Intel Core M-5Y10
De Intel Core M-5Y10 is een ULV (ultra-low-voltage) dual-core-SoC gebaseerd op de Broadwell-architectuur gelanceerd in September 2014. Dankzij zijn lage TDP van slechts 4.5W (aanpasbaar) is de CPU geschikt voor passief gekoelde tablets en 2-in-1-notebooks. Naast de twee CPU cores met Hyper-Threading geklokt aan 0.8 - 2.0 GHz, integreert de chip ook een HD Graphics 5300 GPU en een dual-channel LPDDR3/DDR3L(-RS) geheugencontroller tot en met 25.6 GB/s. De chip is gefabriceerd in een 14nm-proces met FinFET-transistors.
Terwijl de Core M-5Y10 ondersteuning biedt voor "Config Down TDP" voor een optioneel TDP van slechts 4 W, is dit niet van toepassing op de 5Y10a.
Broadwell vertegenwoordigt de "Tick" in Intel's Tick-Tock-model, wat neerkomt op een verkleining van zijn voorganger Haswell. Het nieuwe 14nm-productieproces met driedimensionale FinFET-transistors laat toe om niet alleen de energie-efficiëntie te verhogen, maar ook om veel kleinere chips te maken voor meer compacte schikkingen en kleinere toestellen.
Bijkomende voordelen resulteren uit de herziene micro-architectuur van Broadwell. Dankzij zijn verbeterde aftakkingsvoorspelling, grotere buffers (1500 in plaats van 1000 entries in het L2 TLB) en andere aanpassingen, is de performance per MHz met meer dan 5 procent gestegen ten opzichte van voorganger. Er zijn ook nieuwe instructieset-extensies ontworpen voor cryptografische applicaties.
De Core M-5Y10 biedt een erg groot Turbo-bereik van 0.8 - 2.0 GHz; we verwachten dat de eigenlijke frequentie vooral beperkt zal worden door het TDP. Terwijl de CPU vergelijkbaar is met een Core i5-4202Y (Haswell, 11.5W) bij korte, single-threaded benchmarks, kan de performance lager zijn bij aanhoudende belasting. Het hoofddoel van de hogere energie-efficiëntie van Broadwell is dan ook om het energieverbruik te verminderen in plaats van de ruwe rekenkracht te verhogen.
Over het algemeen zou de Core M-5Y70 toereikend moeten zijn voor office- en multimedia-doeleinden evenals meer veeleisende applicaties.
De geïntegreerde HD Graphics 5300 biedt 24 Execution Units (EU's) geklokt aan 100 - 850 MHz. Vergelijkbaar met de CPU core werd de GPU-architectuur (Intel Gen 8) grondig herzien voor verbeterde performance per MHz. De frequentie van de GPU zal echter ook vooral door het TDP beperkt worden, wat grotere performance-winsten ten opzichte van de oudere HD 4200 bij aanhoudende 3D-belasting in de weg staat. Huidige games van 2014 zouden speelbaar moeten zijn met lage instellingen en in XGA-resolutie.
Broadwell is de eerste chip van Intel met volledige ondersteuning voor DirectX 11.2 en OpenCL 1.3/2.0 en OpenGL 4.3. Video wordt doorgegeven via DisplayPort 1.2 of HDMI 1.4a. De nieuwe HDMI 2.0-standaard wordt echter nog niet officieel ondersteund.
Met een TDP van slechts 4.5W vraagt de Core M-5Y10 merkbaar minder energie dan de Haswell Y-serie (11.5W). De CPU kan zelfs in dunne tablets passief gekoeld worden.
Serie Intel Core M Codenaam Broadwell Serie: Core M Broadwell Intel Core M-5Y71 1.2 - 2.9 GHz 2 / 4 4 MB L3 Intel Core M-5Y51 1.1 - 2.6 GHz 2 / 4 4 MB L3 Intel Core M-5Y70 1.1 - 2.6 GHz 2 / 4 4 MB L3 Intel Core M-5Y31 0.9 - 2.4 GHz 2 / 4 4 MB L3 Intel Core M-5Y10c 0.8 - 2 GHz 2 / 4 4 MB L3 Intel Core M-5Y10a 0.8 - 2 GHz 2 / 4 4 MB L3 Intel Core M-5Y10 « 0.8 - 2 GHz 2 / 4 4 MB L3
Kloksnelheid 800 - 2000 MHz Level 1 Cache 128 KB Level 2 Cache 512 KB Level 3 Cache 4 MB Aantal Cores / Threads 2 / 4 Stroomverbruik (TDP = Thermal Design Power) 4.5 Watt Aantal Transistoren 1300 miljoen Productietechnologie 14 nm Chipgrootte 82 mm2 Max. Temperatuur 95 °C Socket BGA Features HD Graphics 5300 (100 - 800 MHz), Dual-Channel DDR3L(-RS)/LPDDR3 Memory Controller (max. 800 MHz, 25.6 GB/s), HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI GPU Intel HD Graphics 5300 (100 - 800 MHz)64-Bit 64-Bit-ondersteuning Architecture x86 Aankondigingsdatum 05-09-2014 Productlink (extern) Intel Core M 5Y10
Benchmarks Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 139 gem: 153.6 mediaan: 155 (2%) max: 167 Points
...
