Kort testrapport Dell XPS 13 9360 QHD+ i5-7200U Notebook

Klaus Hinum, J. Simon Leitner, 01-10-2016

Kleine update, geen effect?! Dell heeft stiekem hun topmodel aangepast: De XPS 13 is één van de eerste modellen die uitgerust wordt met de Kaby Lake processoren van Intel. De behuizing lijkt onaangetast, net zoals het beeldscherm. We hebben het apparaat opnieuw getest en zullen het artikel continu blijven updaten.

Dell XPS 13 9360 QHD+ i5 (XPS 13 9360 Serie)
Processor
Intel Core i5-7200U
Grafische kaart
Intel HD Graphics 620
Geheugen
8192 MB
, DDR4 Dual-Channel
Beeldscherm
13.3 inch 16:9, 3200 x 1800 pixel 276 PPI, Sharp SHP144A
Moederbord
Intel Kaby Lake-U Premium PCH
Opslag
Toshiba NVMe THNSN5256GPUK, 256 GB
, NVMe, 198 GB beschikbaar
Geluidskaart
Intel Kaby Lake-U/Y PCH - High Definition Audio
Netwerkmogelijkheden
Killer Wireless-n/a/ac 1535 Wireless Network Adapter (b/g/n/ac)
Afmetingen
hoogte x breedte x diepte (in mm): 15 x 304 x 201
Batterij
60 Wh, 8085 mAh, 7.6V PW23Y
Besturingssysteem
Microsoft Windows 10 Home 64 Bit
Bijkomende functionaliteiten
McAfee Antivirus, 12 Maanden Garantie
Released
29-09-2016
Gewicht
1.313 kg, Voeding: 263 g
Prijs
1299 Euro
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.



