Apple M1 Max
De Apple M1 Max is een System on a Chip (SoC) van Apple dat wordt aangetroffen in de MacBook Pro 14- en 16-inch modellen van eind 2021. Het biedt alle 10 beschikbare cores van de chip, verdeeld in acht prestatie-kernen (P-cores met 600 - 3220 MHz) en twee energiezuinige cores (E-cores met 600 - 2064 MHz). Er is geen Turbo Boost voor afzonderlijke cores of korte burstperioden. De cores zijn vergelijkbaar met de cores in de Apple M1.
De grote cores (codenaam Firestorm) bieden 192 KB instructie cache, 128 KB data cache en 24 MB gedeelde L2 cache (tegenover 12 MB in de M1). De vier efficiënte kernen (codenaam Icestorm) zijn een stuk kleiner en bieden slechts 128 KB instructie-cache, 64 KB data-cache en 4 MB gedeelde cache. CPU en GPU kunnen beide gebruik maken van de 48 MB SLC (System Level Cache). De efficiency cores (E cluster) klokken met 600 - 2064 MHz, de performance cores (P cluster) met 600 - 3228 MHz.
Het verenigd geheugen (32 of 64 GB LPDDR5-6400) naast de chip wordt verbonden door een 512 bit geheugencontroller (200 GB/s bandbreedte) en kan worden gebruikt door de GPU en de CPU. Dit is het belangrijkste verschil met de M1 Pro en de CPU prestaties zijn redelijk vergelijkbaar.
Het grootste verschil met de M1 Pro is de grotere geïntegreerde GPU met 24 of 32 kernen (in plaats van 16).
Verder integreert de SoC een snelle 16 core neural engine, een secure enclave (bijvoorbeeld voor encryptie), een unified memory architectuur, Thunderbolt 4 controller, een ISP, en media de- en encoders (waaronder twee ProRes engines).
De M1 Pro is vervaardigd in 5 nm bij TSMC en bevat 57 miljard transistors. Het piekverbruik van de chip werd geadverteerd rond 30 W voor CPU-intensieve taken.
Serie Apple Apple M-Series Serie: Apple M-Series Apple M2 Max 2.42 - 3.48 GHz 12 / 12 48 MB L3 Apple M2 Pro 2.42 - 3.48 GHz 12 / 12 24 MB L3 Apple M1 Max « 2.06 - 3.22 GHz 10 / 10 48 MB L3 Apple M1 Pro 2.06 - 3.22 GHz 10 / 10 24 MB L3 Apple M2 Pro 10-Core 2.42 - 3.48 GHz 10 / 10 24 MB L3 Apple M1 Pro 8-Core 2.06 - 3.22 GHz 8 / 8 16 MB L3 Apple M2 2.42 - 3.48 GHz 8 / 8 8 MB L3 Apple M1 2.06 - 3.22 GHz 8 / 8 8 MB L3
Kloksnelheid 2060 - 3220 MHz Level 1 Cache 2.9 MB Level 2 Cache 28 MB Level 3 Cache 48 MB Aantal Cores / Threads 10 / 10 Aantal Transistoren 57000 miljoen Productietechnologie 5 nm Features ARMv8 Instruction Set GPU Apple M1 Max 32-Core GPU 64-Bit 64-Bit-ondersteuning Architecture ARM Aankondigingsdatum 18-10-2021
Benchmarks Cinebench R23 - Cinebench R23 Multi Core
min: 12385 gem: 12389 mediaan: 12386 (20%) max: 12396 Points
...
AMD Ryzen 9 PRO 6950HS -7%
AMD Ryzen 7 PRO 6860Z -5%
AMD Ryzen 7 PRO 6850H -3%
AMD Ryzen 9 5980HS 2%
...
Intel Core i9-13980HX 145%
Cinebench R23 - Cinebench R23 Single Core
min: 1530 gem: 1533 mediaan: 1533 (67%) max: 1536 Points
...
Apple M1 -1%
AMD Ryzen 9 PRO 6950HS -1%
AMD Ryzen 9 5980HS 0%
Intel Core i7-1260U 0%
Intel Core i7-1250U 2%
...
Intel Core i9-12900HX 25%
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 390 gem: 393.3 mediaan: 395 (45%) max: 395 Points
...
Intel Core i7-6567U -7%
Intel Core i7-7700HQ -6%
Intel Core i5-8259U -4%
Intel Core i5-8265U -1%
Intel Core i5-8260U 2%
Apple M1 2%
Intel Core i7-8809G 3%
Intel Core i5-1035G4 4%
...
Intel Core i9-12900HX 88%
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 2735 gem: 2746 mediaan: 2750 (12%) max: 2753 Points
...
Intel Core i7-9750H -7%
Intel Core i9-8950HK -3%
Intel Xeon E-2276M 1%
Intel Core i7-1265U 3%
Intel Core i7-1260U 3%
Intel Core i7-1250U 5%
...
Intel Core i7-12800HX 212%
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 1689 gem: 1691 mediaan: 1691 (17%) max: 1693 Points
...
