AMD A4-1200
De AMD A4-1200 is een mobile dual-core SoC voor tablets, voorgesteld in het midden van 2013. Naast de 2 CPU cores met een basiskloksnelheid van 1.0 GHz (geen Turbo), integreert de 28 nanometer-chip ook een Radeon HD 8180 GPU, een single-channel DDR3-1066 geheugencontroller en een Southbridge met verschillende I/O-poorten. Architectuur Zowel Kabini (voor notebooks) als Temash (tablets en compacte subnotebooks) zijn gebaseerd op AMD's nieuwe Jaguar architectuur, die de vorige Bobcat modellen vervangt (bv. de E-350). De prestaties in verhouding tot de kloksnelheid zijn verbeterd met zo'n 15 procent. Bovendien worden verschillende moderne instructieset-extensies zoals SSE tot en met versie 4.2, AVX en AES nu ondersteund. Het fijnere 28-nanometer proces van TSMC laat lagere voltages en/of hogere kloksnelheden toe vergeleken met Bobcat evenals een maximum van 4 CPU cores (Bobcat: 2 cores). Prestaties Dankzij de lage kloksnelheid van 1.0 GHZ zijn de prestaties eerder bescheiden en vergelijkbaar met die van de oude AMD C-60. Voor eenvoudige office- en multimedia-taken, heeft de A4-1200 genoeg rekenkracht; meer veeleisende software zal de CPU echter snel tot aan zijn limiet brengen. Grafisch De SoC integreert een Radeon HD 8180 GPU met 128 shaders, gebaseerd op de GCN achitectuur en geklokt aan 225 MHz (geen Turbo). Gemiddeld gezien, is de HD 8210 iets trager dan de Intel HD Graphics (Sandy Bridge); de prestaties worden vaak echter beperkt door de CPU. Recente games (2013) zijn daarom nauwelijks speelbaar. Enkel een aantal oudere en minder veeleisende games zullen vloeiend speelbaar zijn. Stroomverbruik Het stroomverbruik van de gehele SoC is ingesteld op slechts 3.9 Watt. De A4-1200 is dus geschikt voor slanke ultraportables en passief gekoelde tablets.
Serie AMD A-Series Codenaam Temash Serie: A-Series Temash Kloksnelheid 1000 MHz Level 1 Cache 128 KB Level 2 Cache 1 MB Aantal Cores / Threads 2 / 2 Stroomverbruik (TDP = Thermal Design Power) 3.9 Watt Productietechnologie 28 nm Features SSE (1, 2, 3, 3S, 4.1, 4.2, 4A), x86-64, AES, AVX, DDR3L-1066 GPU AMD Radeon HD 8180 (225 MHz)64-Bit 64-Bit-ondersteuning Architecture x86 Aankondigingsdatum 23-05-2013
Benchmarks Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 29 gem: 31 mediaan: 31 (1%) max: 33 Points
...
AMD E1-6010 47%
Intel Celeron N2806 87%
...
AMD Ryzen Threadripper 2970WX 14016%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 18 gem: 19 mediaan: 19 (7%) max: 20 Points
Intel Celeron N2806 37%
AMD E1-6010 37%
Intel Atom x5-E8000 42%
Intel Atom x5-Z8300 46%
...
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 0.26 gem: 0.4 mediaan: 0.4 (1%) max: 0.47 Points
AMD E-240 -33%
AMD Athlon Neo MV-40 -15%
AMD Mobile Sempron 2800+ -13%
AMD C-50 -9%
AMD Athlon II Neo K125 15%
AMD E-300 23%
Intel Atom D525 46%
...
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.11 gem: 0.2 mediaan: 0.2 (7%) max: 0.25 Points
AMD E-300 20%
Intel Atom Z3735F 43%
...
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 444 gem: 657 mediaan: 705.5 (6%) max: 771 punten
...
Intel Atom Z540 -14%
Qualcomm Snapdragon 8cx -10%
Intel Atom N470 -10%
Intel Atom N475 -9%
Intel Atom D525 -7%
Intel Mobile A A110 -6%
AMD C-50 0%
Intel Atom Z3735D 30%
...
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 822 gem: 1189 mediaan: 1248 (2%) max: 1439 punten
...