AMD E2-7110 -9%
Intel Celeron 3865U -8%
Intel Core M-5Y51 -3%
Intel Pentium N3540 1%
AMD A4-7210 2%
Intel Core M-5Y10c 3%
...
Intel Core i7-12800HX 2102%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 63 gem: 77.4 mediaan: 81 (25%) max: 82 Points
...
AMD A10-9600P -3%
AMD PRO A12-9800B -2%
Intel Celeron N6211 -2%
Intel Pentium 3825U -1%
Intel Core i5-4300Y -1%
AMD Ryzen 3 2300U 2%
...
Intel Core i9-12900HX 259%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.53 gem: 1.7 mediaan: 1.7 (2%) max: 1.8 Points
...
Intel Celeron N6211 -2%
Intel Core M-5Y51 -2%
Intel Celeron 3865U -1%
AMD Phenom II X2 N640 -1%
Intel Core M-5Y10c -1%
Intel Core i5-2537M -1%
Intel Pentium N3700 1%
Intel Pentium N3530 2%
AMD A4-6210 4%
...
Intel Core i9-12900HX 2367%
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.92 gem: 0.9 mediaan: 1 (3%) max: 0.95 Points
...
AMD A12-9720P -1%
Intel Core i3-5005U 0%
Intel Core i3-5010U 0%
Intel Core i5-4302Y 1%
Intel Celeron 2970M 2%
Intel Core M-5Y51 2%
Intel Core i3-5015U 3%
...
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2830 gem: 3053 mediaan: 3102 (25%) max: 3130 punten
...
Intel Pentium 3825U -3%
Intel Core i5-4300Y -2%
Intel Core i3-5010U 2%
...
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4964 gem: 5235 mediaan: 5217 (6%) max: 5625 punten
...
AMD A6-7310 -3%
AMD A8-7410 -3%
AMD A8-3500M -2%
AMD Phenom II X3 N850 -1%
Intel Core M-5Y51 0%
Intel Core i5-2537M 2%
...
Intel Core i9-12900HX 1134%
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
7072 Points (5%)
...
AMD A6-3420M -1%
Intel Core i3-350M -1%
AMD A6-3410MX 2%
Intel Core i3-2310M 4%
...
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
4159 Points (23%)
...
Intel Celeron N6211 -1%
Intel Core M-5Y51 0%
Intel Core i3-5010U 1%
Intel Core i7-2657M 5%
...
wPrime 2.10 - wPrime 2.0 1024m *
min: 1098 gem: 1117 mediaan: 1116.5 (13%) max: 1135 s
...
Intel Pentium P6100 -3%
AMD Athlon II P340 -1%
AMD Turion II M500 1%
AMD E2-9010 2%
Intel Core i5-4300Y 3%
...
VIA C3-M C3-M-1200 657%
wPrime 2.10 - wPrime 2.0 32m *
min: 25.64 gem: 30.9 mediaan: 30.9 (6%) max: 36.2 s
...
Intel Celeron N3150 -3%
Intel Atom x7-E3950 -2%
AMD Turion II N530 -2%
AMD Pro A10-8700B -1%
AMD Turion II Ultra M620 1%
...
Transmeta Crusoe TM-5800 1507%
min: 1926 gem: 1952 mediaan: 1951.5 (11%) max: 1977 punten
...
Intel Core i3-8145U -3%
Intel Core i3-7020U -2%
Intel Core i3-6100U -2%
Intel Core i5-6360U -1%
Intel Core i3-6100H 2%
Intel Core i3-5015U 4%
Intel Core M-5Y51 5%
Intel Core i5-7Y57 8%
...
