NVIDIA GeForce Go 6150

NVIDIA GeForce Go 6150

NVIDIA GeForce Go 6100 / 6150 is de naam van de geïntegreerde grafische kaart van NVIDIA. De nForce Go 430 MCP voor de AMD Turion laptops. Deze heeft geen eigen geïntegreerd geheugen, maar gebruikt het algemene geheugen (tot 128 MB) net als de concurrent Intel GMA 950. Daarom zijn de prestaties van games matig en is deze slechts geschikt voor oude games (maar wel beter dan de geïntegreerde concurrent van Intel en ATI / AMD).

FabrikantNVIDIA
GeForce Go 6000 Series

GeForce Go 6800 Ultra 12/5@450MHz

GeForce Go 6800 12/5@300MHz

GeForce Go 6600 8/4@375MHz

GeForce Go 6400 4/3@400MHz

GeForce Go 6250 4/3@400MHz

GeForce Go 6200 4/3@300MHz

GeForce Go 6150 2/1@425MHz

GeForce Go 6100 2/1@425MHz

CodenaamC51MV
Pipelines2 / 1 Pixel- / Vertexshader
Core Snelheid *425 MHz
Shader snelheid *425 MHz
Geheugen Typeshared Memory
Gedeeld Geheugenja
Turbocache bis 128MB
DirectXDirectX 9c, Shader 3.0
technologie110 nm
FaciliteitenPureVideo, HD TV encoder, Windows Vista Premium
Aangekondigde datum01.02.2006
Informatie110nm, geïntegreerde grafische kaart (NVIDIA nForce Go 430 MCP chipset)
Link naar fabrikanthttp://www.nvidia.com/page/nb_chipset.html
* De gespecificeerde kloksnelheden zijn slechts richtlijnen van de fabrikant en kunnen door hen gewijzigd zijn.

Benchmarks

3DMark 06
0% 100%
min: 200     avg: 213 (1%)     max: 225 Points
3DMark 05 - Standard 1024x768
0% 100%
min: 602     avg: 630.7 (2%)     max: 660 Points
...
GeForce Go 6150
PowerVR SGX545 16%
Graphics Media Accelerator (GMA) 3650 43%
Radeon HD 6250 316%
Radeon HD 7310 400%
Radeon HD 6320 581%
Radeon HD 7340 606%
...
Radeon HD 7970M Crossfire 5747%
0%
100%
3DMark 03 - Standard 1024x768
0% 100%
min: 1055     avg: 1138.3 (1%)     max: 1200 Points
3DMark 2001SE - Standard 1024x768
0% 100%
min: 3519     avg: 4243 (7%)     max: 5210 Points
Cinebench R10 - Shading 32Bit
0% 100%
min: 867     avg: 867 (8%)     max: 867 Points
- Benchmark resultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

F.E.A.R.
F.E.A.R. (2005)
laag:
73  fps      Compare
gemiddeld:
6  fps      Compare
hoog:
1  fps      Compare
» Met alle geteste laptops speelbaar op laag details.
World of Warcraft (2005): Niet speelbaar met een zwakkere videokaart. - meer...
Quake 3 Arena - Timedemo
Quake 3 Arena - Timedemo (1999)
hoog:
75.4  fps      Compare
» Met alle geteste laptops speelbaar op hoog details.

Voor meer games die mogelijk speelbaar zijn of voor een lijst van alle games en videokaarten, bezoek onze Gaming List

Laptop testrapporten met NVIDIA GeForce Go 6150 grafische kaart

Asus F3M: AMD Turion 64 X2 TL-52, 15.4", 2.8 kg
  Extern testrapport » Asus F3M

HP Compaq Presario F560US: AMD Mobile Sempron 3500+, 15.4", 3.1 kg
  Extern testrapport » HP Compaq Presario F560US

HP Pavilion dv6700t: AMD Turion 64 X2 TL-66, 12.1", 2 kg
  Extern testrapport » HP Pavilion dv6700t

HP Pavilion tx1150ea: AMD Turion 64 X2 TL-60, 12.1", 1.9 kg
  Extern testrapport » HP Pavilion tx1150ea

HP Pavilion tx1250eg: AMD Turion 64 X2 TL-60, 12.1", 1.9 kg
  Extern testrapport » HP Pavilion tx1250eg

HP Pavilion tx2000z: AMD Turion 64 X2 TL-66, 12.1", 2.4 kg
  Extern testrapport » HP Pavilion tx2000z

HP Pavilion tx2050ea: AMD Turion 64 X2 TL-60, 12.1", 2.4 kg
  Extern testrapport » HP Pavilion tx2050ea

HP Pavilion tx2130ea: AMD Turion 64 X2 TL-60, 12.1", 1.9 kg
  Extern testrapport » HP Pavilion tx2130

HP Pavilion tx2140: AMD Turion 64 X2 TL-64, 12.1", 1.9 kg
  Extern testrapport » HP Pavilion tx2140