Intel Atom 230 -28%
Intel Atom N455 -28%
Intel Atom N475 -20%
Intel Atom Z550 -18%
VIA Nano L2100 -9%
AMD Athlon Neo MV-40 -3%
AMD E-300 -1%
Intel Core 2 Solo SU3300 5%
AMD C-50 8%
Intel Atom N550 19%
...
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 991 gem: 1491 mediaan: 1642.5 (2%) max: 1689 Points
AMD C-50 -8%
AMD Athlon II Neo K125 16%
AMD E-300 18%
AMD V-Series V120 44%
AMD E-350 46%
...
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 548 gem: 798 mediaan: 861.5 (6%) max: 919 Points
...
AMD C-50 -11%
AMD E-300 15%
AMD E-240 27%
AMD E-450 42%
AMD E-350 43%
...
AMD Ryzen 7 5800X 1534%
wPrime 2.10 - wPrime 2.0 1024m *
3798 s (45%)
AMD Ryzen Threadripper 2970WX -99%
...
AMD C-50 -4%
Intel Pentium M 758 -3%
Intel Pentium M 705 -3%
Intel Celeron M 370 -3%
Intel Atom 330 -2%
Intel Atom N455 -1%
Intel Mobile Pentium 4 520 3%
Intel Celeron M 340 5%
Intel Pentium M 738 9%
Intel Pentium M 710 9%
Intel Pentium SU2700 9%
Intel Celeron M 360 10%
...
VIA C3-M C3-M-1200 123%
wPrime 2.10 - wPrime 2.0 32m *
112 s (23%)
Intel Core i9-9980XE -98%
...
Intel Atom N475 -6%
Intel Atom N470 -4%
AMD Turion 64 MT-28 -4%
AMD Mobile Sempron 2800+ -4%
Intel Pentium M 730 -4%
AMD Mobile Sempron 2600+ -3%
AMD Turion 64 ML-30 -2%
Intel Celeron M 380 -1%
AMD C-50 3%
Intel Pentium M 715 3%
Intel Core Solo T1200 4%
Intel Atom 330 4%
Intel Pentium M 758 4%
...
Transmeta Crusoe TM-5800 344%
447 punten (3%)
AMD Athlon Neo MV-40 -26%
AMD E-450 10%
AMD E1-6010 15%
AMD A6-9220e 16%
Intel Celeron N3050 23%
Intel Atom x5-E8000 32%
...
AMD Ryzen 7 5800X 3391%
X264 HD Benchmark 4.0 - x264 Pass 2
2.9 fps (1%)
Intel Pentium 4 2.4 GHz -34%
AMD Athlon Neo MV-40 -31%
AMD A6-9220e -7%
AMD E-450 1%
...
X264 HD Benchmark 4.0 - x264 Pass 1
11.5 fps (3%)
Intel Pentium 4 2.4 GHz -13%
AMD Athlon Neo MV-40 1%
AMD A6-9220e 28%
AMD E-450 41%
...
AMD Ryzen 7 5800X 2848%
TrueCrypt - TrueCrypt Serpent
0 GB/s (1%)
Intel Pentium 4 2.4 GHz -43%
AMD Athlon Neo MV-40 -17%
Intel Core 2 Duo SU7300 30%
...
TrueCrypt - TrueCrypt Twofish
0.5 GB/s (15%)
...
Intel Core i7-4712HQ -6%
Intel Core i5-6600K -4%
Intel Core i5-7500 -3%
Intel Core i7-2860QM -3%
Intel Xeon E5-2680 -2%
Intel Core i5-7600K 5%
Intel Core i7-4700MQ 6%
Intel Core i7-2700K 6%
...
AMD Ryzen 9 3950X 562%
TrueCrypt - TrueCrypt AES
0.3 GB/s (1%)
...
Intel Celeron N2940 -22%
Intel Celeron N2930 -21%
AMD A6-3420M -15%
Intel Pentium N3530 -7%
Intel Pentium N3540 -3%
AMD E1-6010 8%
Intel Xeon E5-2680 12%
AMD A6-9220e 13%
AMD E-450 24%
AMD Phenom II X4 905e 33%
Intel Celeron N3050 34%
...
3DMark 06 - CPU - 3DMark 06 - CPU
min: 725 gem: 733 mediaan: 733 (4%) max: 741 Points
...
