Intel Core i5-3320M

Intel 3320M

Waarschuwing: De volgende informatie is gebaseerd op geruchten en gelekte informatie aangezien de CPU nog aangekondigd moet worden.

De Core i5-3320M is een snelle dual-core processor voor laptops die gebaseerd is op de Ivy Bridge architectuur. Vanwege de Hyperthreading technologie kunnen de twee cores samen tot vier threads parallel uitvoeren wat tot een beter gebruik van de CPU leidt. Elke core heeft een basiskloksnelheid van 2.8 GHz maar kan dynamisch overgeklokt worden door de Turbo Boost tot 3.3 GHz (bij 2 actieve 7 cores) en 3.5 GHz (bij 1 actieve core). Net als zijn Sandy-Bridge voorganger, de Core i5-2540M, beschikt de processor over 3MB aan L3-Chache.

Ivy Bridge is een verbeterde versie van de Sandy Bridge architectuur op een kleinere 'die' met verbeterede CPU én GPU prestaties. De CPU's worden geproduceerd op 22nm (tegenover de 32nm van de Sandy Bridge) en zijn de eerste die 3D transistors gebruiken voor efficiënter verbruik vergeleken met de vergelijkbaar geklokte Sandy Bridge processors. Andere nieuwe features zijn de geïntegreerde  PCI Express 3.0 en DDR3(L)-1600 ondersteuning.

De prestaties van de Core i5-3320M zouden iets boven die van de vergelijkbaar geklokte Sandy Bridge processor moeten liggen vanwege kleine architectonische verbeteringen. Dit zorgt ervoor dat de prestaties ongeveer 5% beter zouden moeten zijn dan de oude i7-2540M.

Net als de meeste andere Ivy-Bridge dual-cores heeft de i5-3360M een TDP van 35 watt. Hierdoor kunnen ook kleinere laptops gebruik maken van de Core i5.

SerieIntel Core i5
CodenaamIvy Bridge

Serie: Core i5 Ivy Bridge

Intel Core i5-3380M2.9 - 3.6 GHz2 / 4 cores3 MB L3
Intel Core i5-3360M2.8 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-3340M2.7 - 3.4 GHz2 / 4 cores3 MB L3
Intel Core i5-3320M « 2.6 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-3230M2.6 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-3210M2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-3437U1.9 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-3427U1.8 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-3337U1.8 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-3317U1.7 - 2.6 GHz2 / 4 cores3 MB L3
Intel Core i5-3439Y1.5 - 2.3 GHz2 / 4 cores3 MB L3
Intel Core i5-3339Y1.5 - 2 GHz2 / 4 cores3 MB L3
Kloksnelheid2600 - 3300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3 MB
Aantal Cores / Threads2 / 4
Stroomverbruik (TDP = Thermal Design Power)35 Watt
Productietechnologie22 nm
FeaturesHD Graphics 4000 (650-1200MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1200 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Startprijs$225 U.S.
Aankondigingsdatum03-06-2012
Productlink (extern)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.04     gem: 3.1     mediaan: 3.1 (4%)     max: 3.1 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.31     gem: 1.3     mediaan: 1.3 (33%)     max: 1.35 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4292     gem: 4407     mediaan: 4415.5 (27%)     max: 4465 punten
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 9473     gem: 9554     mediaan: 9550 (7%)     max: 9683 punten
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 11505     gem: 11699     mediaan: 11667 (8%)     max: 11913 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5380     gem: 5561     mediaan: 5588 (7%)     max: 5646 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 499.2     gem: 537     mediaan: 540 (6%)     max: 557 s
wPrime 2.10 - wPrime 2.0 32m *
min: 15.85     gem: 17.6     mediaan: 17.4 (3%)     max: 20.9 s
WinRAR - WinRAR 4.0
min: 2522     gem: 2915     mediaan: 2707 (4%)     max: 3361 punten
X264 HD Benchmark 4.0 - x264 Pass 2
min: 16.9     gem: 17.5     mediaan: 17.5 (6%)     max: 17.74 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 86.8     gem: 91     mediaan: 91 (21%)     max: 94 fps
TrueCrypt - TrueCrypt Serpent
min: 0.1572     gem: 0.2     mediaan: 0.2 (5%)     max: 0.161 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.267     gem: 0.3     mediaan: 0.3 (5%)     max: 0.276 GB/s
TrueCrypt - TrueCrypt AES
min: 0.2988     gem: 1.4     mediaan: 1.5 (4%)     max: 1.5 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3727     gem: 3770     mediaan: 3767 (8%)     max: 3808 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 11     gem: 13.2     mediaan: 11.9 (3%)     max: 28.84 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 26     gem: 30     mediaan: 27 (1%)     max: 58.8 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 611     gem: 678     mediaan: 636 (3%)     max: 1122 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 53130     gem: 57674     mediaan: 57480 (27%)     max: 62610 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 37700     gem: 38286     mediaan: 37920 (29%)     max: 39380 MFLOPS
Windows 7 Experience Index - Win7 CPU
min: 7.1     gem: 7.2     mediaan: 7.2 (92%)     max: 7.2 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 9831     gem: 10105     mediaan: 10094.5 (9%)     max: 10559 Points
3DMark 11 - 3DM11 Performance Physics
min: 3138     gem: 3571     mediaan: 3501 (9%)     max: 4041 Points
3DMark - 3DMark Ice Storm Physics
min: 24617     gem: 27316     mediaan: 27316 (22%)     max: 30015 Points
3DMark - 3DMark Cloud Gate Physics
min: 2720     gem: 2721     mediaan: 2721 (7%)     max: 2722 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 4040     gem: 4064     mediaan: 4063.5 (7%)     max: 4087 Points
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
