het werkbereik van de UP4-serie wordt gespecificeerd op 7 tot 15 Watt. De processor is daarom zeer geschikt voor zeer dunne en lichte laptops, convertibles of tablets.

SerieIntel Tiger Lake
CodenaamTiger Lake-UP4

Serie: Tiger Lake Tiger Lake-UP4

Intel Core i7-1180G72.2 - 4.6 GHz4 / 8 cores12 MB L3
Intel Core i7-1160G72.1 - 4.4 GHz4 / 8 cores12 MB L3
Intel Core i5-1140G71.8 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i5-1130G71.8 - 4 GHz4 / 8 cores8 MB L3
Intel Core i3-1120G4 « 1.5 - 3.5 GHz4 / 8 cores8 MB L3
Intel Core i3-1110G42.5 - 3.9 GHz2 / 4 cores6 MB L3
Kloksnelheid1500 - 3500 MHz
Level 1 Cache320 KB
Level 2 Cache5 MB
Level 3 Cache8 MB
Aantal Cores / Threads4 / 8
Stroomverbruik (TDP = Thermal Design Power)15 Watt
Productietechnologie10 nm
Max. Temperatuur100 °C
SocketBGA1598
FeaturesLPDDR4x-4266 RAM, PCIe 4, 2 GT/s bus, DL Boost, GNA, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AVX, AVX2, AVX-512, BMI2, ABM, FMA, ADX, SMEP, SMAP, EIST, TM1, TM2, Hyper-Threading, Turbo, SST, AES-NI, RDRAND, RDSEED, SHA
GPUIntel UHD Graphics Xe G4 48EUs (400 - 1100 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum02-09-2020
Productlink (extern)ark.intel.com

Benchmarks

- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
