Intel Core i5-2450M

De Intel Core i5-2450M is een snelle dual-core processor die het eerst verscheen in Dell laptops in november 2011. Deze is gebaseerd op de Sandy Bridge architectuur en biedt Hyper-Threading aan om 4 threads tegelijkertijd te kunnen verwerken (door een efficiënter gebruik van de pipeline). Vergeleken met de snellere Core i7, biedt de i5 een kleine L3 cache van 3 MB. De standaardkloksnelheid is 2.5 GHz, maar middels Turbo Boost kan dit verhoogd worden naar 2.8 GHz (2 actieve cores) en 3.1 GHz (1 actieve core). Vergeleken met de 2510M, biedt de 2450M geen VT-d extensies en Trusted Execution. De geïntegreerde GPU heeft echter wel een hogere Turbo Boost kloksnelheid.
Sandy Bridge is de evolutionaire opvolger van de Arrandale architectuur. De meest significante verbeteringen is de verbeterde Turbo Boost 2.0 en de geïntegreerde grafische chipset op de 32nm CPU core.
De Core i5-2450M biedt een geïntegreerde grafische chipset (Intel HD Graphics 3000) die duidelijk sneller is dan de oudere Intel HD Graphics in de Arrandale CPU's. Omdat de grafische chip geïntegreerd is in de CPU, is deze ook gefabriceerd op 32m, en deelt het snelle L3 cache met de CPU cores (via een nieuwe ring-bus). In de 2450M is deze geklokt op 650MHz of 1300MHz (middels Turbo Boost).
Verder is er een verbeterde dual-channel DDR3 geheugencontroller in de CPU geïntegreerd die gebruikt wordt door zowel de CPU als GPU.
Door de verbeterde architectuur en de nieuwe Turbo Boost 2.0, zijn de gemiddelde prestaties van de Core i5-2450M hoger dan een vergelijkbaar geklokte Arrandale Core i5. Kijkend naar de benchmarks van langzamer geklokte Core i5 CPU's, positioneert de i5-2450M zich iets boven de oudere Core i5-620M en is daarmee ook voor veeleisende taken geschikt.
De 35 watt TDP is inclusief geïntegreerde GPU en geheugencontroller.
| Series | Intel Core i5 |
| Codename | Sandy Bridge |
| Clock Rate | 2500 - 3100 MHz |
| Level 1 Cache | 128 KB |
| Level 2 Cache | 512 KB |
| Level 3 Cache | 3072 KB |
| Number of Cores / Threads | 2 / 4 |
| Max. Power Consumption (TDP = Thermal Design Power) | 35 Watt |
| Transistor Count | 624 Miljoen |
| Manufacturing Technology | 32 nm |
| Die Size | 149 mm2 |
| Max. Temperature | 100 °C |
| Socket | PPGA988 |
| Features | HD Graphics 3000, DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization |
| 64 Bit | 64 Bit support |
| Hardware Virtualization | VT-x |
| Starting Price | $225 U.S. |
| Announcement Date | 11/02/11 |
| Product Link (external) | Intel Core i5 2450M |
CPU Benchmarks
| Cinebench R10 in comparison | ||
| Intel Atom Z670 (min) | 691 | |
| ... | ||
| Intel Core 2 Quad Q9000 | 8059.4 | |
| Intel Core i5 2430M | 8074.9 | |
| AMD Phenom II X4 (Desktop) 905e | 8241 | |
| Intel Core i5 2450M | 8506.8 | |
| Intel Core i5 2520M | 8515.8 | |
| Intel Core i7 3517U | 8524 | |
| Intel Core i7 720QM | 8759.7 | |
| ... | ||
| Intel Core i7 (Desktop) 3960X (max) | 27189.5 | |