X264 HD Benchmark 4.0 - x264 Pass 2
min: 8.7 gem: 9.6 mediaan: 9.6 (4%) max: 10.5 fps
AMD Athlon Neo MV-40 -80%
...
Intel Core M-5Y51 -4%
Intel Atom x7-E3950 -4%
Intel Celeron N2930 -3%
Intel Celeron N2940 -2%
Intel Core M-5Y31 -1%
AMD A8-7410 1%
AMD A4-6210 4%
Intel Celeron N6211 4%
...
Intel Core i9-12900HX 1832%
X264 HD Benchmark 4.0 - x264 Pass 1
min: 52.9 gem: 55.6 mediaan: 55.6 (13%) max: 58.3 fps
...
AMD A6-7310 -4%
Intel Pentium N3530 -3%
Intel Pentium N3540 -2%
Intel Celeron 3865U -2%
Intel Core M-5Y51 -1%
...
Intel Core i9-12900HX 464%
TrueCrypt - TrueCrypt Serpent
min: 0.105 gem: 0.1 mediaan: 0.1 (0%) max: 0.111 GB/s
...
Intel Atom x5-Z8500 -4%
AMD Pro A10-8700B -4%
Intel Core i5-4300Y -4%
Intel Pentium 3825U -4%
Intel Core M-5Y51 -2%
AMD A8-7410 2%
Intel Core i3-5005U 4%
Intel Core M-5Y31 5%
Intel Celeron N3150 6%
...
Intel Core i9-12900HX 1474%
TrueCrypt - TrueCrypt Twofish
min: 0.175 gem: 0.2 mediaan: 0.2 (0%) max: 0.194 GB/s
...
Intel Core M-5Y51 -4%
Intel Atom x7-E3950 -3%
Intel Celeron N3150 -3%
AMD A6-3420M -2%
Intel Celeron N2940 -2%
Intel Pentium 3825U -1%
Intel Celeron N2930 1%
Intel Core i5-4300Y 1%
Intel Core i3-5005U 4%
...
Intel Core i9-12900HX 1634%
TrueCrypt - TrueCrypt AES
min: 1.1 gem: 1.2 mediaan: 1.2 (0%) max: 1.2 GB/s
...
Intel Core M-5Y51 -4%
Intel Core i5-4300Y 4%
Intel Core i3-5015U 4%
Intel Core M-5Y31 4%
Intel Core i3-5005U 4%
...
Intel Core i9-12900HX 1413%
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1903 gem: 2066 mediaan: 1987 (4%) max: 2307 Points
...
Intel Core 2 Duo T7700 -1%
AMD Turion II P540 -1%
Intel Celeron N3150 -1%
Intel Core M-5Y51 3%
AMD Turion II N530 3%
...
Intel Core i9-12900HX 755%
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 19.08 gem: 22.1 mediaan: 22.1 (5%) max: 25.16 s
AMD Ryzen 7 PRO 6850H -96%
...
AMD Pro A8-8600B -2%
Intel Celeron N6211 -1%
Intel Core 2 Duo T7600 -1%
Intel Pentium 3558U 1%
...
VIA C3-M C3-M-1200 1993%
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 43.09 gem: 49.2 mediaan: 49.1 (2%) max: 55.2 s
Intel Core i7-11390H -70%
...
Intel Core 2 Quad Q9100 -2%
Intel Celeron N6211 -2%
Intel Celeron 3865U -2%
Intel Pentium 3558U 1%
Intel Pentium P6100 2%
...
Intel Celeron Dual-Core T1400 4661%
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 971 gem: 974 mediaan: 973.5 (4%) max: 976 s
...
Intel Core i3-5015U -2%
Intel Core i3-380M -2%
Intel Core i3-5005U -1%
Intel Core i3-2310M -1%
AMD A10-9620P 0%
Intel Core i3-370M 2%
Intel Core i5-2537M 2%
Intel Core M-5Y31 2%
AMD PRO A8-9600B 3%
...
VIA C3-M C3-M-1200 2211%
3DMark 11 - 3DM11 Performance Physics
min: 1895 gem: 2158 mediaan: 2171 (6%) max: 2480 Points
...
AMD PRO A8-9600B -4%
AMD A6-3400M -3%
Intel Core M-5Y51 -2%
AMD Pro A10-8700B -2%
AMD A8-3500M 2%
...