Intel Pentium M 730 -10%
AMD Mobile Sempron 3400+ -9%
AMD Turion 64 MT-32 -7%
Intel Pentium M 725 -7%
AMD Turion 64 ML-34 -5%
Intel Pentium M 735 -5%
AMD Mobile Sempron 3500+ -4%
Intel Pentium M 740 1%
Intel Atom N570 1%
Intel Celeron M 530 1%
Intel Pentium M 770 1%
AMD Athlon II Neo K125 1%
Intel Atom N550 1%
AMD Mobile Sempron 3600+ 2%
AMD Mobile Sempron SI-40 5%
...
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 27 gem: 40.8 mediaan: 27 (6%) max: 68.449 s
...
AMD Mobile Sempron M100 -1%
Intel Pentium M 765 -1%
AMD Phenom II X3 P840 -1%
AMD A4 Micro-6400T -1%
Intel Celeron M 430 0%
Intel Pentium Dual Core T2060 0%
AMD Turion 64 ML-44 0%
Intel Core 2 Duo L7100 0%
Intel Celeron N3150 0%
Intel Pentium M 760 2%
AMD Turion 64 MK-38 2%
...
VIA C3-M C3-M-1200 1035%
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 61 gem: 89.2 mediaan: 61 (3%) max: 145.648 s
...
Intel Atom x7-E3950 -5%
Intel Atom x5-Z8500 -4%
Intel Core Duo T2300 -3%
Intel Core Duo T2250 -2%
AMD Athlon II M300 0%
Intel Core 2 Duo L7100 1%
Intel Celeron N3150 1%
AMD A6-3400M 2%
Intel Celeron Dual-Core T1500 2%
Intel Pentium M 770 2%
AMD Athlon 64 X2 (Desktop) 4400+ 3%
...
Intel Celeron Dual-Core T1400 2523%
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1566 gem: 2089 mediaan: 1566 (7%) max: 3134.1 s
...
Intel Celeron M 520 -4%
Intel Core Duo T2300 -2%
AMD A4 Micro-6400T -1%
Intel Pentium Dual Core T2080 1%
Intel Celeron M 430 1%
Intel Pentium Dual Core SU4100 1%
AMD Athlon II M300 2%
Intel Celeron M 550 2%
AMD Turion 64 ML-44 2%
Intel Atom Z3736F 3%
...
VIA C3-M C3-M-1200 978%
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
8910 MIPS (4%)
...
Intel Atom N570 -10%
Intel Atom 330 -10%
Intel Core Duo U2500 -8%
AMD Turion 64 ML-34 -7%
Intel Pentium M 760 -4%
AMD Turion 64 ML-44 -2%
Intel Atom D525 1%
Intel Core 2 Duo SU9300 5%
Intel Celeron M 900 5%
AMD E-450 6%
AMD E-350 8%
...
Intel Xeon E3-1535M v5 1836%
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
5410 MFLOPS (4%)
...
AMD Athlon 64 TF-20 -13%
Intel Mobile Pentium 4 520 -11%
Intel Pentium M 755 -10%
AMD Athlon Neo MV-40 -9%
AMD C-50 -8%
Intel Celeron M 520 -6%
AMD Athlon II Neo K125 -2%
AMD Mobile Sempron 3300+ 9%
Intel Core Duo U2500 11%
Intel Core 2 Duo T5270 16%
Intel Atom N550 17%
Intel Celeron M 550 18%
...
Intel Core i7-3960X 2294%
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
1348 Points (2%)
AMD Athlon Neo MV-40 -15%
AMD C-50 -13%
AMD Athlon II Neo K125 -4%
AMD Mobile Sempron SI-42 5%
AMD E1-6010 15%
AMD E-300 17%
AMD V-Series V120 25%
AMD E-450 38%
Intel Atom D525 42%
...
AMD Ryzen 7 5800X 6284%
3DMark 11 - 3DM11 Performance Physics
570 Points (2%)
AMD C-50 -39%
AMD A6-9220e -7%
AMD E-350 12%
AMD E1-6010 19%
AMD E-450 19%
...
3DMark - 3DMark Ice Storm Physics
min: 2306 gem: 4717 mediaan: 5084.5 (3%) max: 6394 Points
Samsung Hummingbird S5PC110 / Exynos 3110 -89%
...