Size Comparison

Networking
iperf3 Client (receive) TCP 1 m 4M x10
Apple MacBook Pro Retina 13 inch 2013-10
Broadcom 802.11ac (Klaus I211)
762 MBit/s ∼100% +13%
Dell XPS 13 9360 QHD+ i5
Killer Wireless-n/a/ac 1535 Wireless Network Adapter
676 MBit/s ∼89%
MSI GT72S-6QEG16SR421BW
Killer Wireless-n/a/ac 1535 Wireless Network Adapter (Klaus I211)
664 MBit/s ∼87% -2%
Lenovo ThinkPad T460s-20FA003GGE
Intel Dual Band Wireless-AC 8260
637 MBit/s ∼84% -6%
Microsoft Surface Pro 4, Core i5, 128GB
Marvell AVASTAR Wireless-AC Network Controller (Klaus I211)
459 MBit/s ∼60% -32%
Intel NUC5i5RYH
Intel Dual Band Wireless-AC 7265 (Klaus I211)
443 MBit/s ∼58% -34%
MSI PE60 2QD
Intel Dual Band Wireless-AC 3165
236 MBit/s ∼31% -65%
iperf3 Client (transmit) TCP 1 m 4M x10
Apple MacBook Pro Retina 13 inch 2013-10
Broadcom 802.11ac (Klaus I211)
768 MBit/s ∼100% +13%
Dell XPS 13 9360 QHD+ i5
Killer Wireless-n/a/ac 1535 Wireless Network Adapter
680 MBit/s ∼89%
MSI GT72S-6QEG16SR421BW
Killer Wireless-n/a/ac 1535 Wireless Network Adapter (Klaus I211)
625 MBit/s ∼81% -8%
Microsoft Surface Pro 4, Core i5, 128GB
Marvell AVASTAR Wireless-AC Network Controller (Klaus I211)
593 MBit/s ∼77% -13%
Intel NUC5i5RYH
Intel Dual Band Wireless-AC 7265 (Klaus I211)
549 MBit/s ∼71% -19%
Lenovo ThinkPad T460s-20FA003GGE
Intel Dual Band Wireless-AC 8260
534 MBit/s ∼70% -21%
MSI PE60 2QD
Intel Dual Band Wireless-AC 3165
322 MBit/s ∼42% -53%
366
cd/m²
375
cd/m²
390
cd/m²
387
cd/m²
444
cd/m²
397
cd/m²
371
cd/m²
415
cd/m²
390
cd/m²
Helderheidsverdeling
X-Rite i1Pro 2
Maximum: 444 cd/m² Gemiddelde: 392.8 cd/m² Minimum: 18 cd/m²
Helderheidsverdeling: 82 %
Helderheid in Batterij-modus: 444 cd/m²
Contrast: 1345:1 (Zwart: 0.33 cd/m²)
ΔE Color 4 | 0.4-29.43 Ø6.2
ΔE Greyscale 2.83 | 0.64-98 Ø6.5
91.4% sRGB (Argyll 3D) 59.3% AdobeRGB 1998 (Argyll 3D)
Gamma: 2.05
Cinebench R15
CPU Single 64Bit
MSI CX72-7QL
Intel Core i7-7500U
145 Points ∼100% +24%
Dell XPS 13 2016 9350 (FHD, i7-6560U)
Intel Core i7-6560U
133 Points ∼92% +14%
Acer Aspire E5-575G-549D
Intel Core i5-7200U
129 Points ∼89% +10%
Dell XPS 13 9360 QHD+ i5
Intel Core i5-7200U
117 Points ∼81%
Dell XPS 13-9350
Intel Core i5-6200U
116 Points ∼80% -1%
CPU Multi 64Bit
MSI CX72-7QL
Intel Core i7-7500U
363 Points ∼100% +21%
Acer Aspire E5-575G-549D
Intel Core i5-7200U
331 Points ∼91% +10%
Dell XPS 13 2016 9350 (FHD, i7-6560U)
Intel Core i7-6560U
314 Points ∼87% +5%
Dell XPS 13 9360 QHD+ i5
Intel Core i5-7200U
300 Points ∼83%
Dell XPS 13-9350
Intel Core i5-6200U
287 Points ∼79% -4%
Cinebench R11.5 CPU Multi 64Bit
3.39 Points
Cinebench R11.5 OpenGL 64Bit
32.59 fps
Cinebench R11.5 CPU Single 64Bit
1.43 Points
Cinebench R15 CPU Multi 64Bit
300 Points
Cinebench R15 CPU Single 64Bit
117 Points
Cinebench R15 OpenGL 64Bit
41.3 fps
Cinebench R15 Ref. Match 64Bit
97.7 %
Help
PCMark 8 - Home Score Accelerated v2
HP Spectre 13
HD Graphics 520, 6500U, Samsung PM951 NVMe MZVLV256
3549 Points ∼58% +29%
Dell XPS 13 2016 9350 (FHD, i7-6560U)
Iris Graphics 540, 6560U, Samsung PM951 NVMe MZ-VLV256D
3479 Points ∼57% +26%
Acer Aspire S 13 S5-371-71QZ
HD Graphics 520, 6500U, LiteOn CV1-8B512
3386 Points ∼56% +23%
Acer Aspire E5-575G-549D
GeForce GTX 950M, 7200U, Toshiba MQ01ABD100
3162 Points ∼52% +15%
Dell XPS 13-9350
HD Graphics 520, 6200U, Samsung PM951 NVMe MZ-VLV256D
2983 Points ∼49% +8%
Dell XPS 13 9360 QHD+ i5
HD Graphics 620, 7200U, Toshiba NVMe THNSN5256GPUK
2761 Points ∼45%
Apple MacBook 12 (Early 2016) 1.1 GHz
HD Graphics 515, 6Y30, Apple SSD AP0256
2550 Points ∼42% -8%
PCMark 8 Home Score Accelerated v2
2761 punten
Help
Toshiba NVMe THNSN5256GPUK
Sequential Read: 1168 MB/s
Sequential Write: 329 MB/s
512K Read: 1015 MB/s
512K Write: 307 MB/s
4K Read: 33 MB/s
4K Write: 132 MB/s
4K QD32 Read: 525 MB/s
4K QD32 Write: 325 MB/s
3DMark 11 - 1280x720 Performance GPU
Dell XPS 13 2016 9350 (FHD, i7-6560U)
Intel Iris Graphics 540, Intel Core i7-6560U
1947 Points ∼100% +26%
MSI CX72-7QL
Intel HD Graphics 620, Intel Core i7-7500U
1668 Points ∼86% +8%
Dell XPS 13 9360 QHD+ i5
Intel HD Graphics 620, Intel Core i5-7200U
1541 Points ∼79%
HP Spectre 13
Intel HD Graphics 520, Intel Core i7-6500U
1487 Points ∼76% -4%
Acer Aspire S 13 S5-371-71QZ
Intel HD Graphics 520, Intel Core i7-6500U
1428 Points ∼73% -7%
Dell XPS 13-9350
Intel HD Graphics 520, Intel Core i5-6200U
1398 Points ∼72% -9%
3DMark 2001SE Standard
67477 punten
3DMark 11 Performance
1683 punten
3DMark Cloud Gate Standard Score
5778 punten
3DMark Fire Strike Score
848 punten
Help
lage gem. hoge ultra
World of Warcraft (2005) 4810.1fps
Diablo III (2012) 3028.6fps
BioShock Infinite (2013) 50.530.325.58.2fps
The Witcher 3 (2015) 12.7fps
World of Warships (2015) 5839.720.5fps
Rainbow Six Siege (2015) 35.622.412.1fps
Rise of the Tomb Raider (2016) 17.4fps
Far Cry Primal (2016) 168fps
Overwatch (2016) 40.13013.9fps