Intel Core i7-12800HX 937%
3DMark - 3DMark Ice Storm Physics
min: 18980 gem: 20947 mediaan: 20080 (13%) max: 24168 Points
...
Intel Core M-5Y51 -4%
Intel Pentium N3540 -3%
AMD E2-7110 -3%
Intel Celeron N4100 0%
AMD Pro A10-8700B 1%
AMD PRO A8-9600B 2%
Intel Core i5-8279U 3%
AMD A4-7210 3%
AMD A6-7310 4%
...
Intel Core i5-4300Y 642%
3DMark - 3DMark Cloud Gate Physics
min: 1628 gem: 1811 mediaan: 1838 (5%) max: 1980 Points
...
Intel Core M-5Y51 -4%
AMD E2-7110 -3%
Intel Pentium N3540 -2%
AMD Pro A10-8700B 3%
AMD A4-7210 6%
...
Intel Core i9-12950HX 1159%
3DMark - 3DMark Fire Strike Standard Physics
min: 2299 gem: 2558 mediaan: 2595 (5%) max: 2786 Points
...
AMD PRO A8-9600B -5%
Intel Core M-5Y51 -4%
AMD E2-7110 -3%
Intel Pentium N3530 3%
...
Intel Core i7-12800HX 1247%
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 3293 gem: 3775 mediaan: 3853.5 (7%) max: 4098 punten
...
Intel Pentium 3825U -6%
AMD A8-7410 -2%
Intel Core M-5Y31 1%
Intel Core i3-5005U 8%
AMD Pro A8-8600B 11%
...
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 1934 gem: 2003 mediaan: 2007.5 (39%) max: 2064 punten
...
Intel Core i3-5005U -4%
Intel Core i5-4300Y -4%
AMD PRO A8-9600B -2%
Intel Core i3-5015U -1%
AMD PRO A12-9800B 1%
AMD A10-9600P 3%
Intel Core M-5Y51 4%
Intel Core i3-5010U 8%
...
Intel Core i5-1230U 156%
Geekbench 2 - 32 Bit - Geekbench Stream
min: 4887 gem: 5598 mediaan: 5597.5 (45%) max: 6308 Points
AMD Athlon Neo MV-40 -79%
...
Intel Core i5-5300U -6%
Intel Core i7-5600U -6%
Intel Core i5-4310M -5%
Intel Celeron 3865U -4%
Intel Core i3-8145U 7%
Intel Core M-5Y51 8%
...
Intel Xeon E3-1535M v5 99%
Geekbench 2 - 32 Bit - Geekbench Memory
min: 4280 gem: 4465 mediaan: 4464.5 (40%) max: 4649 Points
...
Intel Core i3-5005U -8%
Intel Core M-5Y51 6%
Intel Celeron 3865U 8%
Intel Core i5-4210H 10%
...
Intel Core i7-8559U 124%
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 4272 gem: 4361 mediaan: 4361 (9%) max: 4450 Points
...
Intel Core i5-4300Y -11%
Intel Core M-5Y51 -7%
Intel Pentium 3825U -4%
AMD A8-3520M 2%
AMD A4-6210 4%
Intel Core i3-5005U 4%
AMD E2-7110 6%
...
Geekbench 2 - 32 Bit - Geekbench Integer
min: 4050 gem: 4111 mediaan: 4110.5 (8%) max: 4171 Points
AMD Athlon Neo MV-40 -72%
...
Intel Pentium 3825U -4%
Intel Core M-5Y51 -1%
Intel Core i3-5005U 2%
Intel Pentium N3540 3%
Intel Core i5-4300Y 4%
...
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 4362 gem: 4418 mediaan: 4417.5 (12%) max: 4473 Points
...
Intel Core i3-5005U -2%
Intel Core M-5Y51 -1%
Intel Core i5-4300Y 1%
AMD Pro A8-8600B 7%
...
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 3302 gem: 3365 mediaan: 3310 (4%) max: 3581 ms
...
Intel Celeron N4100 -7%
Intel Core i5-4302Y -7%
Intel Core i5-4300Y -3%
Intel Core i3-4012Y 4%
AMD Pro A8-8600B 14%
...
Sunspider - Sunspider 1.0 Total Score *
min: 157 gem: 168.9 mediaan: 166.9 (2%) max: 185.4 ms
...
Intel Core i5-4310U -2%
AMD PRO A12-9800B 1%
Intel Core i5-5250U 1%
Intel Core i9-8950HK 3%
Intel Core i3-5005U 3%
Intel Celeron 3865U 5%
...