Renesas MP5232 -12%
Qualcomm Snapdragon 801 MSM8974AA -9%
HiSilicon k3v2 Hi3620 -5%
AMD A6-9220e -5%
Rockchip RK3066 1.5 GHz 6%
Samsung Exynos 4212 1.5 GHz 7%
Qualcomm Snapdragon 200 8225Q 22%
...
Intel Core i5-4300Y 3197%
3DMark - 3DMark Cloud Gate Physics
min: 202 gem: 393 mediaan: 482 (1%) max: 494 Points
AMD A6-9220e 13%
AMD E1-6010 39%
...
AMD Ryzen 7 5800X 5750%
3DMark - 3DMark Fire Strike Standard Physics
min: 179 gem: 358 mediaan: 358 (1%) max: 537 Points
...
AMD A6-9220e 5%
AMD E1-6010 122%
...
Geekbench 2 - 32 Bit - Geekbench Stream
min: 859 gem: 1405 mediaan: 1659 (13%) max: 1697 Points
Qualcomm Snapdragon S1 MSM7227 -95%
...
Samsung Exynos 5260 Hexa -12%
Samsung Exynos 7884B -4%
Mediatek MT8135 -2%
MediaTek Dimensity 820 9%
Intel Atom Z3460 21%
Qualcomm Snapdragon 801 MSM8974AC 22%
...
Intel Core i7-7740X 782%
Geekbench 2 - 32 Bit - Geekbench Memory
min: 725 gem: 1145 mediaan: 1351 (12%) max: 1358 Points
Qualcomm Snapdragon S1 MSM7227 -73%
...
Rockchip RK3066 1.5 GHz -6%
Intel Atom Z2480 -6%
Samsung Exynos 4212 1.5 GHz -5%
Mediatek Helio G25 -1%
HiSilicon k3v2 Hi3620 4%
Qualcomm Snapdragon 400 MSM8226 5%
...
Intel Core i7-7740X 863%
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 875 gem: 1343 mediaan: 1573 (3%) max: 1580 Points
Qualcomm Snapdragon S1 MSM7227 -97%
...
Intel Atom Z2480 -14%
MediaTek MT8317T -6%
Rockchip RK3066 1.5 GHz 5%
MediaTek MT8377 8%
AMD Athlon Neo MV-40 17%
...
Geekbench 2 - 32 Bit - Geekbench Integer
min: 714 gem: 1021 mediaan: 1169 (2%) max: 1179 Points
Qualcomm Snapdragon S1 MSM7227 -90%
...
MediaTek MT8377 -18%
Qualcomm Snapdragon 200 8225Q -16%
Samsung Exynos 3470 Quad -14%
Samsung Exynos 4212 1.5 GHz 3%
Qualcomm Snapdragon 400 MSM8226 4%
Intel Atom Z3460 5%
...
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 787 gem: 1196 mediaan: 1395 (4%) max: 1406 Points
Qualcomm Snapdragon S1 MSM7227 -90%
...
MediaTek MT8377 -17%
Intel Atom Z2480 -17%
Qualcomm Snapdragon 200 8225Q -16%
Rockchip RK3066 1.5 GHz -14%
Samsung Exynos 3470 Quad 1%
Samsung Exynos 4212 1.5 GHz 4%
Qualcomm Snapdragon 400 MSM8226 6%
...
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 506 gem: 831 mediaan: 986 (2%) max: 1000 punten
Samsung Hummingbird S5PC110 / Exynos 3110 -73%
...
Renesas MP5232 -21%
Broadcom BCM21664T -21%
Intel Atom x3-C3230RK 3%
Qualcomm Snapdragon 212 APQ8009 29%
...
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 308 gem: 481 mediaan: 564 (12%) max: 572 punten
Samsung Hummingbird S5PC110 / Exynos 3110 -50%
...
Qualcomm Snapdragon 400 MSM8928 -18%
Spreadtrum SC9830A -16%
Qualcomm Snapdragon 400 APQ8028 -10%
Mediatek MT6592 -9%
Qualcomm Snapdragon 410 MSM8916 0%
Qualcomm Snapdragon 410 APQ8016 1%
HiSilicon Kirin 910 6%
Marvell Armada PXA1908 20%
...