Geluidsniveau

Onbelast
30.6 / 30.6 / 32.2 dB (A)
Belasting
32.2 / 38.5 dB (A)
  red to green bar


30 dB
stil
40 dB(A)
hoorbaar
50 dB(A)
luid

min: dark, med: mid, max: light   Audix TM1, Arta (15 cm afstand)   environment noise: 30.3 dB(A)
dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2039.941.141.840.72533.534.934.234.23131.434.43433.34036.335.235.635.55033.331.532.733.76334.63431.131.38029.729.229.828.910027.627.427.126.912527.526.426.426.716024.524.326.225.22002423.42524.72502422.925.523.331523.922.325.823.140023.521.52823.750022.120.628.320.863020.919.523.919.980020.819.224.918.9100019.919.225.118.5125020.918.226.618.1160021.31828.318200020.617.729.817.6250019.617.729.917.4315021.217.627.317.5400018.417.625.717.6500017.717.62117.5630017.817.819.517.5800017.717.618.217.61000017.917.817.917.61250017.917.717.917.51600017.817.717.817.7SPL32.330.738.530.7N1.81.52.91.5median 20.9median 18.2median 25.7median 18.1Delta2.92.32.32.5hearing rangehide median Fan NoiseDell XPS 13 9360 QHD+ i5
Max. Belasting
 39 °C40 °C34 °C
 35 °C35 °C29 °C
 30 °C28 °C27 °C
Maximum: 40 °C
Gemiddelde: 33 °C
36 °C42 °C39 °C
30 °C34 °C34 °C
29 °C30 °C31 °C
Maximum: 42 °C
Gemiddelde: 33.9 °C
Stroomadapter (max.)  45 °C | Kamertemperatuur 21.4 °C | Fluke 62 Mini
(±) The average temperature for the upper side under maximal load is 33 °C / 91 F, compared to the average of 30.7 °C / 87 F for the devices in the class Subnotebook.
(±) The maximum temperature on the upper side is 40 °C / 104 F, compared to the average of 35.9 °C / 97 F, ranging from 22 to 57 °C for the class Subnotebook.
(±) The bottom heats up to a maximum of 42 °C / 108 F, compared to the average of 40.3 °C / 105 F
(+) In idle usage, the average temperature for the upper side is 26.2 °C / 79 F, compared to the device average of 30.7 °C / 87 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 30 °C / 86 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 28.7 °C / 83.7 F (-1.3 °C / -2.3 F).
Dell XPS 13 9360 (7200U)Dell XPS 13 9350 (6200U)Dell XPS 13 9350 (6560U)Acer Aspire S 13 S5-371-71QZLenovo IdeaPad 710S-13ISK
Heat
-8%
-16%
1%
-7%
Maximum Upper Side *
40
45.2
-13%
45
-13%
38.5
4%
42
-5%
Maximum Bottom *
42
45.2
-8%
50
-19%
47.7
-14%
37.5
11%
Idle Upper Side *
28
30.4
-9%
27.2
3%
34.8
-24%
Idle Bottom *
31
31.2
-1%
27.4
12%
33.4
-8%

