Intel Core i7-2617M

Intel 2617M

De Intel Core i7-2617M is een energie-efficiënte ULV (Ultra Low Voltage) processor voor dunne en lichte laptops. De standaard kloksnelheid van 1.5 GHz is relatief laag, maar dankzij Turbo Boost 2.0 kan de kloksnelheid naar 2.6 GHz verhoogd worden (bij één belaste core, 2.3 GHz bij twee belaste cores). Dit hangt echter wel af van de koelcapaciteit en energieverbruik van de laptop. Met Hyper-Threading kan de i7-2617M maximaal 4 threads tegelijkertijd verwerken. Vergeleken met de langzamere i5-2537M biedt de i7-2617M een hogere kloksnelheid (standaardkloksnelheid, Turbo-kloksnelheid, GPU Turbo) en meer Level 3 cache.

Sandy Bridge is de evolutionaire opvolger van de Arrandale-architectuur. De meest zichtbare verbeteringen zijn de verbeterde Turbo 2.0 en de geïntegreerde grafische kaart op de 32nm CPU core.

De geïntegreerde Intel HD Graphics 3000 wordt op 350 of 950 MHz (Turbo Boost) geklokt. Door de lage kloksnelheid zonder Turbo, zullen de prestaties merkbaar lager zijn dan de HD Graphics 3000 in 35W en 45W processoren (in non-LV processoren is de standaardkloksnelheid vaak 650-1100/1300 MHz).

De prestaties van de CPU zouden wat hoger moeten zijn dan vergelijkbaar geklokte Arrandale Core i5-processoren. De prestaties zullen daarom vergelijkbaar met een Core i3-350M als Turbo Boost veel gebruikt kan worden.

Het TDP van 17 watt (inclusief geïntegreerde GPU en geheugencontroller) maakt het gebruik van de i7-2617M CPU in kleine subnotebooks mogelijk.

SerieIntel Core i7
CodenaamSandy Bridge
Serie: Core i7 Sandy Bridge
Intel Core i7-2960XM2700 - 3700 MHz4 / 88 MB
Intel Core i7-2860QM2500 - 3600 MHz4 / 88 MB
Intel Core i7-2920XM2500 - 3500 MHz4 / 88 MB
Intel Core i7-2760QM2400 - 3500 MHz4 / 86 MB
Intel Core i7-2820QM2300 - 3400 MHz4 / 88 MB
Intel Core i7-2720QM2200 - 3300 MHz4 / 86 MB
Intel Core i7-2675QM2200 - 3100 MHz4 / 86 MB
Intel Core i7-2670QM2200 - 3100 MHz4 / 86 MB
Intel Core i7-2635QM2000 - 2900 MHz4 / 86 MB
Intel Core i7-2630QM2000 - 2900 MHz4 / 86 MB
Intel Core i7-2640M2800 - 3500 MHz2 / 44 MB
Intel Core i7-2620M2700 - 3400 MHz2 / 44 MB
Intel Core i7-2649M2300 - 3200 MHz2 / 44 MB
Intel Core i7-2629M2100 - 3000 MHz2 / 44 MB
Intel Core i7-2677M1800 - 2900 MHz2 / 44 MB
Intel Core i7-2637M1700 - 2800 MHz2 / 44 MB
Intel Core i7-2657M1600 - 2700 MHz2 / 44 MB
» Intel Core i7-2617M1500 - 2600 MHz2 / 44 MB
Kloksnelheid1500 - 2600 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Aantal Cores / Threads2 / 4
Max. Stroomverbruik (TDP = Thermal Design Power)17 Watt
Aantal Transistoren624 miljoen
Productietechnologie32 nm
Chipgrootte149 mm2
Max. Temperatuur100 °C
SocketBGA1023
GPUIntel HD Graphics 3000 (350 - 950 MHz)
64-Bit64-Bit-ondersteuning
Startprijs$100 U.S.
Aankondigingsdatum03-01-2011
Productlink (extern)Intel Core i7 2617M

Benchmarks

Cinebench R11.5 - CPU Multi 64Bit
2.1 Points (5%)
Cinebench R10 - Rendering Single 32Bit
3315 Points (36%)
Cinebench R10 - Rendering Multiple CPUs 32Bit
6690 Points (10%)
Cinebench R10 - Rendering Multiple CPUs 64Bit
8113 Points (11%)
Cinebench R10 - Rendering Single CPUs 64Bit
4143 Points (40%)
wPrime 2.0x - 1024m *
782.7 seconds (9%)
wPrime 2.0x - 32m *
24.1 seconds (5%)
3DMark 06 - CPU
2762 Points (18%)
Super Pi mod 1.5 XS 1M *
15.3 Seconds (3%)
Super Pi mod 1.5 XS 2M *
34.8 Seconds (1%)
Super Pi Mod 1.5 XS 32M *
816.9 Seconds (4%)
3DMark Vantage - P CPU no PhysX 1280x1024
7233 Points (10%)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Smaller numbers mean a higher performance

v1.8.1a

Testrapporten voor de Intel Core i7 2617M processor
