Intel Core i3-2330M

Intel 2330M

De Intel Core i3-2330M is een dual-core processor voor laptops. Deze is gebaseerd op de Sandy Bridge-architectuur en kan dankzij Hyper-Threading tegelijk aan 4 threads werken (voor een efficiënter gebruik van de pipeline). Vergeleken met de snellere Core i5 beschikt de i3 niet over Turbo Boost-technologie voor de CPU en is dan ook op 2.2 GHz (max.) geklokt. Vergeleken met de Core i3-2310M heeft de 2330M slechts een 100 MHz hogere kloksnelheid te bieden.

Sandy Bridge is de evolutionaire opvolger van de Arrandale-architectuur. De meest zichtbare verbeteringen zijn de nieuwe 256-bit AVX-instructieset, de verbeterde Turbo 2.0 (niet beschikbaar voor het CPU gedeelte in de 2330M) en de geïntegreerde grafische kaart op de 32nm CPU core.

De i3-2330M heeft een geïntegreerde grafische kaart (Intel HD Graphics 3000) die duidelijk sneller is dan de oudere Intel HD Graphics in de Arrandale CPU's. Doordat de nieuwe GPU geïntegreerd is in de CPU, is deze ook gefabriceerd op 32nm en deelt het snelle Level 3 cache met de CPU cores (middels een nieuwe ringbus). In de 2330M is deze geklokt van 650-1100 MHz (dankzij Turbo Boost). Snellere Sandy Bridge CPU's hebben GPU's die zijn geklokt tot maximaal 1300 MHz (bijvoorbeeld de i5-2520M).

Verder is er op de CPU een verbeterde dual-channel DDR3 geheugencontroller geïntegreerde die door zowel de CPU als GPU gebruikt wordt.

Door de verbeterde architectuur zijn de gemiddelde prestaties van de Core i3-2330M hoger dan een vergelijkbaar geklokte Arrandale Core i3 zonder Turbo Boost. In de synthetische benchmarks zijn de prestaties vergelijkbaar met de hoger geklokte Core i3-380M (2.5 GHz) en daarmee voldoende voor de meeste toepassingen.

Het TDP van 35 watt is inclusief geïntegreerde GPU en geheugencontroller.

SerieIntel Core i3
CodenaamSandy Bridge

Serie: Core i3 Sandy Bridge

Intel Core i3-2370M2.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2350M2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-2348M2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-2330M « 2.2 GHz2 / 4 cores3 MB L3
Intel Core i3-2328M2.2 GHz2 / 4 cores3 MB L3
Intel Core i3-2312M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2310M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2308M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2377M1.5 GHz2 / 4 cores3 MB L3
Intel Core i3-2375M1.5 GHz2 / 4 cores3 MB L3
Intel Core i3-2367M1.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2365M1.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2357M1.3 GHz2 / 4 cores3 MB L3
Kloksnelheid2200 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3 MB
Aantal Cores / Threads2 / 4
Stroomverbruik (TDP = Thermal Design Power)35 Watt
Aantal Transistoren624 miljoen
Productietechnologie32 nm
Chipgrootte149 mm2
Max. Temperatuur85 (PGA); 100(BGA) °C
SocketrPGA988B / BGA1023
FeaturesHD Graphics 3000 (650-1100MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1100 MHz)
64-Bit64-Bit-ondersteuning
Architecturex86
Aankondigingsdatum15-05-2011
Productlink (extern)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.07     gem: 2.1     mediaan: 2.1 (3%)     max: 2.14 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2869     gem: 2888     mediaan: 2888 (17%)     max: 2904 punten
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 6263     gem: 6457     mediaan: 6465.5 (5%)     max: 6593 punten
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 7745     gem: 7876     mediaan: 7887 (5%)     max: 7944 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3591     gem: 3624     mediaan: 3623.5 (4%)     max: 3654 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 722     gem: 781     mediaan: 789 (9%)     max: 826 s
wPrime 2.10 - wPrime 2.0 32m *
min: 22     gem: 24.7     mediaan: 25.1 (5%)     max: 26.38 s
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (3%)
TrueCrypt - TrueCrypt AES
0.2 GB/s (1%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2610     gem: 2629     mediaan: 2627 (6%)     max: 2649 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 17     gem: 17.6     mediaan: 17.7 (4%)     max: 18 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 40     gem: 40.3     mediaan: 40 (2%)     max: 41 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 926     gem: 936     mediaan: 941 (4%)     max: 944 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 33000     gem: 35000     mediaan: 35000 (17%)     max: 37000 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 22170     gem: 24085     mediaan: 24085 (18%)     max: 26000 MFLOPS
Windows 7 Experience Index - Win7 CPU
6.5 Points (83%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 6879     gem: 7014     mediaan: 7008 (6%)     max: 7165 Points
3DMark 11 - 3DM11 Performance Physics
min: 2782     gem: 2786     mediaan: 2786 (8%)     max: 2790 Points
- Benchmarkresultaten voor deze videokaart
- Gemiddelde benchmarkresultaten voor deze videokaart
* Kleinere getallen betekenen een hogere prestatie