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Smaller numbers mean a higher performance
v1.16
log 23. 14:33:40
#0 no ids found in url (should be separated by "_") +0s ... 0s
#1 not redirecting to Ajax server +0s ... 0s
#2 did not recreate cache, as it is less than 5 days old! Created at Sun, 21 Feb 2021 08:40:14 +0100 +0s ... 0s
#3 no comparison url found in template nbc.compare_page_2 needed +0.004s ... 0.005s
#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.005s
#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.005s
#6 composed specs +0s ... 0.005s
#7 did output specs +0s ... 0.005s
#8 getting avg benchmarks for device 4153 +0s ... 0.005s
#9 got single benchmarks 4153 +0.01s ... 0.015s
#10 got avg benchmarks for devices +0s ... 0.015s
#11 min, max, avg, median took s +0.256s ... 0.272s
#12 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.272s
#13 return log +0s ... 0.272s
Testrapporten voor de AMD A-Series A4-1200 processor
Asus F102BA-DF047H (AMD Radeon HD 8180, 10.10")
» Kort testrapport Asus F102BA-DF047H Netbook - Testrapport » Asus F102BA-DF047H - Extern testrapport
Asus X102BA-BH41T (AMD Radeon HD 8180, 10.10")
» Asus X102BA-BH41T - Extern testrapport
HP Pavilion 10 TouchSmart 10z-e000 (AMD Radeon HD 8180, 10.10")
» HP Pavilion 10 TouchSmart 10z-e000 - Extern testrapport
Medion Akoya E1317T (AMD Radeon HD 8180, 10.00")
» Medion Akoya E1317T - Extern testrapport
Medion Akoya E1318T-MD99330 (AMD Radeon HD 8180, 10.10")
» Medion Akoya E1318T-MD99330 - Extern testrapport
Medion The Touch 10 (AMD Radeon HD 8180, 10.00")
» Medion The Touch 10 - Extern testrapport
MSI W20-3M (AMD Radeon HD 8180, 11.60")
» MSI W20-3M - Extern testrapport
MSI W20-A421 (AMD Radeon HD 8180, 11.60")
» Kort testrapport MSI W20-A421 Tablet - Testrapport
Toshiba Satellite Click W35Dt-A3300 (AMD Radeon HD 8180, 13.30")
» Toshiba Satellite Click W35Dt-A3300 - Extern testrapport
Toshiba Satellite Click W35Dt-AST2N01 (AMD Radeon HD 8180, 13.30")
» Toshiba Satellite Click W35Dt-AST2N01 - Extern testrapport
Toshiba Satellite W30Dt-A-100 (AMD Radeon HD 8180, 13.30")
» Kort testrapport Toshiba Satellite W30Dt-A-100 Convertible - Testrapport » Toshiba Satellite W30Dt-A-100 - Extern testrapport
Andere CPU's van de serie A-Series » AMD A8-7410 4x 2.2 GHz - 2.5 GHz
» AMD A8-3550MX 4x 2 GHz - 2.7 GHz
» AMD A6-7310 4x 2 GHz - 2.4 GHz
» AMD A8-3530MX 4x 1.9 GHz - 2.6 GHz
» AMD A8-3510MX 4x 1.8 GHz - 2.5 GHz
» AMD A4-7210 4x 1.8 GHz - 2.2 GHz
» AMD A6-3430MX 4x 1.7 GHz - 2.4 GHz
» AMD A8-3520M 4x 1.6 GHz - 2.5 GHz
» AMD A6-3410MX 4x 1.6 GHz - 2.3 GHz
» AMD A8-3500M 4x 1.5 GHz - 2.4 GHz
» AMD A6-3420M 4x 1.5 GHz - 2.4 GHz
» AMD A6-3400M 4x 1.4 GHz - 2.3 GHz
» AMD A4-3330MX 2x 2.2 GHz - 2.6 GHz
» AMD A4-6210 4x 1.8 GHz
» AMD A4-5050 4x 1.55 GHz
» AMD A4-3310MX 2x 2.1 GHz - 2.5 GHz
» AMD A4-3320M 2x 2 GHz - 2.6 GHz
» AMD A4 Micro-6400T 4x 1 GHz - 1.6 GHz
Omringende CPU's + Intel Atom E3826 2x 1.46 GHz
- AMD GX-210JA 2x 1 GHz
- Intel Atom D525 2x 1.8 GHz
- Intel Atom E3825 2x 1.33 GHz
- Intel Atom E3805 2x 1.33 GHz
Please share our article, every link counts!
Klaus Hinum (Update: 2014-01-24)
