Intel Celeron N3160

Intel N3160

De Intel Celeron N3160 is een quad-core-SoC voor instapnotebooks die werd voorgesteld in het begin van 2016. De CPU is geklokt aan 1.6 - 2.24 GHz (Boost) en maakt deel uit van het Braswell-platform. Het SoC is gefabriceerd in een modern 14nm-proces (P1273) met FinFET's. Naast de vier CPU-cores biedt het SoC ook een DirectX 11.2-capabele GPU en een DDR3L-geheugencontroller (2x 64-bit, 25.6 GB/s). De N3160 heeft een 160 MHz hogere Boost-kloksnelheid dan zijn voorganger, de Celeron N3150.

Architectuur

De processor-cores zijn gebaseerd op de Airmont-architectuur, die in feite een iets gekrompen versie van de vorige Silvermont-core is. Hoewel de performance per MHz niet verbeterd werd, laat het efficiëntere 14nm-proces een beter gebruik van de Turbo Boost toe, wat in sommige situaties tot hogere prestaties leidt. De per-MHz-performance is nog altijd een stuk lager dan die van de duurdere Core-serie (bv. Broadwell).

Prestaties

Met 4 CPU-cores en een kloksnelheid tussen 1.6 en 2.24 GHz zijn de technische specificaties gelijkaardig aan die van de oudere Celeron N2930, waardoor de performance slechts iets beter is. De processor is dus geschikt voor alledaagse taken (office, browsen) evenals voor lichte multi-tasking.

Graphics

De HD Graphics (Braswell) is gebaseerd op de Intel Gen8-architectuur met ondersteuning voor DirectX 11.2 en wordt ook toegepast in de Broadwell-serie (bv. HD Graphics 5300). Met 12 EU's (Execution Units) en een kloksnelheid tot 640 MHz liggen de GPU-prestaties echter een stuk lager. De GPU is gemiddeld genomen ongeveer twee keer zo snel als de HD Graphics (Bay Trail), wat iets trager is dan de oudere HD Graphics 4000. Alleen oudere en eenvoudigere titels als Counter Strike: GO zullen vlot speelbaar zijn. De chip bevat nog altijd een geavanceerde video-unit met ondersteuning voor 4K/H.265-videoversnelling.

Energieverbruik

Het gehele SoC is afgestemd op een TDP van 6 Watt (SDP 4 Watt). De chip kan dus passief gekoeld worden.

SerieIntel Celeron
CodenaamBraswell

Serie: Celeron Braswell

Intel Celeron N3160 « 1.6 - 2.24 GHz4 / 4 cores
Intel Celeron N31501.6 - 2.08 GHz4 / 4 cores
Intel Celeron N30601.6 - 2.48 GHz2 / 2 cores
Intel Celeron N30501.6 - 2.16 GHz2 / 2 cores
Intel Celeron N30001.04 - 2.08 GHz2 / 2 cores
Kloksnelheid1600 - 2240 MHz
Level 2 Cache2 MB
Aantal Cores / Threads4 / 4
Stroomverbruik (TDP = Thermal Design Power)6 Watt
Productietechnologie14 nm
Max. Temperatuur90 °C
SocketFCBGA1170
FeaturesIntel HD Graphics (Braswell, 12 EUs, 320 - 640 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics (Braswell) (320 - 640 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum01-04-2016
Productlink (extern)ark.intel.com

Benchmarks

3DMark - 3DMark Ice Storm Unlimited Physics
19687 Points (17%)
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
1696 Points (19%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
1091 punten (11%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
3305 punten (4%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
4300 ms (5%)
Sunspider - Sunspider 1.0 Total Score *
991 ms (11%)
Octane V2 - Octane V2 Total Score
8018 Points (7%)
PCMark for Android - PCM f. Android Computer Vision
3380 Points (18%)
PCMark for Android - PCM f. Android Storage
7992 Points (17%)
PCMark for Android - PCM f. Android Work Score 2.0
5399 Points (35%)
PCMark for Android - PCM f. Android Work Score
7580 Points (38%)
CrXPRT 2 - CrXPRT2 Performance Score
36 Points (20%)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