* ... kleiner is beter

dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2032.635.82529.932.33131.631.24034.334.25032.534.46330.132.98027.634.410026.244.112526.15416024.848.920024.257.425022.958.331522.162.440021.364.550019.963.763019.268.780019.167.7100018.669.4125018.571.3160017.668.7200017.471.5250017.668.3315017.558.6400017.563.8500017.566.1630017.760.5800017.764.51000017.859.51250017.555.61600017.747.2SPL30.579.4N1.546.1median 18.5median 63.7Delta2.45.735.335.132.931.831.83236.535.132.428.93328.936.328.848.32761.52752.924.860.92462.822.763.32269.521.267.82174.82075.919.472.718.97117.770.117.86917.671.817.668.117.671.417.673.717.670.417.571.617.671.617.669.617.459.717.583.630.662.51.5median 69.6median 17.84.62.434.334.53432.630.833.334.534.633.635.132.232.634.329.136.228.348.128.841.525.954.724.650.423.857.223.468.222.569.621.871.220.968.719.876.519.372.71976.618.673.318.272.117.964.91867.417.870.517.869.91864.21858.817.959.517.952.617.983.731.257.11.6median 67.4median 198.23hearing rangehide median Pink NoiseDell XPS 13 9360 QHD+ i5Apple MacBook 12 (Early 2016) 1.1 GHzDell XPS 13 2016 9350 (FHD, i7-6560U)
Dell XPS 13 9360 QHD+ i5 audio analysis

(±) | speaker loudness is average but good (79.4 dB)
Bass 100 - 315 Hz
(±) | reduced bass - on average 9.5% lower than median
(±) | linearity of bass is average (14% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 4.5% away from median
(+) | mids are linear (5% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 2.9% away from median
(±) | linearity of highs is average (11% delta to prev. frequency)
Overall 100 - 16.000 Hz
(+) | overall sound is linear (13.2% difference to median)
Compared to same class
» 15% of all tested devices in this class were better, 3% similar, 82% worse
» The best had a delta of 8%, average was 19%, worst was 50%
Compared to all devices tested
» 10% of all tested devices were better, 3% similar, 88% worse
» The best had a delta of 3%, average was 21%, worst was 53%

Apple MacBook 12 (Early 2016) 1.1 GHz audio analysis

(+) | speakers can play relatively loud (83.6 dB)
Bass 100 - 315 Hz
(±) | reduced bass - on average 11.3% lower than median
(±) | linearity of bass is average (14.2% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 2.4% away from median
(+) | mids are linear (5.5% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 2% away from median
(+) | highs are linear (4.5% delta to prev. frequency)
Overall 100 - 16.000 Hz
(+) | overall sound is linear (9.3% difference to median)
Compared to same class
» 2% of all tested devices in this class were better, 2% similar, 96% worse
» The best had a delta of 8%, average was 19%, worst was 50%
Compared to all devices tested
» 2% of all tested devices were better, 1% similar, 98% worse
» The best had a delta of 3%, average was 21%, worst was 53%

Dell XPS 13 2016 9350 (FHD, i7-6560U) audio analysis

(+) | speakers can play relatively loud (83.8 dB)
Bass 100 - 315 Hz
(-) | nearly no bass - on average 19.4% lower than median
(-) | bass is not linear (15.4% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 4.7% away from median
(±) | linearity of mids is average (9.1% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 3.5% away from median
(±) | linearity of highs is average (7.6% delta to prev. frequency)
Overall 100 - 16.000 Hz
(±) | linearity of overall sound is average (18.1% difference to median)
Compared to same class
» 52% of all tested devices in this class were better, 7% similar, 41% worse
» The best had a delta of 8%, average was 19%, worst was 50%
Compared to all devices tested
» 31% of all tested devices were better, 6% similar, 62% worse
» The best had a delta of 3%, average was 21%, worst was 53%

Voorlopige samenvatting

Getest: Dell XPS 13 9360 met 4K display en Intel i5-7200U Kaby Lake CPU
Getest: Dell XPS 13 9360 met 4K display en Intel i5-7200U Kaby Lake CPU

Voor het originele, Engelse testrapport, klik hier.

Onze initiële resultaten en indrukken zijn teleurstellend: de ventilator draait bijna constant, zelfs zonder noemenswaardige CPU belasting. Ons testmodel heeft ook last van een zoemend geluid, wat vaker voorkomt bij XPS 13 modellen.

Dit is echter niet alle kritiek. Onze eerste CPU benchmarks met Cinebench R15 laten resultaten zien die niet tippen aan onze verwachtingen van de Kaby Lake update. Ons model met de i5-7200U CPU presteert even goed als de voorgaande i5-6200U processor, terwijl andere notebooks met de nieuwe 7200U chip over het algemeen 10% sneller zijn. De nieuwe Intel HD Graphics 620 kan ook niet z'n volledige potentie waarmaken en blijft achter op concurrenten met dezelfde GPU.

We zullen dit artikel de komende tijd bijwerken.
