Intel Pentium B960

Intel B960

De Intel Pentium B960 is een dual-core processor voor instapniveau notebooks. Deze is gebaseerd op de Sandy Bridge architectuur, maar vele eigenschappen zoals Turbo Boost voor de CPU, Hyper-Threading, AES, virtualisatie (VT-x en VT-d), Trusted Execution en Intel Quick Sync zijn gedeactiveerd. De Pentium B960 integreerd een grafische chip genaamd Intel HD Graphics die is gebaseerd op de HD Graphics 2000 met kloksnelheden van 650-1100 MHz (middels Turbo Boost).

De prestaties van de Pentium B960 zullen hoger moeten zijn dan gelijk geklokte Arrandale Pentium CPU's. De B960 zou dan ook vergelijkbaar moeten presteren met een Core i3-330M op 2.13 GHz, Hyper-Threadubg en 3MB L3 cache.

De 35 watt TDP is inclusief geïntegreerde GPU en geheugencontroller.

SerieIntel Pentium
CodenaamSandy Bridge

Serie: Pentium Sandy Bridge

Intel Pentium B9802.4 GHz2 / 2 cores2 MB L3
Intel Pentium B9702.3 GHz2 / 2 cores2 MB L3
Intel Pentium B960 « 2.2 GHz2 / 2 cores2 MB L3
Intel Pentium B9502.1 GHz2 / 2 cores2 MB L3
Intel Pentium B9402 GHz2 / 2 cores2 MB L3
Intel Pentium 9971.6 GHz2 / 2 cores2 MB L3
Intel Pentium 9871.5 GHz2 / 2 cores2 MB L3
Intel Pentium 9771.4 GHz2 / 2 cores2 MB L3
Intel Pentium 9671.3 GHz2 / 2 cores2 MB L3
Intel Pentium 9571.2 GHz2 / 2 cores2 MB L3
Kloksnelheid2200 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache2 MB
Aantal Cores / Threads2 / 2
Stroomverbruik (TDP = Thermal Design Power)35 Watt
Aantal Transistoren624 miljoen
Productietechnologie32 nm
Chipgrootte149 mm2
Max. Temperatuur85 °C
SocketrPGA988B
FeaturesHD Graphics, DDR3 Memory Controller
GPUIntel HD Graphics (Sandy Bridge) (650 - 1100 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum01-10-2011
Productlink (extern)Intel Pentium B960

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.45     gem: 1.6     mediaan: 1.7 (2%)     max: 1.7 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.9 Points (3%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2759     gem: 2838     mediaan: 2851 (23%)     max: 2869 punten
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 5019     gem: 5417     mediaan: 5500 (6%)     max: 5550 punten
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 6083     gem: 6648     mediaan: 6757.5 (5%)     max: 6815 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2563     gem: 3337     mediaan: 3521 (19%)     max: 3542 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 1025     gem: 1069     mediaan: 1061 (13%)     max: 1129 s
wPrime 2.10 - wPrime 2.0 32m *
min: 32.18     gem: 33.7     mediaan: 33.5 (7%)     max: 35.7 s
WinRAR - WinRAR 4.0
min: 1354     gem: 1367     mediaan: 1366.5 (8%)     max: 1379 punten
X264 HD Benchmark 4.0 - x264 Pass 2
9.2 fps (3%)
X264 HD Benchmark 4.0 - x264 Pass 1
51.7 fps (12%)
TrueCrypt - TrueCrypt Serpent
min: 0.074     gem: 0.1     mediaan: 0.1 (0%)     max: 0.0758 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.127     gem: 0.1     mediaan: 0.1 (0%)     max: 0.133 GB/s
TrueCrypt - TrueCrypt AES
min: 0.165     gem: 0.2     mediaan: 0.2 (0%)     max: 0.172 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2133     gem: 2215     mediaan: 2231 (5%)     max: 2248 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 17.97     gem: 18.3     mediaan: 18 (4%)     max: 18.93 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 40.64     gem: 41.6     mediaan: 41 (2%)     max: 43.78 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 917     gem: 937     mediaan: 937 (4%)     max: 958 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 24750     gem: 28587     mediaan: 27320 (13%)     max: 33690 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 15880     gem: 15893     mediaan: 15900 (12%)     max: 15900 MFLOPS
Windows 7 Experience Index - Win7 CPU
min: 6.1     gem: 6.4     mediaan: 6.1 (78%)     max: 7.6 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 4552     gem: 5131     mediaan: 5216.5 (5%)     max: 5409 Points
3DMark 11 - 3DM11 Performance Physics
2139 Points (6%)
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie

v1.22
log 23. 00:49:54

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Fri, 20 Jan 2023 08:57:08 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.006s ... 0.007s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#12 composed specs +0s ... 0.009s

#13 did output specs +0s ... 0.009s

#14 getting avg benchmarks for device 2988 +0.001s ... 0.01s

#15 got single benchmarks 2988 +0.022s ... 0.032s

#16 got avg benchmarks for devices +0s ... 0.033s

#17 min, max, avg, median took s +0.251s ... 0.284s

#18 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.284s

#19 return log +0s ... 0.284s

Testrapporten voor de Intel Pentium B960 processor

Acer Aspire E1-531-B964G50Mnks: Intel HD Graphics 2000, 15.60", 2.5 kg
  Extern testrapport » Acer Aspire E1-531-B964G50Mnks

Acer TravelMate P253-E-B9604G50Mnks: Intel HD Graphics 2000, 15.60", 2.6 kg
  Extern testrapport » Acer TravelMate P253-E-B9604G50Mnks

Lenovo G580-59371511: Intel HD Graphics 2000, 15.60", 2.4 kg
  Extern testrapport » Lenovo G580-59371511

Fujitsu LifeBook AH512-MPAB2PL: Intel HD Graphics 2000, 15.60", 2.4 kg
  Extern testrapport » Fujitsu LifeBook AH512-MPAB2PL

Lenovo IdeaPad G780-M842QGE: NVIDIA GeForce GT 630M, 17.30", 3 kg
  Extern testrapport » Lenovo IdeaPad G780-M842QGE

HP Pavilion g7-1301sm: AMD Radeon HD 7450M, 17.30", 3 kg
  Extern testrapport » HP Pavilion g7-1301sm

Acer Aspire E1-531-B9606G50Mnks: Intel HD Graphics (Sandy Bridge), 15.60", 2.5 kg
  Extern testrapport » Acer Apire E1-531-B9606G50Mnks

Lenovo IdeaPad G580-MBBG3GE: Intel HD Graphics (Sandy Bridge), 15.60", 2.6 kg
  Extern testrapport » Lenovo IdeaPad G580-MBBG3GE

Packard Bell EasyNote TV: Intel Graphics Media Accelerator (GMA) HD Graphics, 15.60", 2.6 kg
  Extern testrapport » Packard Bell EasyNote TV

HP Pavilion g6-2041SF: AMD Radeon HD 7670M, 15.60", 2.5 kg
  Extern testrapport » HP Pavilion g6-2041SF

Toshiba Satellite C855-12X: AMD Radeon HD 7610M, 15.60", 2.3 kg
  Extern testrapport » Toshiba Satellite C855-12X

Fujitsu Lifebook A531-0MRKA2PL: Intel Graphics Media Accelerator (GMA) HD Graphics, 15.60", 2.5 kg
  Extern testrapport » Fujitsu Lifebook A531-0MRKA2PL

Sony VAIO VPC-EH3S6E H3S6E: NVIDIA GeForce 410M, 15.60", 2.4 kg
  Extern testrapport » Sony VAIO VPC-EH3S6E H3S6E

Lenovo IdeaPad G570-59-325775: Intel HD Graphics 2000, 15.60", 2.6 kg
  Extern testrapport » Lenovo IdeaPad G570-59-325775