Octane V2 - Octane V2 Total Score
min: 8474 gem: 9240 mediaan: 9354 (10%) max: 9622 Points
...
Intel Atom x5-Z8550 -13%
AMD E2-7110 -10%
AMD Pro A8-8600B -10%
Intel Pentium N3700 -6%
Intel Core i5-4302Y 6%
Intel Core i5-4300Y 10%
Intel Core M-5Y51 13%
AMD E2-9010 13%
Intel Core i3-4012Y 13%
...
Intel Core i9-12900HX 931%
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
v1.22
log 25. 10:53:57
#0 no ids found in url (should be separated by "_") +0s ... 0s
#1 not redirecting to Ajax server +0s ... 0s
#2 did not recreate cache, as it is less than 5 days old! Created at Wed, 25 Jan 2023 08:57:11 +0100 +0.001s ... 0.001s
#3 no comparison url found in template nbc.compare_page_2 needed +0.006s ... 0.007s
#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s
#9 composed specs +0s ... 0.008s
#10 did output specs +0s ... 0.008s
#11 getting avg benchmarks for device 6369 +0.002s ... 0.01s
#12 got single benchmarks 6369 +0.015s ... 0.024s
#13 got avg benchmarks for devices +0s ... 0.024s
#14 min, max, avg, median took s +0.39s ... 0.414s
#15 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.414s
#16 return log +0s ... 0.414s
Testrapporten voor de Intel Core M-5Y10 processor
Kort testrapport Asus Zenbook UX305 Subnotebook Slank. Hoe veel dunner kan je krijgen? De Core M is in allerbeste vorm, met slechts 12 millimeter in een luchtledige behuizing. De prestaties lopen wel wat acht...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 13.30" | 1.3 kg
Kort testrapport Dell Latitude 13 7350 Convertible Ultrabook Convertible. Dell’s Latitude 13 7350 is een mix van een Ultrabook, een tablet en een convertible. Deze combinatie van stille kracht, goede invoerappar...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 13.30" | 1.7 kg
Kort testrapport HP Envy x2 15-c000ng Convertible Fan-less. HP's 15.6 inch convertible wilt punten scoren met een efficiënte Broadwell processor van Intel, die een design zonder fan mogelijk maakt. Een Full HD ...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 15.60" | 2.5 kg
Asus UX305FA-FB041H : Intel HD Graphics 5300, 13.30", 1.2 kg
Extern testrapport » Asus UX305FA-FB041H
Asus Transformer Book T300FA-FE001H : Intel HD Graphics 5300, 12.50", 1.6 kg
Extern testrapport » Asus Transformer Book T300FA-FE001H
Asus Zenbook UX305FA-FC007H : Intel HD Graphics 5300, 13.30", 1.2 kg
Extern testrapport » Asus Zenbook UX305FA-FC007H
HP Envy x2 15-c000ng : Intel HD Graphics 5300, 15.60", 2.5 kg
Extern testrapport » HP Envy x2 15-c000ng
Asus Zenbook UX305FA-ASM1 : Intel HD Graphics 5300, 13.30", 1.3 kg
Extern testrapport » Asus Zenbook UX305FA-ASM1
Asus Zenbook UX305FA-FC008H : Intel HD Graphics 5300, 13.30", 1.2 kg
Extern testrapport » Asus Zenbook UX305FA-FC008H
HP Envy X2-j001nf : Intel HD Graphics 5300, 13.30", 1.8 kg
Extern testrapport » HP Envy X2-j001nf
Dell Latitude 13 7350 : Intel HD Graphics 5300, 13.30", 1.7 kg
Extern testrapport » Dell Latitude 13 7350
Asus ZenBook UX305FA-FB003H : Intel HD Graphics 5300, 13.30", 1.3 kg
Extern testrapport » Asus ZenBook UX305
Please share our article, every link counts!
.170
Andere CPU's van de serie Core M » Intel Core M-5Y51 2x 1.1 GHz - 2.6 GHz
» Intel Core M-5Y31 2x 0.9 GHz - 2.4 GHz
» Intel Core M-5Y10c 2x 0.8 GHz - 2 GHz
Omringende CPU's + AMD 3015Ce 2x 1.2 GHz - 2.3 GHz
+ Intel Core M-5Y10c 2x 0.8 GHz - 2 GHz
- AMD A9-9420e 2x - 2.5 GHz
Klaus Hinum (Update: 2014-12-10)
