Intel Core i7-820QM

Intel 820QM

De Intel Core i7 820QM is een high end quad core processor uit 2009. Hij heeft 4 cores (quad core CPU) en Hyperthreading. Daardoor kan er aan 8 threads gelijktijdig gewerkt worden.

Door de Turbo mode kan de CPU geklokt worden tot 3,06 GHz en is hij eveneens snel voor oudere single core applicaties zoals sommige games.

De Core i7 9xx reeks heeft eenheeft een geïntegreerde geheugen controller voor DDR3 geheugen (1066 of 1333). De geheugen prestaties zijn daardoor erg goed (vergeleken met oudere CPU's met een externe geheugen controller). Dit resulteert uiteindelijk wel in een hogere TDP van de gehele chip.

Core architectuur is nog steeds erg vergelijkbaar met de architectuur van de Core 2 CPU's.

Het stroomverbruik tot 45 Watt (TDP) is vrij hoog voor een laptop CPU, en door de de Turbo modus is het waarschijnlijk dat deze waarde ook effectief gehaald wordt. Daardoor is deze CPU enkel geschikt voor grote laptops.

SerieIntel Core i7
CodenaamClarksfield
Serie: Core i7 Clarksfield
Intel Core i7-940XM2130 - 3333 MHz4 / 88 MB
Intel Core i7-920XM2000 - 3200 MHz4 / 88 MB
Intel Core i7-840QM1860 - 3200 MHz4 / 88 MB
» Intel Core i7-820QM1730 - 3060 MHz4 / 88 MB
Intel Core i7-740QM1730 - 2930 MHz4 / 86 MB
Intel Core i7-720QM1600 - 2800 MHz4 / 86 MB
Kloksnelheid1730 - 3060 MHz
Front Side Bus2500
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache8 MB
Aantal Cores / Threads4 / 8
Stroomverbruik (TDP = Thermal Design Power)45 Watt
Aantal Transistoren774 miljoen
Productietechnologie45 nm
Chipgrootte296 mm2
Max. Temperatuur100 °C
SocketRPGA989
64-Bit64-Bit-ondersteuning
Startprijs$546 U.S.
Aankondigingsdatum23-09-2009
Productlink (extern)Intel Core i7 820QM

Benchmarks

Cinebench R11.5 - CPU Multi 64Bit
min: 2.95     gem: 3.1     mediaan: 3 (87%)     max: 3.390000104904175 Points
Cinebench R10 - Rendering Single 32Bit
min: 3075     gem: 3456.6     mediaan: 3271.5 (72%)     max: 4185 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 8341     gem: 9174.4     mediaan: 8559 (82%)     max: 10398 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
min: 10222     gem: 10497.8     mediaan: 10317 (92%)     max: 11264 Points
Cinebench R10 - Rendering Single CPUs 64Bit
min: 3709     gem: 3952.2     mediaan: 3987 (69%)     max: 4101 Points
wPrime 2.10 - 1024m *
min: 423.97     gem: 1139.7     mediaan: 1361.7 (16%)     max: 1411.58 seconds
wPrime 2.10 - 32m *
min: 13.73     gem: 35.2     mediaan: 42 (8%)     max: 43 seconds
3DMark 06 - CPU - CPU Score
min: 3053     gem: 3226.1     mediaan: 3149 (74%)     max: 3629 Points
Super Pi mod 1.5 XS 1M - 1M *
14 Seconds (3%)
Super Pi mod 1.5 XS 2M - 2M *
min: 31     gem: 31.7     mediaan: 32 (1%)     max: 32 Seconds
Super Pi Mod 1.5 XS 32M - 32M *
min: 765     gem: 787.3     mediaan: 780 (3%)     max: 817 Seconds
PCMark 05 - Standard 1024x768
7734 Points (87%)
Windows 7 Experience Index - Processor
min: 7.1     gem: 7.2     mediaan: 7.2 (94%)     max: 7.2 points
3DMark Vantage - P CPU no PhysX 1280x1024
min: 10851     gem: 11569.7     mediaan: 11251.5 (46%)     max: 12631 Points
3DMark 11 - Performance Physics 1280x720
min: 4002     gem: 4002     mediaan: 4002 (100%)     max: 3988 points
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Smaller numbers mean a higher performance

v1.13