AMD Ryzen 5 6600HS -2%
Intel Xeon W-2145 -1%
AMD Ryzen 7 4800HS 1%
...
Intel Core i7-12800HX 100%
0 85 170 255 340 425 510 595 680 765 850 935 1020 1105 1190 1275 1360 1445 1530 1615 Tooltip Apple MacBook Pro 14 2021 M1 Max 24-Core GPU Rosetta 2: Ø1684 (1672.66-1688.19)
Apple Mac Studio 2022 M1 Max: Ø1691 (1678.91-1695.2)
Apple MacBook Pro 16 2021 M1 Max Rosetta 2: Ø1687 (1667.29-1693.05)
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 197 gem: 202.3 mediaan: 200 (61%) max: 210 Points
...
Intel Xeon E-2276M -4%
Intel Core i9-8950HK -3%
Intel Core i5-1230U 1%
Apple M1 2%
...
Intel Core i9-12900HX 37%
Blender - Blender 2.79 BMW27 CPU *
min: 187 gem: 188.7 mediaan: 189 (1%) max: 190 Seconds
Intel Core i5-1038NG7 -98%
Intel Core i7-12800HX -19%
Intel Core i9-12900HX -18%
Intel Core i9-12950HX -8%
Intel Core i7-12850HX 2%
AMD Ryzen 7 PRO 6850H 25%
...
Geekbench 5.4 - Geekbench 5.1 - 5.4 64 Bit Single-Core
min: 1764 gem: 1780 mediaan: 1782 (77%) max: 1795 punten
...
Intel Core i7-1265U -3%
Apple M1 -3%
Intel Core i7-12800HX -1%
Intel Core i7-12850HX 0%
Intel Core i9-12950HX 5%
Intel Core i9-12900HX 7%
Apple M2 7%
Geekbench 5.4 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
min: 12563 gem: 12656 mediaan: 12697 (44%) max: 12708 punten
...
Intel Core i7-1370P -20%
Intel Core i7-12850HX -3%
Intel Core i7-12800HX 12%
Intel Core i9-12950HX 20%
Intel Core i9-12900HX 28%
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 404.3 gem: 459.2 mediaan: 482.3 (1%) max: 491.1 ms
Apple M2 -1%
Apple M1 3%
Intel Core i9-12900HX 7%
Intel Core i9-12950HX 9%
Intel Core i7-12800HX 13%
Intel Core i7-12850HX 14%
...
Octane V2 - Octane V2 Total Score
min: 66938 gem: 68647 mediaan: 68029 (70%) max: 70973 Points
...
AMD Ryzen 9 5980HS -3%
AMD Ryzen 7 PRO 6860Z 7%
Apple M2 7%
...
Intel Core i9-12900HX 39%
WebXPRT 3 - WebXPRT 3 Score
min: 350 gem: 358.7 mediaan: 360 (91%) max: 366 Points
...
Intel Core i7-12800HX -14%
Intel Core i9-12950HX -13%
Intel Core i9-12900HX -12%
Apple M2 1%
...
CrossMark - CrossMark Overall
min: 1586 gem: 1607 mediaan: 1615 (62%) max: 1621 Points
...
Apple M2 -4%
Intel Core i7-1265U -3%
Intel Core i5-1245U -2%
Intel Core i7-12850HX 0%
...
Intel Core i9-12900HX 34%
Power Consumption - Prime95 Power Consumption - external Monitor *
50.8 Watt (9%)
...
Intel Core i7-11390H 5%
Intel Core i5-1245U 9%
AMD Ryzen 5 6600HS 15%
...
Intel Core i7-12800HX 249%
0 5 10 15 20 25 30 35 40 45 50 55 60 65 Tooltip Apple MacBook Pro 14 2021 M1 Max 24-Core GPU: Ø50.8 (39.5-65.7)
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
53 Watt (11%)
...
Intel Core i7-1265U -8%
AMD Ryzen 5 PRO 6650U -6%
Intel Core i7-6700HQ -1%
...
Intel Core i9-12950HX 275%
0 5 10 15 20 25 30 35 40 45 50 55 Tooltip Apple MacBook Pro 14 2021 M1 Max 24-Core GPU: Ø53 (49.7-57.1)
Power Consumption - Idle Power Consumption - external Monitor *
11.6 Watt (11%)
...
AMD Ryzen 7 PRO 6850H -13%
Intel Core i5-1245U 11%
Intel Core i9-12950HX 90%
Intel Core i9-12900HX 121%
...
0 1 2 3 4 5 6 7 8 9 10 11 12 Tooltip Apple Mac Studio 2022 M1 Max: Ø11.6 (11.4-12)
Power Consumption - Cinebench R15 Multi Power Efficiency - external Monitor
31.9 Points per Watt (37%)
...
Intel Core i7-1260U -9%
AMD Ryzen 9 PRO 6950HS -7%
AMD Ryzen 5 PRO 6650U -6%
Intel Core i7-1250U -5%
AMD Ryzen 7 PRO 6860Z 0%
...
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
